User manual of EC160 elevator intelligent integrated machine Preface Preface EC160 elevator intelligent integrated machine is the new intelligent elevator control system with drive technology, control technology and network communication technology. Applying advanced frequency vector control technology, intelligent elevator control technology and network communication technology, our products integrate drive, control and management of the elevator to improve the safety and reliability, operation, economy and individual design.
Page 3
User manual of EC160 elevator intelligent integrated machine Content Content Chapter 1 EC160 configuration ....................1 1.1 Hardware configuration ..................... 1 1.2 Standard functions of software .................. 2 1.3 Optional functions of software ................. 10 Chapter 2 Safety precautions and notices ................12 2.1 Safety marks ......................
Page 4
User manual of EC160 elevator intelligent integrated machine Content 4.3.2 Specification of digital input signal ............... 31 4.3.3 Specification of relay digital output signal ............31 4.4 Encoder wiring ......................31 4.4.1 Encoder wiring of asynchronous master .............. 31 4.4.2 Encoder wiring of synchronous master ..............31 4.5 System installation and configuration..............
Page 5
User manual of EC160 elevator intelligent integrated machine Content 6.2.3 System monitoring---drive state ................74 6.2.4 System monitoring---main controller ..............75 6.2.5 System monitoring---car controller ............... 76 6.3 Fault history record ....................76 6.4 Language selection ....................77 6.5 Parameters setting inquiry ..................77 6.5.1 Parameters setting---master drive control ............
Page 6
User manual of EC160 elevator intelligent integrated machine Content 8.1 Inspection and confirmation of the electrical assembly ......... 153 8.2 Power on and check ..................... 153 8.3 Parameter check ....................155 8.4 Autotuning of the hoistway position ............... 155 8.5 Autotuning of the hoistway position by the up/down button ........156 8.6 Run at fast speed ....................
Page 7
User manual of EC160 elevator intelligent integrated machine Content 9.4.5 Definition of the input/output interface ............... 179 9.4.6 Definition of jumper terminal ................180 9.4.7 Instruction of LED ....................180 9.4.8 Diagram of communication interface..............181 9.4.9 Debugging ......................182 9.4.10 Precautions for separate standby of bias floors ..........
Page 8
User manual of EC160 elevator intelligent integrated machine EC160 configuration Chapter 1 EC160 configuration 1.1 Hardware configuration Name Model Application Qty. Position Remarks EC160 Equipped, Motor drive elevator To the Elevator select model control and 1 for each intelligent actual...
Page 9
User manual of EC160 elevator intelligent integrated machine EC160 configuration 1.2 Standard functions of software Type Function name Function instruction Remarks Direct stop According to the distance control principle, Standard operation generate a running curve Internal External weighing compensation device is...
Page 10
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks door lock closes, the overload switch will act and the elevator opens the door reversely; after the door lock closes, overload protection will cancel.
Page 11
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks Split-level The elevator returns to the ground floor for Standard protection correction when split-level The system judges the current height and speed by high speed counting. In running...
Page 12
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks Inspection running Operational function Standard The speed switches to the low speed of Inspection speed 50mm/s when the elevator runs at the Standard limit inspection speed to the position of low speed forced deceleration switches.
Page 13
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks inside and outside, go straight to the floor triggering calling VIP running, and keep opening. When the elevator responds to one inside calling after closed manually, it will exit calling VIP running.
Page 14
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks operation all calling records and run to the home floor at the fastest speed. After that, output fire signal to keep the door open. If the elevator...
Page 15
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks the opening command and the elevator will open the door. If the door of the elevator is not closed after closing for 20 seconds, the elevator will open the door.
Page 16
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks Vice control box With the same button and function with the Function operation main control box, need to set F0_09 to 0. selection To avoid short circuit of the lock, disconnect...
Page 17
User manual of EC160 elevator intelligent integrated machine EC160 configuration Type Function name Function instruction Remarks The brake contactor and strong brake Strong brake contactor output at the same time. After the Function contactor set delay, the strong brake contactor is selection disconnected.
Page 18
User manual of EC160 elevator intelligent integrated machine EC160 configuration Function Function instruction Remarks name the hall for function. The user can only record the calling command card calling service with a card. control Single door Configure operator and Default configuration...
Page 19
Danger Please maintain the machine after the power supply is disconnected for at least 10 minutes. The marks are presented on the front cover of the inverter. Follow the instructions of this manual when using EC160 elevator intelligent integrated machine.
Page 20
User manual of EC160 elevator intelligent integrated machine Safety precautions and notices 2.4 Safety precautions 2.4.1 Unpacking inspection Do not install or work on any damaged or faulty parts, otherwise injury may occur. Upon unpacking, confirm the following: 1. No damage occurred during transportation (the damage or scratch to the machine).
Page 21
User manual of EC160 elevator intelligent integrated machine Safety precautions and notices shock and fire may occur. Ensure the action is right after safe connection, otherwise physical injury may occur. Do not touch the conductor parts of output terminals directly, connect the output wires with the casing or short circuit the output wires, otherwise the electric shock, short circuit or fire may occur.
Page 22
Cooling fins will become hot. Do not touch to avoid physical hurt. Do not touch the braking resistor, otherwise physical hurt and electric shock may occur. EC160 elevator intelligent integrated machine is set well in factory. Do not refit by yourself, especially in running, otherwise damage to the machine may occur.
Page 23
User manual of EC160 elevator intelligent integrated machine Product overview Chapter 3 Product overview This chapter introduces the model, specification and performance of EC160 elevator intelligent integrated machine, as well as the delivery and installation. 3.1 Model description 3.2 Name plate 3.3 Power selection...
Page 24
User manual of EC160 elevator intelligent integrated machine Product overview Rated output Rated output Min. braking Model Braking unit power (kW) current (A) resistance EC160-5R5-4 13.0 Built-in 55Ω/1500W EC160-7R5-4 18.5 Built-in 50Ω/2000W EC160-011-4 11.0 27.0 Built-in 40Ω/4000W EC160-015-4 15.0 34.0 Built-in 32Ω/4500W...
Page 25
User manual of EC160 elevator intelligent integrated machine Product overview Item Name Specification High voltage inspection input 3 high voltage inspection input terminals, AC/DC 110V port 6 digital output terminals, DC30V/5A, AC250V/5A, part of Digital output port output terminals can use programmable logic control...
Page 26
User manual of EC160 elevator intelligent integrated machine Product overview 3.5 Delivery confirmation Items Method The received product is in accordance Confirm by the model in the name plate with the ordered. Whether there is damage. Check the appearance Whether there is loose screws.
Page 27
User manual of EC160 elevator intelligent integrated machine Product overview Code Meaning Instruction Elevator error Flash when elevator error The LED displaying is defaulted as the current floor when there is no fault, while fault occurs, Er is flashing and LED will report the fault code directly, such as and flashing.
Page 28
User manual of EC160 elevator intelligent integrated machine Installation and wiring Chapter 4 Installation and wiring This chapter describes the terminals configuration, including main circuit terminal configuration, control circuit terminals configuration and PG terminals configuration. Follow the guidelines of these manual and only professional electricians are allowed to operate, otherwise electric shock may occur.
