- Page 1 WALD INSTALLATION EN...
- Page 2 WALD LEENDERS Installation option 1; fixing THROUGH ceiling. Installation option 2; fixing TO ceiling. 2019.49.002.I.EN...
- Page 3 Installation option 1, fixing with threaded ends and counter plate is recommended. This provides the Wald with better side-collision protection. • If the ceiling height exeeds 2750mm, the Wald can only be suspended according to option 1, with the counter plate and threaded ends. •...
- Page 4 LEENDERS Installation option 1; fixing THROUGH ceiling. Fixing with threaded ends and counter plate is recommended. This provides the Wald with better side-collision protection. 1. Position the counter plate on the ceiling. 2. Fix the threaded ends tot the counter plate.
- Page 5 WALD LEENDERS Installation option 2; fixing TO ceiling. Please note: the construction of the ceiling must be appropriate for this method of attachment. 1. Mark out het ceiling plate 2. Drill holes Use the cardboard template. Face Drill 6 holes distributed over the the flatbit to the rear.
-
Page 6: Installation Option 1
Use a telescopic, double-walled flue that can be adjusted to fit - L= Length telescopic double-walled flue, excluding the connector - X = Length mantel pipe Wald - Y = Length of double-walled flue that protrudes from the ceiling - L = X - Y - 65mm 5a. - Page 7 WALD LEENDERS 7. Installing the double-walled flue Lift the double-walled flue out of the mantel pipe and attach this to the section that is protruding from the ceiling. 8. Attaching the mantel pipe Put the mantel pipe on the lift. Use the lift for attaching the mantel pipe to the ceiling plate.
- Page 8 WALD LEENDERS 9. Levelling the mantel pipe Check to see if the mantel pipe is haning plumb. Adjust for plumb if necessary using the 3x socket-head screws. Loosen the 6x M8x16 a little befor you do this. Afterwards re-tighten the 6x M8x16.
- Page 9 Elevate the lift and first attach the double-walled flue to the swivelling ring. Please note: the weight of the double-walled flue must not be supported by the Wald’s swivelling connector. 14. Securing the stove Elevate the lift more and secure the stove. Use the 6x M8 bolts supplied.
- Page 10 WALD LEENDERS 15. Transport plate Remove the M6 bolt and with this the wooden transport plate. 16. Air supply cover plate (only for use with the Poujoulat Efficience) Secure the air supply cover plate underneath with 3x M6. Please note: only install the cover plate in conjunction with the Poujoulat Efficience.
- Page 11 WALD LEENDERS 18. Inspection Check if the stove is fixed securely to the ceiling. Check if the aeration pipes are properly connected. Check that the heat shield is properly seated underneath. 2019.49.002.I.EN...
-
Page 12: General Instructions And Regulations
General instructions and regulations Installation For the validity of the guarantee the Wald must be installed by a professional fitter employed by a recognised Leenders dealer. See leenders.nl for a current list of addresses of approved dealers or contact the factory.
