Handle protection set for moto guzzi v85 tt

Advertisement

Griffschutz / Handle protection set
MOTO GUZZI V85 TT
ab Baujahr 2019 / from date of manufacture 2019
Artikel Nr.: / Item-no.:
554
4212
00 01
schwarz / black
INHALT

CONTENTS

1
700010387 Griffschutz links schwarz
1
700010388 Griffschutz rechts schwarz
1
700010389 Schraubensatz:
4x Senkschrauben M8x45
2x Senkschrauben M6x75
4x Senkscheibe ø8,4 x ø25mm
2x Senkscheibe ø6,4 x ø18mm
BENÖTIGTE WERKZEUGE

TOOLS REQUIRED

WICHTIG
IMPORTANT
Eine Seite nach der anderen montieren, damit sich der Lenker nicht verstellt !
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind, wie man eine
bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen Schrauben zuerst nur locker
an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende Anzugsmoment festgezogen. Dadurch wird
sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente beachten! Nach der Montage alle Verschraubungen
auf festen Sitz kontrollieren!
Mount one side after the other, so that the handle bar position does not change !
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action, you should
ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws should be tightened to
the torque specified. This guarantees, that the product is mounted without tension. Observe the tightening torques of the manufacturer!
Control all screw connections after the assembling for tightness!
1
700010387 Handle bar left black
1
700010388 Handle bar right black
1
700010389 Screw kit:
4x countersunk head screws M8x45
2x countersunk head screws M6x75
4x countersunk washer ø8,4 x ø25mm
2x countersunk washer ø6,4 x ø18mm
Verlängerung/
extension
Ratsche/Ratchet
1