Page 29
User manual of EC160 elevator intelligent integrated machine Installation and wiring 4.1 Dimensions Figure 4-1 Installation dimension C hole size Screw Model W (mm) H (mm) D (mm) A (mm) B (mm) (mm) bolt EC160-004-2 334.5 φ7 EC160-5R5-2 334.5 φ7 EC160-7R5-2 334.5...
Page 30
User manual of EC160 elevator intelligent integrated machine Installation and wiring EC160-015-4 334.5 φ7 EC160-018-4 φ7 EC160-022-4 φ7 EC160-030-4 φ7 When design the control cabinet, the left and right space should be no less than 50mm and the above and below space should be no less than 100mm to ensure enough cooling.
Page 31
User manual of EC160 elevator intelligent integrated machine Installation and wiring encoder Terminal for parallel connection or group CAN communication control communication Terminal for Apply to DC12V, push-pull or open collector asynchronous master encoder encoder Terminal only for Use specific cables when connecting with...
Page 32
User manual of EC160 elevator intelligent integrated machine Installation and wiring Grounding terminal 4.2.3 Specification of the main circuit leads Grounding Model Input leads (mm²) Output leads (mm²) leads (mm²) EC160-1R5-S2 EC160-2R2-S2 EC160-004-2 EC160-5R5-2 EC160-7R5-2 EC160-011-2 EC160-015-2 EC160-018-2 EC160-004-4 EC160-5R5-4...
Page 33
User manual of EC160 elevator intelligent integrated machine Installation and wiring no more than 4Ω. Do not use the special grounding wires with other devices. Do not short circuit or ground the input/output circuits. The output terminal U/V/W of the machine needs to go through the ground metal pipe and route separately with the signal wires of the control circuit to avoid interference.
Page 34
User manual of EC160 elevator intelligent integrated machine Installation and wiring Figure 4-6 Connection diagram of energy feedback unit 4.2.7 Connection of PE terminal The PE terminal needs to be grounded with proper techniques to avoid electric shock and fire. The resistance is less than 10Ω.
Page 35
User manual of EC160 elevator intelligent integrated machine Installation and wiring Plug-in Terminal definition Code indicator Remarks code Contact detection of LED11 LINE3 Default NO input star-delta contactor Inspection signal (off is LED12 INS1 Default NC input inspection) Inspection LED13...
Page 36
User manual of EC160 elevator intelligent integrated machine Installation and wiring Plug-in Terminal definition Code indicator Remarks code Spare input 1 LINE2 LED27 Default NO input MF input terminal When input low level is valid (SW3 is at 24V+), 24V- terminal is digital input 24V- common terminal.
Page 37
User manual of EC160 elevator intelligent integrated machine Installation and wiring Plug-in Terminal definition Code indicator Remarks code output 250VAC COM2 Y2 common terminal COM2 Star-delta contactor output (synchronous LED36 Relay NO output 5A, tractor) 250VAC COM3 Y3 common terminal...
Page 38
User manual of EC160 elevator intelligent integrated machine Installation and wiring 4.3.2 Specification of digital input signal Input Open circuit input Optical isolation “0” electrical level 0~2mA Current signal “1” electrical level 4.5~8mA “0” electrical level 18~24V DC Voltage signal “1”...
Page 39
U, V and W encoder: the polarity number of the encoder should be the same with that of the motor. If using the encoder, it is necessary to install weighing compensation devices. Besides, EC160 can extend PG card of Endat encoder via CN11 to support ECN1313 encoder. The encoder wiring diagram of synchronous master is shown as follows:...
Page 40
User manual of EC160 elevator intelligent integrated machine Installation and wiring For the elevators with different speed, install forced deceleration switch. Generally, install SDS1 and SUS1 for the elevator with speed less than 1.75m/s; install SDS2 and SUS2 for the elevator with speed of 2.0m/s~3.0m/s (in order to avoid shock, bitable magnetic switch is recommended).
Page 41
User manual of EC160 elevator intelligent integrated machine Installation and wiring stop. After the elevator compresses the buffer according to the national standards, the switch still keeps acting. The table above lists the recommended position of corresponding forced deceleration switch at common speed. The specific conditions...
Page 42
User manual of EC160 elevator intelligent integrated machine Installation and wiring Figure 4-9 Installation position of hoistway switch...
Page 43
User manual of EC160 elevator intelligent integrated machine Installation and wiring 4.5.3 Connection precautions of peripheral devices 4.5.3.1 Power supply The voltage of the power supply corresponds to the rated voltage of the machine, the fluctuation range<7%. 4.5.3.2 Breaker The breaker is needed between the power supply and the input terminals of the integrated machine.
Page 44
User manual of EC160 elevator intelligent integrated machine Installation and wiring If the parallel distance between the communication and power cables is longer than 5m, there should be a 30cm space to prevent power interference. If the wiring space is limited and cannot satisfy the requirements, use the shielded twisted pair and carry out single-point grounding.
Page 45
User manual of EC160 elevator intelligent integrated machine Installation and wiring 4.6 Installation guideline to EMC compliance 4.6.1 General knowledge of EMC EMC is the abbreviation of electromagnetic compatibility, which means the device or system has the ability to work normally in the electromagnetic environment and will not generate any electromagnetic interference to other equipments.
Page 46
User manual of EC160 elevator intelligent integrated machine Installation and wiring In the system, EMS and EMI of inverter coexist. Decrease the EMI of inverter can increase its EMS ability. 4.6.3 EMC installation guideline In order to ensure all electric devices in the same system to work smoothly, this section, based on EMC features of inverter, introduces EMC installation process in several aspects of application (noise control, site wiring, grounding, leakage current and power supply filter).
Page 47
User manual of EC160 elevator intelligent integrated machine Installation and wiring and output power cable can be coupling each other to make the EMC filter out of function. 4.6.3.3 Grounding Inverter must be grounded safely when in operation. Grounding enjoys priority in all EMC methods because it does not only ensure the safety of equipment and persons, but also is the simplest, most effective and lowest cost solution to EMC problems.
Page 48
User manual of EC160 elevator intelligent integrated machine Debugging tools Chapter 5 Debugging tools 5.1 Instruction Manual controller is the specific debugging tools for system debugging and maintenance. It consists of LCD display and keys which has following functions: 5.1.1 Main controlling interface Following elevator state can be watched through LCD displaying: The automotive, maintenance, attendant, fire safety, overload and door open state;...
Page 49
User manual of EC160 elevator intelligent integrated machine Debugging tools Factory setting restore; Fault history clearance. 5.2 Connection method Figure 5-1 Interface of the manual controller and EC160 5.3 Keys and LED indicator 5.3.1 Key definition Instruction Escape key, return to the...
Page 50
User manual of EC160 elevator intelligent integrated machine Debugging tools 5.3.2 Manual controller and LED indicator Code Meaning Instruction Connection signal of manual controller On when normal communication and EC160 Connection signal of manual controller On when normal communication and the car...
Page 51
The simple manual controller (hereafter referred to as controller) consists of 5-figure LED, 7 LED indicators and 8 keys. As the simple debugging tool for EC160, the controller has the basic functions of parameter setting, fault inquiry, running monitoring, factory authorization and manual calling.
Page 52
5.5.3 LED indicator instruction Code Description On when communication between controller and EC160 is normal On when the setting or monitoring parameter is speed On when communication between controller and computer is normal On when no communication for the controller...
Page 53
User manual of EC160 elevator intelligent integrated machine Debugging tools AL total No serial Er fault Corresponding word number number code floor no fault record Displayed word SEC fault time StENd weighing StErr weighing Corresponding word second autotuning succeeded autotuning failed...
