Alliance Laundry Systems FCIX50200UE Original Instructions Manual

Alliance Laundry Systems FCIX50200UE Original Instructions Manual

Cylinder ironers, 500 mm diameter with integrated feeding and length folding
Hide thumbs
Table of Contents

Advertisement

Quick Links

Cylinder Ironers
500 mm Diameter with Integrated Feeding and Length
Folding
Refer to Page 4 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. D1607ENR1
www.alliancelaundry.com
July 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCIX50200UE and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems FCIX50200UE

Summary of Contents for Alliance Laundry Systems FCIX50200UE

  • Page 1 Cylinder Ironers 500 mm Diameter with Integrated Feeding and Length Folding Refer to Page 4 for Model Identification Original Instructions Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. D1607ENR1 www.alliancelaundry.com July 2016...

  • Page 3: Table Of Contents

    Original Factory Setting................15 © Copyright 2016, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.

  • Page 4: Model Identification

    FCUZ50260UE FCSZ50260UE FCIZ50260UG FCUZ50260UG FCSZ50260UG FCIZ50260UL FCUZ50260UL FCSZ50260UL FCIZ50260US FCUZ50260US FCSZ50260US FCIZ50320UE FCUZ50320UE FCSZ50320UE FCIZ50320UG FCUZ50320UG FCSZ50320UG FCIZ50320UL FCUZ50320UL FCSZ50320UL FCIZ50320US FCUZ50320US FCSZ50320US Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...
  • Page 5 FCPX50320UE FCPZ50320UE FCPX50200UG FCPX50320UG FCPZ50320UG FCPX50200UL FCPX50320UL FCPZ50320UL FCPX50200US FCPX50320US FCPZ50320US FCPX50260UE FCPZ50260UE IFF50-200 FCPX50260UG FCPZ50260UG IFF50-250 FCPX50260UL FCPZ50260UL IFF50-320 FCPX50260US FCPZ50260US LSREP5020 LSREP5025 LSREP5032 © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 6: Warnings And Symbols

    Switch off the machine only by “A“ key. Refer to Figure 6 . Otherwise, you risk losing certain factory settings or your wash programs from the machine memory. © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 7: Programming

    The fold length is, in this case, automat- • „front“ front linen exit ically calculated by programmed length of linen. • „no folding“ ironing without folding • „5.2m/min“ is ironing speed © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 8: Operation Modes Of The Cross Folder

    • „NS:3/10“ is number of normal cross folds/quantity of linen always folded in half of its length, refer to Figure 4 . in the stack © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 9: Stacker

    When pressing the " E " key after the previous "Change The Ac- • „NS:3/10“ is number of normal cross folds/quantity of linen tive Language (Y/N):", the display will have a question: in the stack (10 pieces) © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...
  • Page 10 " P " key. eters 4 and 5 will be skipped. © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...
  • Page 11 Programming Diagram of Control System Programming Mode Diagram Figure 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 12: A New Program Form

    OF FOLD / NUMBER TY OF PRO- NUMBER TYPE OF LINEN IN GRAM TEMPE- IRONING LENGTH CROSS CROSS NUMBER RATURE SPEED FOLDS OF LINEN FOLDS FOLD STACK © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 13: Factory Setting

    Suitable time period is 250-400 ms, which is dis- B With correction played as value 25-40. 3. Setting first fold: Figure 8 [Input: pulses ] Table distance: © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...
  • Page 14 The longer the time period, fewer stacks can be on the conveyer and vice versa. Figure 10 © Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...

  • Page 15: Original Factory Setting

    2nd fold (2 only): ........Time of the stacker conveyer running Conveyor time: ........Modem settings: 57600 / 8 / N / 1 ......PCCSW: ......© Copyright, Alliance Laundry Systems LLC - Part No. D1607ENR1 DO NOT COPY or TRANSMIT...
