Cellphone-Mate SureCall Fusion-5 User Manual

4. Products sold by Cellphone-Mate, Inc. shall not be considered defective or non-conforming to the
Buyers' order if they satisfactorily fulfill the performance requirements that were published in the
product specification literature, or in accordance with samples provided by Cellphone-Mate, Inc. This
warranty shall not apply to any products or parts thereof which have been subject to accident,
negligence, alteration, abuse, or misuse. Cellphone-Mate, Inc. makes no warranty whatsoever in
respect to accessories or parts not supplied by it.
5. EXCEPT AS EXPRESSLY SET FORTH HEREIN, THERE ARE NO WARRANTIES, CONDITION
GUARANTEES OR REPRESENTATIONS AS TO MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR OTHER WARRANTIES, CONDITIONS, GUARANTEES OR REPRESENTATIONS, WHETHER
EXPRESSED OR IMPLIED, IN LAW OR IN FACT, ORAL OR IN WRITING. CELLPHONE-MATE, INC.'S
AGGREGATE LIABILITY IN DAMAGES OR OTHERWISE SHALL NOT EXCEED THE PAYMENT, IF ANY,
RECEIVED BY CELLPHONE-MATE, INC. FOR THE UNIT OF PRODUCT OR SERVICE FURNISHED OR TO BE
FURNISHED, AS THE CASE MAY BE, WHICH IS THE SUBJECT OF CLAIM OR DISPUTE. IN NO EVENT
SHALL CELLPHONE-MATE, INC. BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES,
HOWSOEVER CAUSED.
6. All matters regarding this warranty shall be interpreted in accordance with the laws of the State of
California and any controversy that cannot be settled directly shall be settled by arbitration in
California in accordance with the rules then prevailing of the American Arbitration Association, and
judgment upon the award rendered may be entered in any court having jurisdiction thereof.
7. If one or more provisions provided herein are held to be invalid or unenforceable under applicable
law, then such provision shall be ineffective and excluded to the extent of such invalidity
or unenforceability without affecting in any way the remaining provisions hereof.
FUSION-5 Booster Specifications
Upl i nk Freq. Ra nge (MHz)
Downl i nk Freq. Ra nge
Supported s ta nda rds
Input/Output i mpeda nce
Avera ge ga i n
Noi s e figure
VSWR
AC Power Transformer
Ma x output power
Ca bl e
RF connectors
Power cons umption
Di mens i ons
Wei ght
FCC ID (USA)
Ca na da IC
Safety Information
The Federal Communications Commission (FCC) has tested this product and found it to comply
with their RF Exposure Requirements, pursuant to FCC Part 22 and 24.
To comply with the FCC RF exposure requirements, keep the human user's body at least 8"
(20cm) from the indoor antenna of the booster.
Don't expose this product to extreme low or high temperature (-4°F or -20°C and 150°F or
70°C).
There are no consumer serviceable or modifiable parts inside this booster product. Alteration or
abuse of the booster or other components will void this product's warranty, and could be
dangerous to the user.
728-746/746-757/869-894/1930-1990/2110-2155
698-716/776-787/824-849/1710-1755/1850-1910
CDMA, GSM, UMTS, WCDMA, HSPA(+), EVDO, LTE
50Ω
65dB
<6 dB
≤2.0
Input AC110V, 60Hz; Output: DC 9-20V
3 Watts EIRP
CM400 or LMR400
N Fema l e (both ends )
<25W
10.75"x 9"x 2.3"
10.5LB
RSNCM-EHPRO
7784A-EHPRO
Five Band Business/Home Booster
Fusion-5
:
Package Contents
▪ 65dB Five-Band signal booster
▪ 110V AC power charger
▪ 5dB and 10dB attenuators
▪ Mounting kit
▪ User manual(this document)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.Changes or modifications not
expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment : CAN ICES-3 (B)/NMB-3(B)
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
The Manufacturer's rated output power of this equipment is for single carrier operation. For situations
when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially
where the output signal is re-radiated and can cause interference to adjacent band users. This power
reduction is to be by means of input power or gain reduction and not by an attenuator at the output of
the device.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
User Manual
(Model: CM－Fusion-5)
Cellphone-Mate, Inc.
CM-FUSION-5 (2012 V1.0)
888.365.MATE (6283) phone - (510)996-7250 fax
www.surecall.com www.cellphone-mate.com
48346 Milmont Drive Fremont, CA 94538
®
