- Page 1 PHAROS INTERIOR INSTALLATION EN...
-
Page 2: Materials And Tools Required
PHAROS INTERIOR LEENDERS Materials and tools required 1x mounting ring 1x decorative pipe 1x bearing plate 16x balls (+ 3 spares) 1x finishing cover 1x flap-control handle 1x lower shell 1x Spark screen 1x ceiling-floor support plate 2x shell parts... - Page 3 PHAROS INTERIOR LEENDERS Nut M8 (4x) Bodywork-ring M8 (4x) Ceiling-floor support plate Treaded rod M8 (4x) Nut M8 (4x) Pipe with ring plate Indication mark on the backside 2. Installing the ceiling-floor support plate 1. Preparation • Cut the four threaded rods included in the delivery to the proper length, •...
- Page 4 PHAROS INTERIOR LEENDERS Hexagon- head bolt M8 x 20 A: 4x bolt M6x20 B: 4x bolt M8x20 Stovepipe support The centre hole indicates the middle of the rear side of the bearing plate. 5. Fixing the stove pipe 6. Levelling •...
- Page 5 PHAROS INTERIOR LEENDERS Finishing cover Decorative pipe Column Mounting ring 10. Preparing the stove 9. Installing the decorative pipe and column • Slide the decorative pipe (the slots at the upper end) and the column • Bring the pre-assembled frame to the place of installation using a on the stove pipe and move them upwards as far as possible) handtruck.
- Page 6 • Remove the Pharos lifting jack. against the bottom of the frame. • The Pharos Interior is now ready for use. Check its performance. • Insert the M6x75 bolt with an M6 nut and an M6 bodywork ring on it into the hole of the bottom shell, and tighten it until it cannot go any further (there is still some thread left).
-
Page 7: General Instructions And Regulations
General instructions and regulations Installation To secure the warranty, the Pharos Interior must be installed by a properly qualified person employed by a dealer recognized by Leenders. See leenders.nl for a current list of addresses of recognized dealers or contact the manufacturer.
