- Page 1 USER MANUAL AKASO EK7000 Action Camera V1.3...
-
Page 2: Table Of Contents
Getting Started Overview of Modes Customizing Your EK7000 Connecting to the App Playing Back Your Content Deleting Videos and Photos on Your EK7000 Offloading Your Content Reformatting Your microSD Card Maintenance Your Camera Maximizing Battery Life Battery Storage and Handling... -
Page 3: What's In The Box
USB Cable Tethers Lens Cloth Helmet Mounts Charger Backdoor Quick Start Guide AKASO EK7000 Action Camera Bandages Battery Remote Quick Start Guide How to use all sorts of accessories of action camera? Scan the following QR code or enter the website to watch the video. -
Page 4: Your Ek7000
YOUR EK7000 14 6... - Page 5 Shutter/Select Button Micro HDMI Port Working/Wifi Indicator Lens Power/Mode/Exit Button Screen Charging Indicator Up Button microSD Slot Down/Wifi Button Micro USB Port Battery Door Note: Camera does not record sound when it is in the waterproof case.
-
Page 6: Getting Started
GETTING STARTED Welcome to your new EK7000. To capture video and photos, you need a microSD card (sold separately). MICROSD CARDS Use brand name memory cards that meet these requirements: • MicroSD, microSDHC, or microSDXC • Class 10 or UHS-I rating •... -
Page 7: Overview Of Modes
TURNING ON/OFF Wifi To turn on Wifi Turn on camera, press Down button to turn on Wifi. To turn off Wifi Press Down button to turn off Wifi. OVERVIEW OF MODES There are 5 modes: Video, Photo, Burst Photo, Time Lapse and Setting. Video Mode Video Mode is the default mode when you turn on the camera. - Page 8 Photo Mode Press Mode button once to switch to Photo Mode after you turn on camera. In Photo Mode, press Shutter button, the camera takes a photo. 0004 | 30297 12MP WIDE Burst Photo Mode Press Mode button several times to switch to Burst Photo Mode. In Burst Photo Mode, press Shutter button, the camera takes 3 photos per second.
- Page 9 Time Lapse Photo Mode Press Mode button several times to switch to Time Lapse Photo Mode. In Time Lapse Photo Mode, press Shutter button, the camera takes a serial of photos at 3s/ 5s/10s intervals. 0004 | 30297 12MP WIDE Settings Press Mode Button several times to switch to settings mode.
-
Page 10: Customizing Your Ek7000
CUSTOMIZING YOUR EK7000 Settings 1. Video Resolution: 1080P60FPS, 1080P30FPS, 4K25FPS, 2.7K30FPS, 1080P60FPS, 720P120FPS, 720P60FPS Default setting is 1080P 60FPS. 2. Looping Record: Off/On Default setting is off. Using Looping Record, you can continuously record video, but save only the moments that you want. - Page 11 Shutter: On/Off Start-up: On/Off Beep: On/Off Default setting is on. Sets the volume of your EK7000's alerts. Volume: 0, 1, 2, 3 Default setting is 3. This option lets you adjust the volume. Press Shutter button to adjust the volume.
-
Page 12: Connecting To The App
2. Connect the Wifi “EK7000” and enter the password on your smartphone WLAN setting. 3. Open AKASO GO App, tap “+” icon on the upper right corner. Add “EK7000” and click the “Live Preview”. 4. Your camera will be connected to the AKASO GO App. -
Page 13: Deleting Videos And Photos On Your Ek7000
TV. With this method, playback resolution depends on the resolution of the device and its ability to play back that resolution. Viewing Videos and Photos on Your EK7000 1. Turn on camera to enter Video or Photo mode. -
Page 14: Offloading Your Content
Note that you must use a card reader to offload photos or audio files. Offloading Your Content to Smartphone 1. Open the AKASO GO App. Connect the camera with the app. 2. Tap Playback icon to see all the videos and photos. -
Page 15: Reformatting Your Microsd Card
REFORMATTING YOUR MICROSD CARD To keep your microSD card in good condition, reformat it on a regular basis. Reformatting erases all of your content, so be sure to offload your photos and videos first. 1. Turn on camera. 2. Press Mode button four times, then Shutter button to enter Camera Setting. 3. -
Page 16: Maximizing Battery Life
BATTERY STORAGE AND HANDLING The camera contains sensitive components, including the battery. Avoid exposing your camera to very cold or very hot temperatures. Low or high temperature conditions may temporarily shorten the battery life or cause the camera to temporarily stop working properly. Avoid dramatic changes in temperature or humidity when using the camera, as condensation may form on or within the camera. -
Page 17: Remote
REMOTE Photo Button Video Button Splashproof only, not waterproof VIDEO To record Video, verify the camera is in Video mode. To start recording: Press the Grey Video Button. The camera will emit one beep and the camera light will flash while recording. To stop recording: Press the Grey Video Button again. - Page 18 CR2032 BATTERY REPLACEMENT FOR EK7000 REMOTE 1. Use a 1.8mm Phillips tip screwdriver to remove the 4 screws on the back cover of the remote, allowing you to open it. 2. Remove another 4 screws on PCB board. 3. Lift the PCB board and slide out the battery, as shown in the picture.
-
Page 19: Mounting Your Camera
4. Install the new battery, keeping the “+” pole facing up. 5. Install all 4 screws back onto the PCB board. 6. Install all 4 screws back into the cover. MOUNTING YOUR CAMERA Attach your camera to helmets, gear and equipment. -
Page 21: Contact Us
CONTACT US For any inquiries with AKASO products, please feel free to contact us, we will respond within 24 hours. E-mail: cs@akasotech.com Tel: (888) 466-9222 (US) Mon-Fri (except holiday) 9am-5pm (EST) Official website: www.akasotech.com...
