NAME PROGRAM PAGE

NAME PROGRAM PAGE NAME PROGRAM PAGE NAME PROGRAM PAGE
Use this page to name your patches.
The cursor will default to the first character. Use the Q knob to select the letter or
character. Use the left arrow and right arrow to go forwards and backwards. Pressing
the up or down arrow makes a blank space. After programming name save patch again
to save name.

COMMON FUNCTIONS

COMMON FUNCTIONS
COMMON FUNCTIONS COMMON FUNCTIONS
1. Setting MIDI Channel: Hold shift button and press left arrow twice to get to MIDI
page.
2. Saving a patch: Press save button once, the switch will be lit and SAVE TO: will
appear. You can save over the old patch with the new edited patch by pressing the
save button once again, or you can choose a new destination by turning the Q knob to
another patch location that will be displayed. To save to a different bank, use the up
arrow, and then select patch location. If you want to cancel the process or get back to
the main page press the shift button.
3. Escaping from an edited patch: Hit save button once then hit shift button. This will
get you to the main page; you can then select a new patch using the Q knob.
4. Accessing edit pages: While holding the shift button press the < > arrow buttons or
turn the Q knob.
5. Selecting second memory bank - Bank B: In the Main program page, or the Save to
page, up arrow toggles between bank A and bank B.

SCREEN JUMPS

SCREEN JUMPS SCREEN JUMPS SCREEN JUMPS
By pressing these buttons or moving these knobs, the display will change to the
corresponding edit pages.
Pressing LFO2 / LFO3
" SYNC (Osc. 3)
" 24DB
"
Moving GLIDE
" FREQ 1,2,or 3

EXTERNAL INPUT

EXTERNAL INPUT
EXTERNAL INPUT EXTERNAL INPUT
Processes audio signals from other clever sources. To hear signal, MIDI note(s) must
be sent to the SE-1 in order to open VCA.
will jump to: MODULATION EDIT PAGE
" OSCILLATOR TUNE PAGE
" MISCELLANEOUS EDIT PAGE #2
ENV 3,4 "
" MISCELLANEOUS EDIT PAGE #1
" OSCILLATOR TUNE PAGE
ENVELOPE EDIT PAGE
7
