Summary of Contents for Samsung RL62VCRS
-
Page 1: User Manual
Refrigerator user manual English imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register Free Standing Appliance... -
Page 2: Door Alarm
KEY FEATURES OF YOUR NEW REFRIGERATOR Your Samsung Refrigerator comes equipped with various innovative storage and energy-efficient features. • Twin Cooling System The Refrigerator and Freezer have separate evaporators. Due to this independent cooling system, the Freezer and Refrigerator cool more efficiently. -
Page 3: Safety Information
SAFETY INFORMATION • B efore operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • B ecause these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual. WARNING CAUTION/WARNING SYMBOLS USED Indicates that a danger of death or serious injury exists. WARNING Indicates that a risk of personal injury or material damage exists. -
Page 4: Severe Warning Signs
• I n order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of WARNING refrigerant used. • N ever start up an appliance showing any signs of damage. If in doubt, consult your dealer. • T he room must be 1㎥ in size for every 8g of R600a refrigerant inside the appliance. • T he amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance. -
Page 5: Caution Signs
• D o not dissemble or repair the refrigerator by yourself. - You run risk of causing a fire, malfunction and/or personal injury. • I f you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung electronics service center. • K eep ventilation opening in the appliance enclosure or mounting structure clear of obstruction. • D o not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer. -
Page 6: Warning Signs For Disposal
• D o not store volatile or flammable substances in the refrigerator. - T he storage of benzene, thinner, alcohol, ether, LP gas and other such products may cause explosions. • D o not re-freeze frozen foods that have thawed completely. • D o not store pharmaceuticals products, scientific materials or temperature-sensitive products in the refrigerator. - Products that require strict temperature controls must not be stored in the refrigerator. • D o not put a container filled with water on the refrigerator. - If spilled, there is a risk of fire or electric shock. CAUTION SIGNS FOR CLEANING • D o not insert your hands into the bottom area under the appliance. -
Page 7: Additional Tips For Proper Usage
ADDITIONAL TIPS FOR PROPER USAGE • A llow the appliance to stand for 2 hours after installation. • T o get best performance of product, - Do not place foods too closely in front of the vents at the rear of the appliance as it can obstruct free air circulation in the freezer compartment. - Wrap the food up properly or place it in airtight containers before put it into the fridge freezer - Do not put any newly introduced food for freezing near to already frozen food. -
Page 8: Table Of Contents
SETTING UP YOUR REFRIGERATOR OPERATING YOUR SAMSUNG REFRIGERATOR TROUBLESHOOTING 8_ contents 09 Getting ready to install the refrigerator 10 Installation of the water line 13 Setting up the refrigerator 13 Removing the refrigerator doors 17 Leveling the refrigerator 18 Parts and features... -
Page 9: Getting Ready To Install The Refrigerator
GETTING READY TO INSTALL THE REFRIGERATOR Congratulations on your purchase of this Samsung Refrigerator. We hope you enjoy the state-of-art features and efficiencies that this new appliance offers. Selecting the best location for the Refrigerator • A location with easy access to the water supply. • A location without direct exposure to sunlight. • A location with level (or nearly level) flooring. • A location with enough space for the Refrigerator doors to open easily. • A llow sufficient space to the right, left, back and top for air circulation. If the Refrigerator does not have enough space, the internal cooling system may not work properly. -
Page 10: Setting Up Your Refrigerator
• W hen using any electrical device (such as a power drill) during installation, be sure the device is insulated or wired in a manner to prevent electric shock. • All installations must be in a accordance with local plumbing code requirements. • W ater line Kit and water filter are not covered by Samsung’s Warranty. The manufacturer (or dealer, installer) of them is responsible for any defects and all the loss caused by water filter & water line kit. • T he filter should be replaced should be replaced according to manufacturer (or dealer)’s instruction. -
Page 11: To Use Without The Water Filter
• T urn water on and check for any leakage. • Y ou can purchase the necessary filter cartridge at the retailer where you purchased this refrigerator. Make sure you buy the SAMSUNG filter cartridge (Replacement cartridge No : DA29-00015A) to ensure the best performance. • W ater line must be connected to drinkable water only • A compression fitting and nut kit is supplied with the unit and it is inside the fridge drawer. -
Page 12: Connecting The Water Line To The Refrigerator
Connecting the water line to the refrigerator 1. Remove the cap from water line on the unit and insert compression nut to the water line on the unit after disassembling from provided water line. 2. Connect both water line from the unit and water line in the kit. 3. -
Page 13: Setting Up The Refrigerator
SETTING UP THE REFRIGERATOR Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and functions of the appliance. By completing the following steps, your Refrigerator should be fully operational. 1. P lace the Refrigerator in an appropriate location with reasonable clearance between the wall and the Refrigerator. Refer to installation instructions in this manual. (P8. Selecting the best location for the Refrigerator) - Page 14 How to reverse the door (OPTION) Unplug the refrigerator or disconnect the power. The number on each picture indicates the relevant location of the refrigerator. Refer to the Reference Picture for each location. Reference Picture Disassemble ground wire by removing 1 screw, and disassemble right upper hinge by removing 3 bolts.
