File: MBA5-P33 V8 User Guide
Version : V1.0
MBA5-P33 V8
User guide
1/24
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Advertisement
Table of Contents
Related Manuals for AXEM Technology MBA5-P33 V8
Summary of Contents for AXEM Technology MBA5-P33 V8
- Page 1 File: MBA5-P33 V8 User Guide Version : V1.0 MBA5-P33 V8 User guide 1/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
-
Page 2: Table Of Contents
File: MBA5-P33 V8 User Guide Version : V1.0 Table of content Background ............................. 3 Product introduction ......................... 4 Introduction ........................4 Precaution before using battery ..................5 Charger..........................5 Notes ..........................6 Installation instructions ......................7 Appearance ........................7 Install Micro SD and SIM cards ..................7 Battery Charging ....................... -
Page 3: Background
File: MBA5-P33 V8 User Guide Version : V1.0 Background Description Date Version Author Auditor First parution 21/10//2019 V1.0 3/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €... -
Page 4: Product Introduction
1 Product introduction Introduction The MBA5-P33 V8 is a key product of the latest generation of rugged mobile readers, the MBA5 V8 range. This device is equipped with the Android 8.1 operating system. For even more performance, the MBA5-P23 V8 is built with an octa-core 2.5GHz processor. -
Page 5: Precaution Before Using Battery
File: MBA5-P33 V8 User Guide Version : V1.0 1.2 Precaution before using battery • Do not leave battery unused for long time, no matter it is in device or inventory. If battery has been used for 6 months already, it should be check for charging function or it should be disposed correctly. -
Page 6: Notes
File: MBA5-P33 V8 User Guide Version : V1.0 1.4 Notes Note 1: Using the incorrect type battery can lead to danger of explosion. Please dispose the used battery according to instructions. Note 2: Due to the used enclosure material, the product shall only be connected to a USB Interface of version 2.0 or higher. -
Page 7: Installation Instructions
File: MBA5-P33 V8 User Guide Version : V1.0 2 Installation instructions 2.1 Appearance 2.2 Install Micro SD and SIM cards The cards sockets are showing as follows: 2.3 Battery Charging By using USB Type-C contact, the original adaptor should be used for charging the device. Make sure not to use other adaptors to charge the device. -
Page 8: Buttons And Function Area
File: MBA5-P33 V8 User Guide Version : V1.0 2.4 Buttons and Function Area Buttons instructions Power Located on left side, press to ON/OFF device. Located on left side, its function can be defined by Function key Side button software. Scanning button located on both sides. There are SCAN button two scanning buttons. -
Page 9: Call Function
File: MBA5-P33 V8 User Guide Version : V1.0 3 Call Function 3.1 Calling numbers 1. Click icon 2. Click number key to input phone numbers. 3. Click icon to call. 4. Click icon to end call. 3.2 Contacts 1. Click contacts to open contacts list. -
Page 10: Other Functions
File: MBA5-P33 V8 User Guide Version : V1.0 4 Other functions Swipe down the screen to get access to the following functions: • Wifi activation • Bluetooth activation • Don’t disturb • Flashlight • Screenshot 10/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 11: Barcode Reader-Writer
File: MBA5-P33 V8 User Guide Version : V1.0 5 Barcode reader-writer In App Center, open 2D barcode scan test. Press “SCAN” button or click Scan key to start scanning. The parameter “Auto interval” can be adjusted. In the tab CONFIG, parameters numbers and values can be adjusted. Moreover, illumination power level can be adjusted from 0 to 10. - Page 12 File: MBA5-P33 V8 User Guide Version : V1.0 Caution: Please scan codes in correct way otherwise the scanning will be failed. 1D barcode: 2D barcode: Max. radiant power: 0.6mW Wave-length: 655nm IEC 60825-1 (Ed.2.0). 21CFR 1040.10 and 1040.11 standard. 12/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE –...
-
Page 13: Uhf Rfid Reader
File: MBA5-P33 V8 User Guide Version : V1.0 6 UHF RFID reader UHF Scan function 1. Open App Center, open “UHF”. 2. Select SINGLE or AUTO and click START, the UHF tags could be read. 3. Click STOP in demo to stop reading of UHF tags. -
Page 14: Uhf Configuration
File: MBA5-P33 V8 User Guide Version : V1.0 UHF configuration Click CONFIG in demo to adjust working mode (865-868MHz, 921-928MHz…) and output power (from +19dBm to +27dBm adjustable). 14/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 15: Uhf Tag Reading And Writing
File: MBA5-P33 V8 User Guide Version : V1.0 UHF Tag Reading and Writing The storage of one tag has 4 zones: RESERVED, EPC, TID and USER. Normally, the default password is 00000000. TID zone can only be read, other zones can be read and written. -
Page 16: Uhf Tag Lock And Kill
File: MBA5-P33 V8 User Guide Version : V1.0 UHF Tag Lock and Kill 6.4.1 Lock Function EPC memory can be locked. 16/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 17: Kill Function
File: MBA5-P33 V8 User Guide Version : V1.0 6.4.2 Kill Function Kill function can be used to kill the tag permanently, which means it will never be read or written again. Write the correct access password and click kill. 17/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE –... -
Page 18: Other Functions
File: MBA5-P33 V8 User Guide Version : V1.0 7 Other functions Bluetooth 1. Open “BT Printer” in App Center. 2. In the list of detected devices, click the device that you want to pair. 3. Select printer and click “Print” to start printing contents. -
Page 19: Gps
File: MBA5-P33 V8 User Guide Version : V1.0 7.2 GPS 1. Click “GPS” in App Center to open GPS test. 2. Setup GPS parameters to access GPS information. 19/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 20: Volume Setup
File: MBA5-P33 V8 User Guide Version : V1.0 7.3 Volume setup 1. Click “Volume” in App Center. 2. Setup volume by requirements. 20/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 21: Sensor
File: MBA5-P33 V8 User Guide Version : V1.0 7.4 Sensor 1. Click “Sensor” in App Center. 2. Setup the sensor by requirements. 21/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 22: Keyboard
File: MBA5-P33 V8 User Guide Version : V1.0 7.5 Keyboard 1. Click “Keyboard” in App Center. 2. Setup and test the main value of the device. 22/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 23: Network
File: MBA5-P33 V8 User Guide Version : V1.0 7.6 Network 1. Click “Network” in App Center. 2. Test WIFI/Mobile signal by requirements. 23/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 24: Accessories
File: MBA5-P33 V8 User Guide Version : V1.0 8 Accessories Cradle 24/24 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
