Specifications - Makita Quiet Series Instruction Manual

SPECIFICATIONS

Model
MAX Output Power
SCFM @ 90 PSIG
Cut-In Pressure
Cut-Out Pressure
Bore x Stroke x Qty
Voltage -Single Phase
Hz
Motor RPM
Lubrication
Tank Size
Weight
Dimensions (L x H x W)
Outlet Max Pressure
CSA/US Listed
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Note: Specifications may differ from country to country.
Minimum Circuit Requirement: 15 AMPS
* A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same rating as the branch circuit the air
compressor is operated on. If the air compressor is connected to a circuit protected by fuses, use time delay fuses.
IMPORTANT
Read the Safety Guidelines and ALL instructions carefully before operating.
www.makitatools.com
www.makita.ca
MAC100Q
350 W
0.7
51 mm x 8 mm x 2
1 gal (3.8 L)
12.5 kg (27.6 lbs)
L: 328 mm (12-7/8")
W: 370 mm (14-1/2")
H: 282 mm (11-1/8")
MAC210Q
800 W
2.0
105 PSIG (0.72 MPa)
135 PSIG (0.93 MPa)
64 mm x 14 mm x 2
120 V AC
60 Hz
-1
1,750 min
Oil-Less
2 gal (7.6 L)
20.5 kg (45.2 lbs)
L: 441 mm (17-3/8")
W: 429 mm (16-7/8")
H: 347 mm (13-5/8")
135 PSIG (0.93 MPa)
Yes
MAC320Q
1100 W
2.6
64 mm x 17 mm x 2
3 gal (11.4 L)
23.8 kg (52.5 lbs)
L: 456 mm (18")
W: 481 mm (19")
H: 348 mm (13-3/4")
3
