MOD

MOD MOD MOD
RATE: Adjusts the speed of LFOs 1 - 3. Each LFO can be set at a different rate.
LFO 2: When this switch is lit, RATE and DEPTH controls affect LFO 2
LFO 3: When this switch is lit, RATE and DEPTH controls affect LFO 3.
DEPTH: Adjusts the amount of the selected LFO.

MODULATION EDIT PAGE

MODULATION EDIT PAGE MODULATION EDIT PAGE MODULATION EDIT PAGE
Displays LFOs 1 - 3, their destinations and waveforms.
Functions that Floss 1 - 3 can modulate:
*OSC123 (freq of all Osc's) RMODMX (ring mod level)
OSC1FM (freq of Osc 1)
OSC2FM (freq of Osc 2)
OSC3FM (freq of Osc 3)
OSC2MX (level of Osc 2)
OSC3MX (level of Osc 3)
Waveforms: Triangle, square, sawtooth up, sawtooth down, noise, sample & hold.
*LFO 1 only.
MODULATION MIDI SYNC PAGE E E E MODULATION MIDI SYNC PAG
MODULATION MIDI SYNC PAG MODULATION MIDI SYNC PAG
Assign midi time clock to drive the LFOs and choose key triggering option.

CONTROL

CONTROL CONTROL CONTROL
VOLUME: Adjusts main output level.
GLIDE: Sets glide (portamento) time for pitch slides from note to note.
SHIFT: **Holding this button and pressing
section will advance through edit pages. Use to get to MIDI Edit Page #2 for setting
MIDI channel. Holding SHIFT and pressing SAVE will toggle edit-compare function.
SAVE: Pressing this button once will initiate "Save to". Pressing again completes this
function. Pressing SHIFT following SAVE will cancel it. (Use this as an escape from an
edited patch to get to main page).
NOISMX (noise level)
VCFRES (filter resonance) NOASSN (nothing)
VCFFM (filter frequency)
OSC1PW (pulse width)
OSC2PW (pulse width)
<
or
OSC3PW (Pulse width)
VOLUME (main level)
>
or turning Q knob in programmer
4
