- Page 1 DIA MkII INSTALLATION EN...
- Page 2 DIA MkII LEENDERS Points of attention installation Dia MkII Moving the stove • Carefully remove the casing from the stove by moving it upwards; leave the packaging material covering the stove. • Unscrew the transport brace from the pallet. • Remove the bolts.
- Page 3 DIA MkII LEENDERS Mounting the wall bracket • Mount the wall bracket using the expansion-shell bolts. • Affix 2x flat tape on the vertical strips of the wall bracket. Hanging the stove • Place sliding pieces underneath the transport brace. • Push the stove against the wall bracket so that the oblong holes slide over the eyes.
- Page 4 DIA MkII LEENDERS Levelling the stove 2 • Use the 2 M8 socket-head bolts provided at the back of the wall support to level the stove “depthwise” (socket-head wrench 4). • Tap the cotters into place. Fitting wall-support finishing cover • Fit the finishing cover by sliding the projections into the slots.
- Page 5 DIA MkII LEENDERS Rotatable? • Fixed position: leave bolts in place as delivered. • 2 x 45° rotatable: remove bolts no. 1 and release bolt no. 2 and secure it with the nut. Service: adjusting the door • Remove the pipe and casing from the stove. • Open the door. • Adjust the door so that it hangs parallel using an open-end spanner j.w.
-
Page 6: General Instructions And Regulations
DIA MkII LEENDERS General instructions and regulations Installation To secure the warranty, the Dia MkII must be installed by a properly qualified person employed by a dealer recognized by Leenders. See leenders.nl for a current list of addresses of recognized dealers or contact the manufacturer. The stove is susceptible to scratching. Handle with care. After installation, check the draught by burning some kindling wood. • All local regulations including those referring to national and European standards must be observed when installing the appliance. • Ensure there is sufficient ventilation/air supply in the room where the stove is installed. Air extractors such as a cooker hood may cause problems due to flue gases escaping from the stove into the room.