- Page 15 Remove 1 screw (use screwdriver) and 2 bolts (use 3/16 allen wrench), and then remove right side middle hinge. Separate the cap of the front left leg side of the Cover and insert it on the front right leg side of the Cover. Reattach the former right hinge on the left side and the former left hinge on the right side by using 2bolts.
- Page 16 3 bolts and reattach the ground wire using 1 screw. You can get the hinge from the installation tool box supplied with your new Samsung refrigerator. (Be careful not to tip over the fridge door and have wire damage.)
-
Page 17: Leveling The Refrigerator
LEVELING THE REFRIGERATOR After putting the doors back on the Refrigerator, make sure the Refrigerator is level so that you can make final adjustments. If the Refrigerator is not level, it will not be possible to get the doors perfectly even. Also it is possible to sweat in the refrigerator and ask more energy bills. -
Page 18: Operating Your Samsung Refrigerator
PARTS AND FEATURES Use this page to become more familiar with the parts and features of the Refrigerator. Fridge Light Multi-Purpose Fridge Door Bin Moving Tray Multi-Purpose (Location is adjustable) Door Bin Water Tank Fridge Shelves (Option) Bottle Bin Vegetable & Fruit... -
Page 19: Using The Control Panel
USING THE CONTROL PANEL 1. For auto ice maker model 2. For normal ice maker model Temperature & Function select / control panel Press this button to freeze food quickly. ( 1 ) Power Freeze (Power Freeze will last 2 and a half hours.) Button Freezer temperature set button. Press this button to set the Freezer temp between -14ºC and -25ºC. ( 2 ) Freezer Button (At initial power on, the default setting is -19ºC.) When the Ice Off Button is pressed, ice will not be produced. -
Page 20: Controlling The Temperature
- The temperature display will blink when freezer temperature increases due to frequent door opening, keeping warm food, etc. (Blinking will stop when the refrigerator reaches normal temperature. If for some reason it does not stop after a long period of time, contact a Samsung service center.) Setting the fridge temperature If you want to control the fridge temperature, follow as below. -
Page 21: Controlling The Power Freeze
(Blinking will stop when the refrigerator reaches normal temperature. If for some reason it does not stop after a long period of time, contact a Samsung service center.) If you want to make ice faster (Controlling the Power Freeze) Speeds up the time needed to freeze products in the freezer. -
Page 22: Making Ice
MAKING ICE Auto Ice Maker Model Take out the ice by using the shovel. The ice maker will produce 8 cubes per cycle - approximately 100~130 cubes in a 24-hour period, depending on freezer compartment temperature, room temperature, number of door openings and other use conditions. Throw away the first few batches of ice to allow the water line to clear. Be sure nothing interferes with the sweep of the feeler arm. -
Page 23: Storing Food In The Refrigerator
STORING FOOD IN THE REFRIGERATOR The Samsung Refrigerator has been designed to provide you with maximum space saving features and functions. Here are some of the customized compartments we have created to keep your food fresher longer. In order to further prevent odor from seeping into the ice compartment, stored food should be wrapped securely and as airtight as possible. -
Page 24: Door Bins
REMOVING AND RELOCATING THE FRIDGE ACCESSORIES 1. Door Bins To remove - Simply lift the bin up and pull straight out. To replace - Slide it in above the desired location and push down until it stops. Injury may occur if the door bins are not firmly inserted. Do not allow children to play with bins. -
Page 25: Pull Out Drawer
REMOVING THE FREEZER ACCESSORIES 1. Pull Out Drawer To remove - P ull the drawer out to full extension. Tilt up rear of drawer and lift straight out. (Refer to picture 1 & 2) Open the freezer door fully and remove the drawer. To replace - P lace the drawer onto the rails by tilting it up. Lower the drawer into place until it is horizontal and slide the drawer in. (Refer to picture 3) 2. -
Page 26: Using The Water Dispenser
USING THE WATER DISPENSER (OPTION) You can easily obtain chilled water with the water dispenser without opening the refrigerator door. In addition, you can save electricity by reducing the number of times the door is opened by more than 30%. Overview When the water dispenser is not in use, the following is recommended 1. -
Page 27: Cleaning The Interior
CLEANING THE REFRIGERATOR Caring for your Samsung Refrigerator prolongs the life of your appliance and helps keep it odor and germ-free. Cleaning the Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth. You can remove the drawers and shelves for a more thorough cleaning. -
Page 28: Replacing The Interior Light
Replacing the interior light For LED lamp, please contact service engineer to replace it. 28_ operating... -
Page 29: Troubleshooting
troubleshooting PROBLEM SOLUTION The Refrigerator does not • C heck that the power plug is properly connected. work at all or it does not • I s the temperature control on the display panel set to the correct temperature? chill sufficiently. Try setting it to a lower temperature. • I s the refrigerator in direct sunlight or located near a heat source? • I s the back of the refrigerator so close to the wall that air cannot keep circulating? (Refer to page 10 for the best location.) The food in the • I s the temperature control on the display set to the correct temperature? Try setting it to a warmer temperature. - Page 30 memo...
- Page 31 memo...
-
Page 32: Ambient Room Temperature Limits
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRY AUSTRALIA...