Page 54
User manual of EC160 elevator intelligent integrated machine Debugging tools 5.5.5 Operation procedure flowchart Figure 5-5 Operation procedure flowchart of simple manual controller 5.5.6 Monitoring instruction Name Display format Detailed description Feedback speed Unit: mm/s, FUN LED on...
Page 55
User manual of EC160 elevator intelligent integrated machine Debugging tools Reference speed Unit: mm/s, FUN LED on Current floor Floor number Current height Unit: m Output voltage Unit: V, V LED on Output current Unit: A, A LED on Output frequency...
Page 56
User manual of EC160 elevator intelligent integrated machine Debugging tools 5.5.7 Corresponding list of function parameters Function Default Name Detailed instruction of parameters code value P0 Group Master drive control 0: Vector control without PG P0.00 Speed control mode 1: Vector control with PG...
Page 57
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value P0.14 Reserved 0~65535 P0.15 Reserved 0~65535 P1 Group Speed curve adjustment P1.00 Increasing acceleration 1 0.001~1.000m/s 0.350 P1.01 Increasing acceleration 2 0.001~10.000m/s 0.350...
Page 58
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Rated frequency of the P2.02 3.00Hz~400.00 50.00 motor Rated speed of the P2.03 1~30000rpm 1440 motor Rated voltage of the P2.04...
Page 59
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Disconnection 0.1~10.0s P3.04 detection time of the 0.0: No detection encoder at high speed Reverse detection time 0.1~10.0s P3.05 of the encoder 0.0: No detection...
Page 60
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value ASR high speed P4.04 0~100 proportional gain ASR high speed P4.05 0.01~10.00s 0.60 integral time Speed detection high P4.06 speed filter times Switch high point P4.07...
Page 61
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value P4.22 Rated load 0~10000kg 1000 0: Digital input Weighing input P4.23 1: Analog input of car selection 2: Analog input of engine room...
Page 62
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Overload pre-warning P5.04 20.0%~150.0% 130.0 threshold 0: Corresponds to the rated current of the motor, detecting all the time 1: Corresponds to the rated current of the...
Page 63
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Converting module P7.04 -20.0~100.0°C Read only temperature P7.05 DSP software version 1.00~9.99 Read only P7.06 MCU software version 1.00~9.99 Read only P7.07...
Page 64
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value A2.00 1 floor displaying 0~9999 1617 A2.01 2 floor displaying 0~9999 1618 A2.02 3 floor displaying 0~9999 1619 A2.03 4 floor displaying...
Page 65
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value H2.05 Front door 41~48 floor 0~255 H2.06 Front door 49~56 floor 0~255 H2.07 Front door 57~64 floor 0~255 H3 Group Rear door stopping floor H3.00...
Page 66
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value L0.01 Up bias floor 0~64 L0.02 Down bias floor 0~64 L0.03 Parallel home floor 0~64 T0 Group Time setting T0.00 Open delay 0~500.0s...
Page 67
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Single floor running T0.18 0~100.0s 45.0 protection time Fast arrival opening T0.19 0~65535 delay Beam keeping failure T0.20 0~65535s time Reserved T0.21...
Page 68
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value 0: Main elevator and sub-elevator opening at Floor opening mode of the same time F0.05 parallel outside calling 1: Main elevator opening...
Page 69
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value 9: Reserved 10: Inspection signal 11: Inspection up button signal 12: Inspection down button signal 13: Up door area (rear door opening...
Page 70
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value 0~65535 Unit: Define RDC port of DC01, LED light corresponding to PAS Ten: Define RDO port of DC01, LED light corresponding to DOD F0.15...
Page 71
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value 0~65535 1: Calling below 32 floor connected to inside line 2: Parallel calling scan in cycle 4: Speed involved in parallel control...
Page 72
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value 0~65535 0: 220V power supply (The switching of drive power supply is controlled by Y6. Set KPWR input to normally closed logic. Detect UPS output feedback and bus voltage.
Page 73
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Time 1 of time sharing F0.29 service 0~65535 Stop at 17~32 floors Time 1 of time sharing F0.30 service 0~65535 Stop at 33~48 floors Time 1 of time sharing F0.31...
Page 74
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Time 3 of time sharing F0.40 service 0~65535 Stop at 1~16 floors Time 3 of time sharing F0.41 service 0~65535 Stop at 17~32 floors Time 3 of time sharing F0.42...
Page 75
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Rear door 33~48 F0.63 communicating IC card 0~65535 open floors Rear door 49~64 F0.64 communicating IC card 0~65535 open floors F0.65...
Page 76
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value F0.75 Analog LL set voltage 0~65535 F0.76 Analog FL set voltage 0~65535 F0.77 Analog OL set voltage 0~65535 … … …...
Page 77
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value High bit of input U1.14 0~65535 Read only terminal state Extension input U1.15 0~65535 Read only terminal state U1.16 Number clearance tip...
Page 78
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value U2 Group Hoistway information U2.00 Total height of the floor 0~600.00m Read only Low speed down forced U2.01 0~60.000m Read only...
Page 79
User manual of EC160 elevator intelligent integrated machine Debugging tools Function Default Name Detailed instruction of parameters code value Low 16-bit input E0.08 terminal state of the 1.0000~1.FFFF main board at fault High 16-bit input E0.09 terminal state of the 2.0000~2.FFFF...
Page 80
User manual of EC160 elevator intelligent integrated machine Function parameters Chapter 6 Function parameters 6.1 Original debugging interface 【main menu】 【Monitoring password input】 A system control 00000000 B fault record After input C language selection correct password D parameters setting...
Page 81
User manual of EC160 elevator intelligent integrated machine Function parameters E password setting F system autotuning G data management H system information 6.2.1.2 Running state Auto opening Floor: 1 0mm/s Height: Leveling distance: 100mm 1234567890 1234567890 ↑ ↓ 1234567890 1234567890...
Page 82
User manual of EC160 elevator intelligent integrated machine Function parameters C language selection [2] random running 3. Reference frequency: D parameters setting [3] drive state 000.00Hz inquiry [4] main controller 4. Output frequency: E password setting [5] car controller 000.00Hz F system autotuning 5.
Page 83
User manual of EC160 elevator intelligent integrated machine Function parameters forced contactor door lock speed-changing 19 contact of the 27 hardware enabling 28 6 high speed up forced brake contactor pre-opening feedback speed-changing 29 pre-opening 7 down limit adhesion 8 up limit...
Page 84
User manual of EC160 elevator intelligent integrated machine Function parameters The fault history record: the first one stands for the latest fault and the floor stands for the elevator floor where the fault occurs. The detailed fault time and instructions can be attained by pressing ENT.
Page 85
User manual of EC160 elevator intelligent integrated machine Function parameters 6.5.1 Parameters setting---master drive control 【main menu】 【parameters setting 【P0 master drive A system control inquiry】 control】 B fault record P0 master drive 00 speed control mode C language selection...
Page 86
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify P0_02 Max. speed of the elevator 0.100~6.000m/s【1.750】 in running This is the upper limit of the actual speed of the elevator.
Page 87
User manual of EC160 elevator intelligent integrated machine Function parameters 6.5.2 Parameters setting---speed and deceleration distance 【main menu】 【parameters setting 【P1 speed and A system control inquiry】 deceleration distance】 B fault record P0 master drive 00 increasing C language selection...
