Item # 100-266-7687;# 100-150-1159;# 100-150-1168;#1001-869-016;#1001-869-015;
#1001-880-278; #1001-880-279; #1001-880-280; #1001-880-296; #1001-880-297;
#1001-880-298; #1001-880-299;
Model # 2.1.1088
USE AND CARE GUIDE
ADIRONDACK CHAIR
Questions, problem, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY 2.1.1088
Summary of Contents for HAMPTON BAY 2.1.1088
- Page 1 Model # 2.1.1088 USE AND CARE GUIDE ADIRONDACK CHAIR Questions, problem, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM HAMPTONBAY.COM...
- Page 2 Table of Contents Table of Contents..........Safety Information.......... Warranty............Pre-Assembly..........Tools Required..........Hardware Included..........Package Contents..........Assembly ............. 5-10 Safety Information - Examine all packing material before assembling; shortages may occur from parts left in the packing material. - Please follow the instructions on the following pages. Warranty WHAT IS COVERED All merchandise is warranted to be free from defects in workmanship and material for one year from the date of purchase.
- Page 3 Pre-Assembly TOOLS REQUIRED PHILLIPS SCREW DRIVER HARDWARE INCLUDED Description Quantity Part ø BOLT 15/5/16”x50 MM ø BOLT 12,7/1/4”x35 MM ø SCREW 8 x 1 1/2” ø LOCK NUT 13/5/16”x8 MM ø ø PLASTIC WASHER 35/ 9 x 3 MM ø ø PLASTIC WASHER 35/ 19 x 3 MM ø...
- Page 4 Pre-Assembly (continued) PACKAGE CONTENS Description Quantity Part SEAT BACK SUPPORT RIGHT LEG LEFT LEG RIGHT ARM LEFT ARM WOOD HINGE WOOD SLAT HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 5 Warning Attaching plastic washer to each wood join Ensure you attach the plastic washers in each wood join part of the chair. Failure to attach these plastic washers will cause the chair to not fold properly and damage to the chair. AA JJ HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 6 Assembly 1 Attaching the right and left leg Attach the right leg (C) and left leg (D) to the seat (A) using bolts (AA), washers (HH), washers (EE), and nuts (DD). Tighten the bolts using the Allen key (JJ) and wrench (II). Use the wrench (II) to hold the nuts (DD) in place while you tighten with the key (JJ).
- Page 7 Assembly ( continued ) 2 Attaching the wood slat Attach the wood slat (H) to the legs (C and D) using screws (CC). Tighten with a Phillips screwdriver. ø SCREW 8 x 1 1/2” HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Assembly ( continued ) 3 Attaching the chair back Attach the bottom brace of the chair back (B) to the hinges (G) using bolts (BB), washers (HH), and washers (FF). Tighten the bolts (BB) with the Allen key (JJ). Description Quantity Part ø...
- Page 9 Assembly ( continued ) 4 Attaching the hinges to the seat Attach the hinges (G) to each side of the seat (A) using bolts (AA), washers (HH), washers (EE), washers (HH), and nuts (DD) as shown. Tighten the bolts using the Allen key (JJ) and wrench (II). Use the wrench (II) to hold the nuts (DD) in place while you tighten with the key (JJ).
- Page 10 Assembly ( continued ) 5 Attaching the left and right arm Attach the front of the left arm (F) to the top of the left leg (D) using a bolt (AA), washer (HH), washer (GG), washer (HH), and nut (DD). Tighten the bolt (AA) using the Allen key (JJ) and wrench (II). Use the wrench (II) to hold the nut (DD) in place while you tighten with the key (JJ).
