Power connection method with Telink Burning Board
TLSR9518A supports a easy debug method. Only three wires are needed.
5V from Telink Burning Board is connected to VBUS from
TLSR9518ADK80D.
SWM from Telink Burning Board is connected to SWS form TLSR9518ADK80D.
GND from Telink Burning Board is connected to GND form TLSR9518ADK80D.
GND
SWS
VBUS
Telink Confidential
7