Page 88
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Reducing deceleration 1 (fast P1_03 deceleration at the beginning 0.001~9.999m/s 【0.350】 stage) Reducing deceleration 2 (fast P1_04 deceleration at the beginning 0.001~9.999m/s 【0.350】...
Page 89
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify P1_07 Zero-speed threshold 0~0.050m/s【0】 in running Zero-speed threshold means the Min. running speed before braking. Generally, it does not need setting.
Page 90
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code High-speed current loop modify P1_16 0~65535【0】 proportional coefficient in running High-speed current loop P1_17 0~65535【0】 integral coefficient The parameters do not need setting usually. When the load changes, the master will show different features at high/low speed.
Page 91
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify P2_00 Motor type selection 0-1【1】 in running Select the motor type 0: Asynchronous master 1: Synchronous master After changing the motor type, it needs to change the corresponding parameters of the encoder.
Page 92
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code the basic ones of high performance vector control, having direct impact on the performance control. Do not modify above parameters without permits; otherwise, wrong parameters may cause motor damage.
Page 93
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify P3_00 Encoder type selection 0-3【1】 in running Select the encoder type. Generally, the asynchronous master is set to 0 and applying I/O board AJ2 encoder interface.
Page 94
User manual of EC160 elevator intelligent integrated machine Function parameters the encoder at high speed Reverse detection time of the P3_05 0.0~10.0s【1.0】 encoder Above parameters are the detection time of the encoder fault. Setting 0 can cancel the fault protection. Ensure the braking is open or not when reporting the encoder fault and ensure whether the elevator is sliding when reverse fault occurs to the encoder.
Page 95
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify P3_10 Static identification current 10.0-150.0%【50】 in running This parameter is used to set the percentage of the identification current to the rated current of the motor.
Page 96
User manual of EC160 elevator intelligent integrated machine Function parameters C language selection control proportional gain D parameters setting P1 speed and 01 ASR low speed integral inquiry deceleration time E password setting distance 02 Speed detection low F system autotuning...
Page 97
User manual of EC160 elevator intelligent integrated machine Function parameters coefficient 22 Rated load 23 Weighing input selection 24 Weighing compensation input channel 25 Pre-torque bias 26 Bias and gain at the braking side 27 Bias and gain at the...
Page 98
User manual of EC160 elevator intelligent integrated machine Function parameters Figure 6-2 Parameters of speed loop PI The system's dynamic response can be faster if the proportional gain is increased or the integral time is decreased; If the proportional gain is too large or the integral time is too small, the system will become overshoot and tend to oscillate;...
Page 99
User manual of EC160 elevator intelligent integrated machine Function parameters Figure 6-3 ACR switching Function Instruction Setting range【default value】 Remarks code modify P4_10 ACR filter coefficient 0-65535【3】 in running bit0~bit2 corresponds to the running torque command filter times, the Max. value: 7 (the default value 3 means the filter time=2^3/carrier frequency).
Page 100
User manual of EC160 elevator intelligent integrated machine Function parameters in running 【150.0】 100.0% corresponds with the rated current of inverter. For type load test, need to enlarge the parameter. Function Instruction Setting range【default value】 Remarks code P4_14 0~1【1】 Load compensation enabling P4_15 0.000~5.000s【0.700】...
Page 101
User manual of EC160 elevator intelligent integrated machine Function parameters P4_23 Weighing input selection 0~2【0】 P4_23: Weighing input selection Set the signal input of LL, FL and OL. 0: Light load, full load and overload correspond to LL, FL and OL.
Page 102
User manual of EC160 elevator intelligent integrated machine Function parameters P4_25, P4_26 and P4_27 are only valid when P4_24 is set to be non-zero. Function Instruction Setting range【default value】 Remarks code Analog input filter of car P4_28 0.00~0.50s【0.1】 weighing Not modify...
Page 103
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code P5_00 Input phase loss protection 0-2【0】 modify in running P5_01 Output phase loss protection 0-1【1】 Above function codes select input/output phase loss protection enabling.
Page 104
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Overload pre-warning P5_04 20.0%~150.0%【130.0】 threshold Not modify P5_05 Overload pre-warning selection 0-3【0】 in running Overload pre-warning delay P5_06 0.0~30.0s【5.0】 time The value of P5_04 determines the pre-warning threshold, 100% corresponds to the rated current of the integrated machine.
Page 105
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify P5_11 Braking threshold voltage 320~750【700】 in running The 220V integrated machine should be changed into 380V. 6.5.7 Parameters setting---communication setting 【main menu】...
Page 106
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify P6_00 Local communication address 1~247【1】 in running Function Instruction Setting range【default value】 Remarks code Communication baud rate modify P6_01 0~5【4】 selection in running This parameter is used to set the data transmission rate between the upper computer and the integrated machine.
Page 107
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify P6_04 Communication response delay 0~20ms【0】 in running Reply delay refers to the interval time between the end of data receiving of the machine and the reply data sending of the upper computer.
Page 108
User manual of EC160 elevator intelligent integrated machine Function parameters 0~255【168】 in running 0~255【5】 0~255【60】 Set Ethernet IP address. IP address: P6.09.P6.10.P6.11.P6.12 For example: IP address is 192.168.5.60 Function Instruction Setting range【default value】 Remarks code 0~255【255】 0~255【255】 Not modify P6_13~P6_16 Set the subnet mask 0~255【254】...
Page 109
User manual of EC160 elevator intelligent integrated machine Function parameters the group control board 10 running time displaying 11 rated power displaying 12 rated current displaying 6.5.9 Parameters setting---floor setting 【main menu】 【parameters setting 【A1 floor setting】 A system control inquiry】...
Page 110
User manual of EC160 elevator intelligent integrated machine Function parameters H4 front/rear door stopping floor L0 parallel and group control setting Function Instruction Setting range【default value】 Remarks code Collective selective control modify A1_00 0~2【0】 mode in running Select the calling control mode.
Page 111
User manual of EC160 elevator intelligent integrated machine Function parameters inquiry deceleration distance 5 floor displaying E password setting P2 motor parameters 6 floor displaying F system autotuning P3 encoder 7 floor displaying G data management parameters 8 floor displaying...
Page 112
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code A2_06 7 floor displaying 0~9090【1623】 A2_07 8 floor displaying 0~9090【1624】 A2_08 9 floor displaying 0~9090【1625】 A2_09 10 floor displaying 0~9090【1716】 A2_10 11 floor displaying 0~9090【1717】...
Page 113
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code A2_37 38 floor displaying 0~9090【1924】 A2_38 39 floor displaying 0~9090【1925】 A2_39 40 floor displaying 0~9090【2016】 A2_40 41 floor displaying 0~9090【2017】 A2_41 42 floor displaying 0~9090【2018】...
Page 114
User manual of EC160 elevator intelligent integrated machine Function parameters Setting value Displaying " & Setting value Displaying < > Setting value Displaying Setting value Displaying Setting value Displaying Setting value Floor displaying Corresponding table Displaying 6.5.11 Parameters setting---logic setting of I/O control board 【main menu】...
Page 115
User manual of EC160 elevator intelligent integrated machine Function parameters H3 rear door stopping floor H4 front/ rear door stopping floor L0 parallel and group control setting Logic setting 1 is the logic setting of the following signals: Terminal Medium...
