- Page 1 AT E1-VETTA Instructions translated from the original Part 1 TRANSMITTING UNIT USER MANUAL OTHER LANGUAGES https://qrcode.elcaradio.biz/man/83d1e403a35e6f1053e101c0ca1f2c81 0408MA000268 E1_VETTA_P1-00_ENG...
- Page 3 ACCORDINGLY, IT IS THE RESPONSIBILITY OF THE MANUFACTURER AND THE DESIGNERS OF THE MACHINE ON WHICH YOU INTEND TO INSTALL THE ELCA RADIO REMOTE CONTROL to carry out a careful and in-depth risk assessment to determine whether the Elca radio remote control is suitable for the safe and efficient use of the Machine, taking into account the conditions of use and the...
- Page 4 Elca. Elca is not responsible for and accepts no liability for any installation of the Elca Radio Remote Control carried out by Elca itself, or for any use or maintenance of the Elca Radio Remote Control that do not fully comply with all the instructions and warnings supplied by Elca and with all applicable Laws, Regulations and Standards, also local.
- Page 5 IT IS THE RESPONSIBILITY OF THE OWNER, THE USER OF THE SYSTEM AND THEIR EMPLOYEES MANAGERS AND SUPERVISORS to make sure that all the Users of the Elca Radio Remote Control and all those that work or will work with or near the Machine...
-
Page 6: Table Of Contents
INDEX Use and Maintenance Manual ............................9 Structure ................................9 Definitions ................................9 Symbols ................................10 Who these instructions are for ..........................10 Storage of the instructions ............................11 Updating the Manual ............................... 11 Intellectual property ............................... 11 Series, Radio Remote Control and Unit .......................... 12 Conformity ................................... - Page 7 Warnings during normal use ............................. 27 Warnings for after its use ............................28 Belt ..................................28 Description of the Transmitting Unit ..........................30 10.1 Technical data ................................ 31 10.2 The Position of the controls and Connection diagram ....................31 10.3 Transmitting Unit data plate ............................. 31 10.4 Indicator lights ..............................
-
Page 9: Use And Maintenance Manual
The Instruction manual for use and maintenance is an integral part by other local regulations, and every other device, machinery, of the Elca Radio Remote Control and therefore of the Machine that is equipment, system, application, etc., on which the Elca Radio equipped with the Radio Remote Control. -
Page 10: Symbols
Symbols - Maintenance technician: the entity, specialised technician, that carries out routine and extraordinary maintenance on the Elca Radio Remote Control, in order to keep it undamaged and running The parts of the Manual that are drawn attention to by this efficiently. -
Page 11: Storage Of The Instructions
Elca is solely responsible for the instructions compiled and validated by Elca itself (Original Instructions); in order to be able to check the The instructions concerning the installation and accuracy of the translation, any translations should always accompany maintenance of the Radio Remote Control are for the Original Instructions. -
Page 12: Series, Radio Remote Control And Unit
European Union. Elca Radio Remote Controls provide a control interface to e used on The Radio Remote Controls in the E1 series operate in the 434,050- Machines to manage the command and control system. -
Page 13: Manufacturer's Identification
Assistance and spare parts For technical assistance and/or spare parts, please contact Elca. When sending a request regarding an Elca Radio Remote Control the serial number (Serial Num.) of the Radio Remote Control itself must be provided. The serial number (Serial Num) can be found on the unit's data plate (see paragraph 10.3). -
Page 14: Safety Warnings
Radio Remote Control on Manual and all the applicable Laws, Regulations and Standards, any application. also local; The Manufacturer of the Machine or whoever intends to use or install an Elca Radio Remote Control on a Machine should first of all: ELCA... - Page 15 RADIO REMOTE CONTROL AND THE MACHINE OR THE USE - FOR AN ASSESSMENT OF THE RISKS; YOU WANT TO MAKE OF IT, IRRESPECTIVE OF WHETHER - FOR THE DECISION TO USE THE ELCA RADIO REMOTE IT FALLS WITHIN THOSE ENVISAGED OR NOT, OR FOR CONTROL ON THE MACHINE;...
- Page 16 Safety warnings - the use of the Elca Radio Remote Control that does not comply with what is written in this Manual and in any other instructions supplied by Elca and with applicable Laws, Regulations and Standards, also IN THE SAME WAY ELCA IS NOT RESPONSIBLE FOR, AND local;...
