Summary of Contents for Samsung AVXTJH028EE
- Page 1 AVXTJ£ª£ª_IB IM_E_29814.indd 1 2009-3-10 16:47:06...
-
Page 2: Air Conditioner
features of your new air conditioner • Slim & Smart Design Extremely slim and compact design will allow this air conditioner to fit in any kind of interior space. • function generates hydrogen(H) and oxygen(O such as bacteria, pollen, and odor. It makes you breathe better as if you were staying around waterfalls, ocean surf, rivers and mountains. -
Page 3: Safety Information
Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. If you have questions, call your nearest contact center or find help and information online at www.samsung.com. What the icons and signs in this user manual mean:... - Page 4 safety information SEVERE WARNING SIGNS If any gas or impurities other than R410A refrigerant come into the refrigerant pipe, serious problem may occur and it may cause injury. Do not spray flammable gases such as insecticide near the air conditioner. •...
- Page 5 Install the supplied cables firmly. Fix them securely so that external force is not exerted to the terminal block. • If the connection is loose, heat may generate and cause electric shock or fire. Use a rated circuit breaker only. •...
- Page 6 safety information CAUTION SIGNS Do not expose the dust filter to direct sunlight while drying. • Strong direct sunlight may deform the dust filter. Do not allow children to climb on the air conditioner. Use only rated accessories and install the air conditioner with rated equipments. •...
- Page 7 Check for damage on delivery. If damaged, do not install the air conditioner and call the place of purchase immediately. Insert the dust filter before operating the air conditioner. • If there is no dust filter inside the air conditioner, accumulated dust may shorten the life of the air conditioner and cause electricity waste.
- Page 8 safety information CAUTION SIGNS Make sure the voltage and frequency of the electric system are compatible with the air conditioner. If a power outage occurs while the air conditioner is working, turn off the power source immediately. Max current is measured according to IEC standard for safety and current is measured according to ISO standard for energy efficiency.
-
Page 9: Table Of Contents
contents VIEWING YOUR AIR CONDITIONER OPERATING BASIC FUNCTION USING ADVANCED FUNCTION CLEANING AND MAINTAINING THE AIR INSTALLING YOUR AIR CONDITIONER This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC), and the Electromagnetic Compatibility Directive (2004/108/EEC) of the European Union. (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. -
Page 10: Checking The Indoor Unit
viewing your air conditioner before use Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool or warm with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner. CHECKING THE INDOOR UNIT Carefully unpack your air conditioner, and check the unit to make sure it is not damaged. -
Page 11: Removing The Front Panel
REMOVING THE FRONT PANEL Grab the top portion of the front panel and pull the front cover towards yourself. Unhook the safety string and lift up the front panel. Viewing the power button and parts under the panel You may locate the Power button among with the mode indicators. When the front panel is open, you may locate the temperature sensor and the Air flow switch. -
Page 12: Checking The Remote Control
viewing your air conditioner before use CHECKING THE REMOTE CONTROL You can activate the air conditioner by pointing the remote control away from it. When using the remote control, always point it directly at the air conditioner. Remote control display Power Turn on/off the air conditioner, Mode... -
Page 13: Remote Control Display
Remote control display On Timer indicator Off Timer indicator Fan speed indicator Auto Medium High indicator Using the remote control • Point the remote control towards the remote control sensor of the unit. • When properly pressing the button on the remote control, you will hear beep sound from the unit. -
Page 14: Turning The Air Conditioner On And Off
operating basic function TURNING THE AIR CONDITIONER ON AND OFF Press the Power button on the remote control. You will hear a ringing sound and the air flow blade will move up and down automatically when air conditioner is properly on. The air conditioner will operate in the most recent operation mode used or Auto mode. -
Page 15: Cool
Cool In Cool mode, the air conditioner will cool your room. You can adjust the temperature and the fan speed to feel cooler in hot season. 1. Turn on the air conditioner. Press the Power 2. Set the operating mode. Press the Mode button on the remote control until Cool mode indicator appears on the remote control display. -
Page 16: Dry
operating basic function SELECTING OPERATION MODE The air conditioner in Dry mode acts like a dehumidifier by removing moisture from the indoor air. Dry mode makes the air feel refreshing in a humid climate. 1. Turn on the air conditioner. Press the Power 2. -
Page 17: Fan
Fan mode can be selected to ventilate your room. Fan mode will be helpful to refresh the stale air in your room. 1. Turn on the air conditioner. Press the Power 2. Set the operating mode. Press the Mode button on the remote control until Fan mode indicator appears on the remote control display. -
Page 18: Heat
operating basic function SELECTING OPERATION MODE Heat The air conditioner heats as well as cools. Warm your room with this versatile appliance in the cold of winter. 1. Turn on the air conditioner. Press the Power 2. Set the operating mode. Press the Mode button on the remote control until Heat mode indicator appears on the remote control display. -
Page 19: Adjusting The Air Flow Direction