Page 116
User manual of EC160 elevator intelligent integrated machine Function parameters set to be 0 and the NC to be 1. Write the convertering decimal result to logic 2. Above switches 9 and 10 are NC, and others are NO, which can be shown in binary 00000011, converted into decimal (1+2)=003.
Page 117
User manual of EC160 elevator intelligent integrated machine Function parameters The single logic setting of I/O board is the logic setting of each point on I/O board. It can be modified associated with logic setting 1-6: 【H0 IO I/O control 【input signal 1-32】...
Page 118
User manual of EC160 elevator intelligent integrated machine Function parameters A1 floor setting A2 floor displaying H0 logic of the IO control board H1 logic of the car control board H2 front door stopping floor H3 rear door stopping floor...
Page 119
User manual of EC160 elevator intelligent integrated machine Function parameters Terminal Closing Rear Rear Front/rear button Independent Definition door door door Beam for fire running closed open switching fighters NO/NC ○ ○ ○ ○ ○ ○ ○ ○ Binary Decimal 0×128...
Page 120
User manual of EC160 elevator intelligent integrated machine Function parameters F system autotuning comfortability 03 front door stopping G data management P5 elevator protection floor enabling 4 H system parameters 04 front door stopping information P6 communication floor enabling 5...
Page 121
User manual of EC160 elevator intelligent integrated machine Function parameters Set the front door stopping floor which is shown by binary numbers. 1: valid 0: invalid For example, if the elevator stops at 1, 3, 6, and 8 floor and does not stop at other floors, then H2_00=(1+4+32+128)=165.
Page 122
User manual of EC160 elevator intelligent integrated machine Function parameters closing/opening the front and rear doors simultaneously. 6.5.14 Parameters setting---rear door stopping floor 【main menu】 【parameters setting 【H3 rear door stopping A system control inquiry】 floor】 B fault record P0 master drive...
Page 123
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code H3_00 Rear door 1~8 floor 000~255【0】 H3_01 Rear door 9~16 floor 000~255【0】 H3_02 Rear door 17~24 floor 000~255【0】 H3_03 Rear door 25~32 floor 000~255【0】...
Page 124
User manual of EC160 elevator intelligent integrated machine Function parameters H1 logic of the car control board H2 front door stopping floor H3 rear door stopping floor H4 front/ rear door stopping floor L0 parallel and group control setting Function Instruction Setting range【default value】...
Page 125
User manual of EC160 elevator intelligent integrated machine Function parameters comfortability P5 elevator protection parameters P6 communication setting P7 drive information PE factory only A1 floor setting A2 floor displaying H0 logic of the IO control board H1 logic of the car...
Page 126
User manual of EC160 elevator intelligent integrated machine Function parameters elevator and pass the floors above the top floor of sub elevator without stop. When there is only down bias for parallel elevators, set the down bias to main elevator. Simultaneously, if there is up bias, set the top floor or above of lower floors to non-stop.
Page 127
User manual of EC160 elevator intelligent integrated machine Function parameters stopping floor 17 Entire running L0 parallel and group protection time control setting 18 Single floor running T0 time setting protection time F0 function setting U0 calling signal U1 system monitoring...
Page 128
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify T0_06 Starting shake prevention delay 0~5.000s【0.3】 in running T0_06 sets the time from lock connection to the running contactor output. Adjust the parameter when the door shakes when door closed.
Page 129
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify T0_10 Arrival gong delay 0~5.000s【0.000】 in running Set the time from the arrival gong output to canceling the arrival gong. Function Instruction Setting range【default value】...
Page 130
User manual of EC160 elevator intelligent integrated machine Function parameters The time from output brake to braking shifting. Function Instruction Setting range【default value】 Remarks code Not modify T0_16 Keeping time of opening delay 0~500.0s【30.0】 in running Press the opening delay button, and the system will close the door automatically after the set time.
Page 131
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify T0_20 Beam keeping failure time 0~65535s【0】 in running When the elevator stops after fast arrival at the door area and opens the door, after the continuous action time of the beam reaches the set value, the door can be closed manually.
Page 132
User manual of EC160 elevator intelligent integrated machine Function parameters floor 16 test mode H4 front/ rear door 17 relative selection of stopping floor CAN communication L0 parallel and group 18 relative selection of control setting elevator running T0 time setting...
Page 133
User manual of EC160 elevator intelligent integrated machine Function parameters If energy saving is necessary in the state, set the closed signal to normally closed attribute. Function Instruction Setting range【default value】 Remarks code Not modify F0_02 Closing output delay 0~600.0s【0.5】...
Page 134
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Floor opening mode of parallel modify F0_05 0~2【0】 outside calling in running 0: main and sub elevator opening at the same time 1: main elevator opening...
Page 135
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify F0_09 Dual door control mode 0~1【1】 in running 0: dual control box mode 1: single control box mode Set car logic to 3 when selecting dual control box mode. (Refer to the set value of car logic1.)
Page 136
User manual of EC160 elevator intelligent integrated machine Function parameters 4 medium speed up forced speed-changing 24 full load signal switch 5 no definition 25 overload signal 6 no definition 26 no definition 7 down limit 27 no definition 8 up limit...
Page 137
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify F0_16 Test mode 0~65535【0】 in running 0: no operation 1: allow communication reset at drive fault 8: close at fast arrival and shield calling (generally for debugging or test mode)
Page 138
User manual of EC160 elevator intelligent integrated machine Function parameters board after adjustment. The MF output in the car and car weighing compensation are cancelled. The parameter will not involve in default value reset. Function Instruction Setting range【default value】 Remarks...
Page 139
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code modify F0_20 Filter coefficient of stop curve 0~65535【0】 in running 0: disable Valid range 1~255 (generally unnecessary to set the value, modifiable when the elevator shakes...
Page 140
User manual of EC160 elevator intelligent integrated machine Function parameters Function Instruction Setting range【default value】 Remarks code Not modify F0_23 MF definition of DS 0~65535【0】 in running 0: original definition 1: opening keeping delay button 2: front/rear door selection 3: car firefighter input...
Page 141
User manual of EC160 elevator intelligent integrated machine Function parameters Stop time 2 of time sharing F0_33 0~2359【0】 service Time 2 of time sharing service F0_34 0~65535【0】 Stop at 1~16 floors Time 2 of time sharing service F0_35 0~65535【0】 Stop at 17~32 floors...
Page 142
User manual of EC160 elevator intelligent integrated machine Function parameters After enabling the communication IC card (in F0_18, bit3=1), open up 1~64 floor of front door by F0_57~F0_60. The set floor will record internal command without using IC card. For example, in a shopping mall, parking is under the 1st floor, home landing on the 1st floor, stores on 2~5 floors, restaurants on the 12th floor, and other floors are private.
Page 143
User manual of EC160 elevator intelligent integrated machine Function parameters 0 original definition of front/rear door output 11 low speed signal 1 output contactor control 1 12 UPS control 2 star-delta output 13 elevator lock return 3 brake contactor control 1...
Page 144
User manual of EC160 elevator intelligent integrated machine Function parameters A1 floor setting A2 floor displaying H0 logic of the IO control board H1 logic of the car control board H2 front door stopping floor H3 rear door stopping floor...
