GB
INSTRUCTIONS FOR INSTALLATION AND
OPERATION
This product and its accessories fulfil the
requirements of the EU's low voltage directive
(73/23/EEC and 93/68/EEC) and the directive
concerning electromagnetic compatibility
(89/336/EEC and 92/31/EEC).
INSTALLATION
The heater should be mounted horizontally.
The heater is for use in dry rooms only.
The heater should not be mounted directly below an
electric outlet.
Some light vinyl floor coverings and varnished parquet
floors may become discoloured with the long-term
o
effect of temperatures above 35 C. With these types of
floors a minimum clearance of 12 cm to the underside
of the heater is recommended.
Fix the wall bracket ① to the wall, allowing
1.
for the minimum clearance requirement.
The wall bracket may also serve as a template
(see drawing).
2. Enter the heater on the hooks at the bottom of the
wall bracket. Rise the heater towards an
588.311a s4av4 301007
upright position, fasten the strap(s) ② and
fasten the heater on the top of the wall
brackets.
3. The heater may now be connected to the
mains.
OPERATING INSTRUCTIONS
Switch on the heater by pressing the switch Ⓐ and
turn the thermostat dial Ⓑ to 30 (max.). Light Ⓒ
should come on, indicating that the heater is on and
working. When the required room temperature is
reached, slowly turn the thermostat dial
wards until the light Ⓒ goes out. If the thermostat is
set to 5, the heater offers frost protection.
NB! The element is installed with a protective oil
covering. This will evaporate when the heater is
switched on for the first time and may emit a
harmless smoke for the first few minutes.
SAFETY DEVICE
The heater has a built-in safety device that
disconnects the power if, for example, the heater is
accidentally covered (see below). Remove the
offending item immediately! The safety device will
automatically re-connect the power supply as soon
as the temperature in the heater returns to normal.
DO NOT COVER THE HEATER
If the air flow through the heater is obstructed in any
way the heater will overheat and cause the safety
device to cut out and disconnect the power.
Therefore, do not dry clothes, etc., on or close to
the heater! Dust and nap can eventually block the
openings in the underside of the heater. To avoid
this, vacuum the underside at least once a year.
To ease cleaning of the heater's backplate,
dismount the heater from the wall bracket.
Plase observe that the following
symbol means "Do not cover".
back-
B
The MAINS LEAD is specially produced.
In the event of damage, a replacement should be
ordered from supplier and installed by a qualified
electrician.
ACCESSORIES
- Curtain protection rod.
- Lid to prevent random operation of heater.
- Feet for heaters (portable heater).
- Unit Ⓔ for programmed temperature control.
The lamp Ⓓ shows a green light when
temperature reduction is activated.
Please contact your supplier.
We reserve the right to make modifications without notice.
