10.1.14 Engine lack power, idle erratic, or runs lean
1. The fuel pressure is erratic. This may be due to the pump sucking air on the in feed which
causes cavitations and loss of pressure. This happens more frequent when the engine is
hot.
2. Injector positive is wired incorrectly. It does not have its own supply direct from the battery
via relay 1.
3. Incorrect setting of fuel maps.
4. Fuel pressure or flow rate to low. Dirty fuel filter.
5. Faulty fuel pump.
10.1.15 ECU cuts during driving – Interference
Interference or feedback is caused by the following reasons:
1. Earth wires incorrect. Tie the black wires of the harness to the ECU enclosure. Tie a 2.5mm
or thicker wire from the ECU enclosure to the body as an earth strap if it is not screwed
directly onto the body.
2. Screened cables of the sensors must be connected close to the sensors to ensure
maximum screening.
3. No screen wire must be connected to the engine. Only to the TPS, Map sensor
Temperature sensors and lambda sensor if specified by the drawing. Don't common it with
engine ground.
4. Faulty High Tension sparkplug wires.
5. HT lead run too close to sensitive input wires.
6. The Ignition Positive wire is used for high current devices that generate voltage spikes.
Couple all coils etc via relay circuits from the fuse box supplied.
7. Poor voltage supply to the ECU.
8. Large relays do not have decoupling diodes and induce spikes on the ignition wire. Install
free running diode supplied according to drawings.
9. Incorrect alternator wiring. The main charge wire (thick positive) should be connected at the
battery positive terminal rather than the vehicle harness. The battery acts as the smoothing
capacitor.
10. Battery earth straps are not adequate. Earth straps should go from the battery negative to
the body and also from the battery negative to the engine.
11. Incorrect rotor fazing. The spark has to jump a gap in the distributor inducing spikes on the
pickup device.

11. Specifications

These specifications are for the advance ECU combinations. This means that not all may be
applicable to the standard and intermediate ECU. See the
variation.
11.1.1 Inputs
2x Magnetic inputs or 2x Hall or Optic inputs or combination of the 2 Groups
1x Map sensor input 0 – 5V
1x Water Temperature Input – 2K NTC Resistance Sensor
1x Air Temperature Input – 10K NTC Resistance Sensor
1x Lambda Input 0 – 1 V
1x General Input – Selectable for Pot Input, Launch Button or Battery Voltage Correction
Software RS232 Connection
Programmer Connection
11.1.2 Outputs
6x 7A current Outputs to Ground (coil + injector drivers)