Page 145
User manual of EC160 elevator intelligent integrated machine Function parameters P7 drive information C-phase sampling PE factory only D-phase sampling A1 floor setting Current height of the A2 floor displaying elevator H0 logic of the IO Current floor of the...
Page 146
User manual of EC160 elevator intelligent integrated machine Function parameters 6.5.21 Parameters setting---hoistway information The parameters are used to check the floor height and installation distance of the deceleration switch after the elevator autotuning. 【parameters setting 【main menu】 【U2 hoistway inquiry】...
Page 147
User manual of EC160 elevator intelligent integrated machine Function parameters 6.6 Password setting 【main menu】 【password setting】 A system control (1) monitoring password B fault record (2) debugging password C language selection (3) factory password D parameters setting inquiry E password setting...
Page 148
User manual of EC160 elevator intelligent integrated machine Function parameters G data management to PAD H system information [5] PAD data to the controller [1] Data saving of the controller: save the data before powering off after changing, if not, invalid.
Page 149
User manual of EC160 elevator intelligent integrated machine Running at slow speed Chapter 7 Running at slow speed 7.1 Inspection before power on 7.1.1 Machinery assembly, inspection and confirmation Bracket, rail, traction machine, car, rope, control cabinet and governor are installed according to the standards.
Page 150
User manual of EC160 elevator intelligent integrated machine Running at slow speed Check the grounding (1) In the following inspection, the resistor between the measuring terminal/parts and PE closes to infinity. Between R, S, T and PE Between the braking coil and PE...
Page 151
User manual of EC160 elevator intelligent integrated machine Running at slow speed (2) The connection of the encoder is brought into the control cabinet. (3) If the connection cable is not long enough, it is necessary to lengthen the cables and the cables should be shield cables.
Page 152
User manual of EC160 elevator intelligent integrated machine Running at slow speed checking the parameters, set according to the actual debugging. 7.3 Static self-tuning of the synchronous motor Autotuning is needed before the first slow running of synchronous master, otherwise damage to the machine and motor and physical injury or death may occur.
Page 153
User manual of EC160 elevator intelligent integrated machine Running at slow speed C language selection control encoder D parameters setting P1 speed and 02 encoder direction inquiry deceleration distance 03 low-speed encoder E password setting P2 motor parameters disconnection detection...
Page 154
User manual of EC160 elevator intelligent integrated machine Running at slow speed Function Name Instruction code motor 0: Incremental encoder (AM) 1: SIN/COS encoder (synchronous 1387) P3_00 Encoder type 2: UVW encoder (synchronous 8192) 3: Endat encoder (synchronous 1313) Resolution of the...
Page 155
User manual of EC160 elevator intelligent integrated machine Running at slow speed 3. Enter into the static identification current menu, set P3_10 and enter into the main menu-F system autotuning-[3] motor static autotuning. Then the operational interface of the manual controller will display “please confirm the inspection state?”.
Page 156
User manual of EC160 elevator intelligent integrated machine Running at slow speed Select [Yes] and enter: 【motor static autotuning】 Whether begin the motor autotuning? Select [Yes] and enter, and press the up inspection button: 【motor static autotuning】 Motor autotuning… If succeeded, then 【motor static autotuning】...
Page 157
User manual of EC160 elevator intelligent integrated machine Running at slow speed Function Name Instruction code P2_05 Rated current of the motor Depend on the name plate 0: Incremental encoder (AM) 1: SIN/COS encoder (synchronous 1387) P3_00 Encoder type 2: UVW encoder (synchronous 8192)
Page 158
User manual of EC160 elevator intelligent integrated machine Running at slow speed about 30s, the motor will finish autotuning and the running contactor releases automatically. 6. If the master autotuning succeeds, the manual controller will display “autotuning succeeded”. Press ESC to retreat the interface, and then enter main menu-G data management-[1]data saving interface of controller to save the data.
Page 159
User manual of EC160 elevator intelligent integrated machine Running at slow speed If failed, then 【motor rotating autotuning】 Autotuning failed Save the parameters after autotuning. The autotuning of asynchronous motor is the same as above. After finishing autotuning, update P2_06~P2_10.
Page 160
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed Chapter 8 Debugging at fast speed 8.1 Inspection and confirmation of the electrical assembly The connections of the engine room and beam are correct. The connection and installation size of the leveling switch on the car top are correct.
Page 161
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed inspection/automatic switch in the inspection position. (4) Ensure the voltage between the power terminal of the door operator is 220V±7%VAC. (5) Debug according to the instruction of the door operator.
Page 162
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed (2) The elevator runs up to the up terminal forced deceleration switch acts, then the sill of the car is below the sill of he hall about X (refer to 4.5.2).
Page 163
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed Select [Y] to enter Select [Y] to enter Select [Y] to enter 【hoistway information 【hoistway information 【hoistway information autotuning】 autotuning】 autotuning】 Please ensure the Please ensure to begin...
Page 164
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed The high speed counting is in reverse direction. When the elevator goes up, the current height reduces. Please make adjustment according to the precautions of the master in autotuning;...
Page 165
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed state. 5. After proper multi-deck running, make the elevator run at multi-deck speed to the top and bottom to check whether in normal state. 6. After proper top/bottom running, check the up forced deceleration switch distance and down forced deceleration switch distance meet the requirements, and no top-hitting or bottom-clashing;...
Page 166
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed 8.9 Comfortability 8.9.1 Vector control of the sequence in fast-running Fig 8-2 Sequence diagram...
Page 167
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed 8.9.2 Adjustment of non-weighing compensation starting Set P4_14 to be 1, in the time set by P4_15, P4_17, P4_18, P4_19, P4_20 and P4_21 are valid. P4_16 is the transition time from speed loop zero speed (load compensation) to the low speed.
Page 168
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed 8.9.5 Motor noise Check and adjust P0_07 (6kHz), P4_08, P4_09 and P4_10 if the motor has noise in running. When the asynchronous motor is running, increase slip corresponding to load direction properly if output voltage cause master noise.
Page 169
When OL voltage>FL voltage>LL voltage, set F0_17 bit1 to 1, that is, +2 on the original parameter. If the OL and FL signals of the elevator adopt analog weighing voltage of car top board, EC160 autotuning at LL, FL and OL in sequence will be needed, as shown below: 1.
Page 170
User manual of EC160 elevator intelligent integrated machine Debugging at fast speed autotuning? Load 08.2V After the autotuning succeeded, set P4_25, P4_26 and P4_27 to start compensation adjustment. Set P4_25 to the analog voltage when the load of the elevator is balanced. For example, when the load of the elevator is balanced, the analog voltage in drive monitoring is 4V and thus the value need to be 40.0%;...
Page 171
Chapter 9 Complete product description 9.1 Instruction of EC-CTB EC-CTB is the main control board of EC160, including 9 digital signal inputs, 1 analog voltage signal input, 5 relay normally-open signal outputs and 1 relay normally-open/closed signal output. It also has 2 digital signal I/O terminals to communicate with EC-CCB, the terminals to carry on CAN communication for EC160 and the displaying board in car, and RS485 communication with upper computer.
Page 172
User manual of EC160 elevator intelligent integrated machine Complete product description 9.1.2 Interface definition Serial Code Terminal definition 4-core terminal Download port of J-link CANH1, CANL1, 24-, 24+ CAN communication interface CANH2, CANL2, 24-, 24+ CAN communication interface 24V+, 24V-, B, A...
