Function
name
code
Input terminal X1
F5.00
function selection
Input terminal X2
F5.01
function selection
Input terminal X3
F5.02
function selection
reserved
F5.03
reserved
F5.04
F5.05 reserved
F5.06
reserved
F5 –terminal correlative function parameter group
0: leave control terminal unused
1: multi-section speed control terminal
2: multi-section speed control terminal
3: multi-section speed control terminal
4: multi-section speed control terminal
5: external forward run jog control
6: external reverse run jog control
7: Acce/Dece time option terminal 1
8: Acce/Dece time option terminal 2
9: Acce/Dece time option terminal 3
10: external device failure input
11: external reset input
12: free stop input
13: external stop-running order
14: stop DC braking input command DB
15: inverter run banned
16: frequency increasing control (UP)
17: frequency degression control (DOWN)
18: Acc/Dec ban command
19: three-line run control
20: closed-loop ineffective
21: PLC ineffective
22: simple PLC pause control
23: PLC stop status reset
24: frequency provision channel option 1
25: frequency provision channel option 2
26: frequency provision channel option 3
27: frequency switched to CCI
28: command switched to terminal
29: run command channel option 1
30: run command channel option 2
31: run command channel option 3
32: traverse jump-in
33: external interruption input
34: interior counter reset end
35: interior counter triggering end
36: interior timer reset end
37: interior timer triggering end
38: reserved
Same as above
Same as above
3 Function parameter schedule graph
Set range
16
Factory modifi
unit
default cation
1 0 ×
×
×