ADJUSTING THE AIR FLOW DIRECTION Air flow can be directed to your desired position. Vertical air flow Air flow blades move up and down. 1. Press the Air swing Air swing indicator will be on and the number of indicator lights move up and down. Air flow blades move up and down continuously to circulate the air. -
Page 20: Setting The Timer
using advanced functions SETTING THE TIMER This advanced Timer function allows you to turn on/off your air conditioner automatically even when you are away. Simply set the time and your air conditioner will turn on/off automatically. On timer This function allows you to turn on the air conditioner automatically within the time range of 24 hours. -
Page 21: Off Timer
To deactivate the On timer 1. Press the Set/Cancel button on the remote control. On timer you set will be canceled and On timer indicator will disappear. Off timer This function allows you to turn off the air conditioner automatically within the time range of 24 hours. -
Page 22: Combining On Timer And Off Timer
using advanced functions SETTING THE TIMER Combining On timer and Off timer You can combine the On timer and Off timer together for more convenient use of the timer function. 1. Set the On timer. Press the On Timer button. Set the time with Time or ... -
Page 23: Using The Function
USING THE FUNCTION , Micro Plasma Ion, generates hydrogen(H) and oxygen(O decomposition of such harmful particles. It makes you breathe better as if you were staying around waterfalls, ocean surf, rivers and mountains. 1. Press the indicator will appears on the remote control display and the air conditioner generates MPI. -
Page 24: Cleaning The Exterior
cleaning and maintaining the air conditioner CLEANING THE EXTERIOR 1. Wipe the surface of the unit with a slightly wet or dry cloth when needed. Do not use Benzene, Thinner or Clorox They may damage the surface of the air conditioner and can create a CAUTION risk of fire. -
Page 25: Anti-Allergy Filter
Anti-allergy filter Washable Anti-allergy filter leads to reduction in allergens that thrive in polluted air. The filter is cleaned with a vacuum or by hand washing. 1. Open the front panel. Grab the top portion of the front panel and pull the front cover towards yourself. -
Page 26: Replacing The Filter
cleaning and maintaining the air conditioner REPLACING THE FILTER Replacement filter may be purchased from the retail store or ordered from the dealer where you purchased the unit. If you cannot find one, please call a contact center. Deodorizing filter Deodorizing filter absorbs efficiently cigarette smoke, pet odors and other unpleasant smells. -
Page 27: Maintaining Your Air Conditioner
MAINTAINING YOUR AIR CONDITIONER If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug. -
Page 28: Internal Protections Via The Unit Control System
cleaning and maintaining the air conditioner MAINTAINING YOUR AIR CONDITIONER Internal protections via the unit control system This internal protection operates if an internal fault occurs in the air conditioner. Type Against cold air De-ice cycle Anti-protection of internal battery Protect compressor If the heat pump is operating in Heat mode, De-ice cycle is actuated to remove frost from an outdoor unit that may have deposited at low temperatures. -
Page 29: Troubleshooting
appendix TROUBLESHOOTING Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM The air conditioner does not operate immediately after it has been restarted. The air conditioner does not work at all. The temperature does not change. -
Page 30: Operation Ranges
appendix OPERATION RANGES The table below indicates the temperature and humidity ranges the air conditioner can be operated within. Refer to the table for efficient use. OPERATIONAL TEMPERATURE MODE INDOOR COOLING 18˚C to 32˚C HEATING 27˚C or less DRYING 18˚C to 32˚C The standardized temperature for heating is 7˚C. -
Page 31: Installation Part
Installation Part Indoor Unit Installation It is recommended to install the Y-joint before installing the indoor unit. When you install the indoor with side-pipe connection, please make space more than 300mm from the wall. When you install the indoor at the inclined floor, please lean the set toward the drain hose and pipe connection to prevent water overflowing. -
Page 32: Drain Hose Installation
Insulation Once you have checked that there are no leaks in the system, you can insulate the piping and hose. To avoid condensation problems, place T13.0 or thicker Acrylonitrile Butadien Rubber separately around each refrigerant pipe. Note Always make the seam of pipes face upwards. No gap NBR(T13.0 or thicker) Wind insulating tape around the pipes and drain hose... -
Page 33: Wiring Work
Drain hose installation If necessary, connect the 2 meter extension drain hose to the drain hose. Shield Drain hose Extension drain hose (No default resource) If you use the extension drain hose, insulate the inside of the extension drain hose with a shield. Fit the drain hose into 1 of 2 drain hose holes, then fix the end of the drain hose tightly with a clamp. -
Page 34: Indoor Unit Setting
Indoor Unit Setting Before installing the indoor unit, assign an address to the indoor unit according to the air conditioning system plan. The address of the indoor unit is assigned by adjusting MAIN(SW01, SW02) and RMC(SW03, SW04) rotary switches. SW01 SW02 SW03 SW04... - Page 35 memo _35 AVXTJ£ª£ª_IB IM_E_29814.indd 35 2009-3-10 16:48:45...
- Page 36 0900-SAMSUNG (0900-7267864) (€ 0,10/Min) 3 - SAMSUNG(7267864) 0 801 1SAMSUNG(172678) 022-607-93-33 80820-SAMSUNG(726-7864) 0800-SAMSUNG(726-7864) 902 - 1 - SAMSUNG (902 172 678) 075 - SAMSUNG(726 78 64) 0845 SAMSUNG (7267864) 0818 717 100 0810 - SAMSUNG(7267864, € 0.07/min) 0848 - SAMSUNG(7267864, CHF 0.08/min)
-
Page 37: User Manual
Console Type Series Floor : AVXTJ Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register AVXTJ｣ｪ｣ｪ_IB IM_E_29814.indd 2009-05-08 ｿﾀﾀ・10:18:38...