Page 173
9.2 Instruction of EC-CCB EC-CCB is the auxiliary command board in the controller of EC160. Each board has 24 input and 22 output terminals, including 16 floor buttons and 8 function signals. It is mainly used for the signal collection and output of buttons and lights.
Page 174
User manual of EC160 elevator intelligent integrated machine Complete product description 9.2.1 Installation dimension Figure 9-2 Installation dimension 9.2.2 Interface definition Serial Code Terminal definition Remarks DB9 (male) CH1 connects the car top board CH2 connects the internal command DB9 (female)
Page 175
User manual of EC160 elevator intelligent integrated machine Complete product description Serial Code Terminal definition Remarks V+, K, V+, L- Button input of floor 8 to the input of (16+n) button Button input of floor 9 V+, K, V+, L-...
Page 176
User manual of EC160 elevator intelligent integrated machine Complete product description 9.2.3 Car command button and connection of the indicators Figure 9-3 Car command button and connection of the indicators 9.2.4 Car open button and connection of the indicators Figure 9-4 Car open button and connection of the indicators 9.2.5 Car close button and connection of the indicators...
Page 177
User manual of EC160 elevator intelligent integrated machine Complete product description 9.3 Instruction of DC-03F DC-03F is one of the important interfaces for the interaction between the passengers and the control system. The displaying board can receive the calling and display the current floor and the running direction of the elevator.
Page 178
User manual of EC160 elevator intelligent integrated machine Complete product description interference. Connect as the designated as tight as enough. 9.3.2 Interface definition Serial Function Code Terminal definition Power input and RS485 communication A, B, GND, 24+ bus interface LU, V+, V+, UP-...
Page 179
User manual of EC160 elevator intelligent integrated machine Complete product description 9.3.3 Terminal connection of DC-03F Figure 9-7 Switch connection of the calling displaying board 9.3.4 Parameters setting of DC-03F 9.3.4.1 Table of parameters Code Definition Default value Address of the displaying board, range: 0~64...
Page 180
User manual of EC160 elevator intelligent integrated machine Complete product description Data (X stands for : 0 or 1) Definition Lock enabling, the lock signal act when the 0 position is 1 Fire enabling, the fire signal act when the 0 position...
Page 181
User manual of EC160 elevator intelligent integrated machine Complete product description Displaying in the car Station prediction: no Display floor number and leveling mark when inspection in normal special characters or Inspection leveling; displaying displaying other mode Display floor number...
Page 182
User manual of EC160 elevator intelligent integrated machine Complete product description normal special characters 1[F], 2/3 normal Independent displaying displaying or other mode displaying normal special characters Fire Optional displaying displaying or other mode Safety normal special characters circuit off...
Page 183
The elevator is locked. 9.4 Instruction of MC-GCL The group control board MC-GCL and elevator intelligent integrated EC160 make up the distributed control system DCS. By CAN communication, collect internal/external calling recording signals of each elevator. After intelligent processing, allocate the information to corresponding elevator to control 8~64 elevators under high efficiency.
Page 184
User manual of EC160 elevator intelligent integrated machine Complete product description priority. 4. Timing down in rush hour: in the set time, all elevators provide service according to down calling priority. 5. Timing zoning running: in the set time, the specified elevators will only stop at allocated floors and prompt passengers by sound and light according to setting, achieving high speed, efficiency and reducing stop as much as possible.
Page 185
User manual of EC160 elevator intelligent integrated machine Complete product description Name Function Qty. Position MC-GCL For group control One for each elevator In control cabinet 9.4.3 Specification of the connectors Serial No. Model CAN1, CAN2, P2 2EHDRC-4P 2EHDRC-5P J1, J2, J3 SIP2 (pin 2.54mm)
Page 186
User manual of EC160 elevator intelligent integrated machine Complete product description 9.4.4.5 Working environment Temperature 0°~70° Humidity <95% Salt fog 0.13ug/m3 Shock Peak acceleration speed 100gn, 100 times Vibration 10Hz-100Hz 50 times 100Hz-10Hz 50 times Sudden pulse group interference 2.5kV 9.4.5 Definition of the input/output interface...
Page 187
User manual of EC160 elevator intelligent integrated machine Complete product description Output Grounding terminal of CAN2 Not grounded generally Output Not connected 9.4.5.3 Definition of I/O terminal Serial Corresponding Definition 1, 2, 3 and 4 pins input Input — common terminal...
Page 188
9.4.8 Diagram of communication interface No.n elevator No.2 elevator No.1 elevator Figure 9-9 Diagram of GCL CAN communication interface Precautions for wiring and debugging: 1. CL1 and CH1 of MC-GCL should be connected to GPRL and GPRH of EC160 in No.1 elevator,...
Page 189
4. Short circuit all J2 of MC-GCL; short circuit J3 between No.1 and No. n elevator while disconnect J3 pins in other elevators; 5. No.1 elevator: MC-GCL is connected to EC160 (group number L0=3), No.2 elevator: MC-GCL is connected to EC160 (group number L0=4), and so on…No.8 elevator: MC-GCL is connected to EC160 (group number L0=10).
Page 190
User manual of EC160 elevator intelligent integrated machine Complete product description The monitoring password can only enter into A, B and H in the main menu and they are only for read. After inputting the monitoring password, pressing ESC can shift into the password debugging or factory password input mode.
Page 191
User manual of EC160 elevator intelligent integrated machine Complete product description Serial No. Meaning Elevator state: automatic, inspection and group control Current floor and running speed Current mode The highlight is the number involved in group control dispatch Monitor recorded car command...
Page 192
User manual of EC160 elevator intelligent integrated machine Complete product description F system autotuning P3 running mode G data management setting H system information Function Setting range【default Description Remarks code value】 P0_00 Year 2000~2099【2010】 Bottom floor by default P0_01 Month and day 01.01~12.31【01.01】...
Page 193
User manual of EC160 elevator intelligent integrated machine Complete product description Standby floor in rush hour up; separate standby-elevator A returns to standby floor (P2_03=0, the function is invalid) Default floor is in the P1_01 Home landing in middle 00~64【00】...
Page 194
User manual of EC160 elevator intelligent integrated machine Complete product description G data management setting 04 T4 H system information 05 T5 Function Setting range【default Description Remarks code value】 P2_00 Idle time threshold 000.0~600.0【20】s Note: when the elevator cannot run and timeout, exit group control time.
Page 195
User manual of EC160 elevator intelligent integrated machine Complete product description 05 auto rush hour mode enabling 06 threshold of auto rush hour 07 running time of auto rush hour 08 reserved 09 zoning mode 1 enabling 10 zoning mode 1 start...
Page 196
User manual of EC160 elevator intelligent integrated machine Complete product description 34 F34 35 F35 Function Description Setting range【default value】 Remarks code Timing rush hour mode P3_00 000~127【0】 enabling Start time of up rush P3_01 00.00~23.59【00.00】 hour P3_02 End time of up rush hour 00.00~23.59【00.00】...
Page 197
User manual of EC160 elevator intelligent integrated machine Complete product description P3_18 Zoning mode 2 end time 00.00~23.59【00.00】 P3_19 Mode 2 floor setting-16 00000~65535【00000】 P3_20 Mode 2 floor setting-32 00000~65535【00000】 P3_21 Mode 2 floor setting-48 00000~65535【00000】 P3_22 Mode 2 floor setting-64 00000~65535【00000】...
Page 198
User manual of EC160 elevator intelligent integrated machine Complete product description value D parameters setting [3] fault history inquiry clearance E password setting [4] data of the controller F system autotuning to PAD G data management [5] PAD data to the...
Page 199
User manual of EC160 elevator intelligent integrated machine Complete product description Note: Elevator A 10 floors above ground and 2 floors underground; elevator B 10 floors above ground and 1 floor underground; elevator C 11 floors above ground and no floor underground.
Page 200
User manual of EC160 elevator intelligent integrated machine Complete product description Installation method: 1. Install when all power supplies are disconnected. 2. Fix with screws according to the installation holes. 3. Connect the terminals and tighten up. 9.5.2 Configuration Name Function Qty.
Page 201
User manual of EC160 elevator intelligent integrated machine Complete product description Serial No. Terminal code Terminal definition Remarks 24V- DC0V input terminal 9.5.5.2 Definition of P2 and P3 P2: detection input signal P3: output signal of short circuit lock circuit Serial No.
Page 202
User manual of EC160 elevator intelligent integrated machine Complete product description 9.5.7 Wiring diagram of EC-RDB and peripheral interface Figure 9-13 Wiring diagram of EC-RDB and peripheral interface...
Page 203
User manual of EC160 elevator intelligent integrated machine Maintenance and hardware diagnosis Chapter 10 Maintenance and hardware diagnosis 10.1 Maintenance intervals If installed in an appropriate environment, the inverter requires very little maintenance. The table lists the routine maintenance intervals recommended by INVT.
Page 204
User manual of EC160 elevator intelligent integrated machine Maintenance and hardware diagnosis Checking Item Method Criterion that there is something wrong with the features. Ensure that there is no distortion or color-changing Visual of the conductors caused examination The lead of the by overheating.
Page 205
User manual of EC160 elevator intelligent integrated machine Maintenance and hardware diagnosis Checking Item Method Criterion measure with multimeter Ensure there is no Hearing, smelling Transformers and abnormal vibration, noise and visual reactors and smelling. examination Ensure whether there is...
Page 206
User manual of EC160 elevator intelligent integrated machine Maintenance and hardware diagnosis Checking Item Method Criterion Visual examination or Ensure there is no estimate the color-changing caused by usage time overheating. according to the maintenance information Check whether there is...
Page 207
User manual of EC160 elevator intelligent integrated machine Maintenance and hardware diagnosis Time Operational principle Storing time less than 1 year Operation without charging Storing time 1-2 years Connect with the power for 1 hour before first ON command Use power surge to charge for the inverter •...
Page 208
Change electrolytic capacitors if the working hours of electrolytic capacitors in the inverter are above 35000. Please contact with the local INVT offices or dial our national service hotline (400-700-9997) for detailed operation. 10.4 Power cable Read and follow the instructions in chapter Safety Precautions.
Page 209
User manual of EC160 elevator intelligent integrated machine Fault code Chapter 11 Fault code Fault Fault code Fault code of Fault reason Solution Method of LED instruction controller Main control Replace the main Stop Internal fault board fault control board immediately 1.Check the cable...
Page 210
User manual of EC160 elevator intelligent integrated machine Fault code 1.Check the communication communication cable circuit and plug-ins. communication Preferred 2.Check the power overtime stopping, communica- supply (DC24V). between the fault reset tion fault 3.Check the main controller automatically communication...
Page 211
User manual of EC160 elevator intelligent integrated machine Fault code 2.After the misaction of the opening signal switch output for 5s, the 3.Check the door lock still does not operator disconnect Elevator Do not stop protection Analyze with other at the door...
Page 212
User manual of EC160 elevator intelligent integrated machine Fault code time same time logic setting 1.Check the corresponding The main board Earthquake logic setting detects the Function tips action 2.Corresponding earthquake detection point damage The running 1.Check the speed Stop...
Page 213
User manual of EC160 elevator intelligent integrated machine Fault code logic setting 1.Replace the contactor Overtime of Feedback after Stop 2.Check the the running the running immediately; external wiring contactor contactor fault reset 3.Check the opening releasing automatically corresponding logic setting 1.Replace the...
Page 214
User manual of EC160 elevator intelligent integrated machine Fault code 4.Check the corresponding logic setting 5. Check the definition of MF input 1.The brake does not close 1.Adjust the totally when the position elevator stops 2.Adjust braking 2.The brake Stop...
Page 215
User manual of EC160 elevator intelligent integrated machine Fault code 1.Check the No detection of connection cables Stop Hardware the signal after of the IO board immediately; enabling the elevator 2.Check the fault reset adhesion starts contactor and automatically connection 1.Detection of...
Page 216
User manual of EC160 elevator intelligent integrated machine Fault code time logic setting 1.Human obstruction 2.Detection point Safety touch Safety touch damage, pad/beam pad/continuous disconnection or Fault tips action action of beam short circuit overtime overtime 3.Check the corresponding logic setting 1.Check the...
Page 217
User manual of EC160 elevator intelligent integrated machine Fault code DOWN low and medium speed 1.Switch damage forced DOWN low or disconnection Preferred deceleration speed forced 2.Check the leveling; fault switches do not DEC switch speed or reset reset when the...
Page 218
User manual of EC160 elevator intelligent integrated machine Fault code Up forced deceleration switch faulty action when the Emergency Forced DEC elevator goes up; deceleration to Switch damage or switch faulty down forced leveling; fault disconnection action deceleration reset switch faulty...
Page 219
User manual of EC160 elevator intelligent integrated machine Fault code the elevator is in logic setting the terminal 5.The position of station the forced 3.Information deceleration loss of the switch changed hoistway after hoistway 4.Floor error autotuning Contactor No. 50, 51, 52,...
Page 220
User manual of EC160 elevator intelligent integrated machine Fault code of the tractor filter 3.Internal 3.Contact with the Inverter unit damage to IGBT manufacturer W phase 4.Internal 4.Check the protection connection of the internal problems controller is such as loose connection 1.Check the...
Page 221
User manual of EC160 elevator intelligent integrated machine Fault code braking unit braking resistor Constant 4. ACC/DEC 5.Adjust S curve speed over curve is too swift voltage 1.Check the external power supply and 1.Sudden power whether the power is off when the...
Page 222
User manual of EC160 elevator intelligent integrated machine Fault code 5.Check the power cable of the master 1.Set through the parameters 2.Check the 3 1.Asymmetrical Stop phase power Phase loss input power immediately; supply in input in input side 2.Abnormal drive...
Page 223
User manual of EC160 elevator intelligent integrated machine Fault code Check the communica- Fault tips parameters setting tion fault 1.Bad connection of the 1.Check the cable control board of the main board 2.Auxiliary power and the drive Stop Current damage board immediately;...
Page 224
User manual of EC160 elevator intelligent integrated machine Fault code speed setting 1.Serious sliding 1.Signal wires 2.Change the Stop reverse Encoder direction of the immediately; 2.Too short time reversion encoder and fault reset for reverse reautotuning of automatically detection the master...
Page 225
User manual of EC160 elevator intelligent integrated machine Fault code enabling contact of the contact of the signal running contactor contactor 1.Damage to the motor wires, Motor short Stop contact with the 1.Check the motor circuit to the immediately; shell...
Need help?
Do you have a question about the EC160 and is the answer not in the manual?
Questions and answers