-
Page 17: Risk Analysis For Remote-Controlled Machines
Elca radio remote control and all its components are carried out only and entirely in accordance with... -
Page 18: Unintended Activations Of The Commands
- disable the Radio Remote Control and cease using the "Machine+Radio the Radio Remote Control and the position of use just as Remote Control" system until the problem is solved by means of described in the specific part of the Transmitting Unit. the required technical intervention. ELCA... -
Page 19: Radio Remote Control Of The Range E1
Characteristics other apparatus in the vicinity not to be disturbed and vice-versa not An Elca Radio Remote Control of the E1 series belongs to a family of to be disturbed by them. industrial Radio Remote Controls, that can mainly be used, but not only, for controlling lifting and transportation apparatus. - Page 20 TEMPORARILY, CAN CAUSE SERIOUS INJURIES OR DEATH situation. OR DAMAGE TO PROPERTY. The stop function can activate: - by the operator pressing the red STOP button on the Transmitting Unit (manual mode). ELCA...
-
Page 21: Technical Data Of The Range E1
Control; each unit of the Radio Remote Control has its own data plate. Remote Control. The possible risks deriving from the When sending a request regarding an Elca Radio Remote Control the activation of the stop function should be evaluated both serial number (Serial Num.) of the Radio Remote Control itself must... -
Page 22: Transportation And/Or Storage
Radio Remote Control of the Range E1 Applications An Elca Radio Remote Control of the E1 range can be used for various applications: the suitability of the Radio Remote Control for each Do not remove the data plate on the Units from their position, different application, especially for safety reasons, should be assessed since removing it will immediately void the warranty. - Page 23 Machines. the Radio Remote Control. The Manufacturer of the Machine can allow the installation and use of the THE INSTALLATION OF AN ELCA REMOTE RADIO CONTROL Radio Remote Control on these applications under ON MACHINES AND IN SITUATIONS DESCRIBED ABOVE its own responsibility.
-
Page 24: Classification Of The Controls
These initials are reported in the Position of the controls and in the Connection diagram to be used during installation. These documents clarify the correspondence between the commands sent by the Transmitting Unit and those available in the Receiving Unit. ELCA... -
Page 25: Instructions For The User
Radio Remote Control or the Machine. - use the Machine on which the Elca Radio Remote Control is installed only in safe conditions and only if it is possible to get a good view of the working area of the Machine;... - Page 26 Instructions for the User - use the Machine on which the Elca Radio Remote Control is installed - respect any safety distances connected to the use of the Machine only in accordance with the measures and instructions provided by in order to avoid potential and/or real situations of risk.
-
Page 27: Environmental Conditions Of Use
Instructions for the User Environmental conditions of use The environmental conditions of use of the Elca Radio Remote Control Failure to comply with the points above can lead to are the following: a connection between the Units of the Radio Remote... -
Page 28: Warnings For After Its Use
- avoid leaving the Machine in dangerous conditions (for example with a suspended load); - prevent unauthorised or unsuitable trained persons from using the Radio Remote Control. FAILURE TO COMPLY WITH THESE INSTRUCTION SCAN CAUSE SERIOUS INJURIES OR DEATH AND/OR DAMAGE TO PROPERTY. ELCA... - Page 29 The User should use the belt with the Transmitting Unit attached to prevent it falling or actuators accidentally being activated. The belt should be replaced if it show signs of wear or damage. A different use of the belt constitutes an incorrect use of the radio remote control. ELCA...
-
Page 30: Description Of The Transmitting Unit
Radio remote system type: Transmitting model: AT E1-VETT A Freq. range: 434.050-434.790 MHz Internal battery: Li-ion 3.7 V 1100 mA Transmitting power: < 10 mW ERP Protection degree: IP65 TX module: MT32EL Serial n° : E100004 Manufact. : 2017 Made in Italy ELCA... -
Page 31: Technical Data
IP65 Dimensions 170x74x81 mm Weight 400 g 10.3 Transmitting Unit data plate There is just one Data plate on the Transmitting Unit AT E1-VETTA. Its position and the information contained in it can be found in the table below. ELCA... -
Page 32: Indicator Lights
The green or red colour provides information on the radio remote control. See the tables below for the meaning of the LED lights. For the action to be undertaken when the green and red indicator lights are present see the tables below or paragraph 14.1. ELCA... - Page 33 Low battery (5 minutes of run time). Receiving Unit. The Radio Remote Control might be being disturbed or be at the limit The red LED [A] flashes rapidly. of its operating range or else in a place with obstacles impeding the transmission of the signals. ELCA...
-
Page 34: General Operating Instructions
It is necessary to check that the Manufacturer of the Machine and/or the Installer provide suitable instructions and warnings in relation to any risks that derive from the stoppage of the Machine. These risks could, for example, come from inertial movements or from the swinging of the load. ELCA... -
Page 35: Starting The Radio Remote Control
Radio Remote Control. However, it is not possible to eliminate the PIN CODE which will always have to be entered to start the Radio Remote Control. Changing the PIN CODE can be carried out only qualified personnel. ELCA... -
Page 36: Activating The Controls
To start the Radio Remote Control see paragraph 11.3.1Start up using a PIN code. The Transmitting Unit has a low The red LED flashes battery rapidly. (5 minutes of run time). To charge the Transmitting Unit see chapter 12. ELCA... -
Page 37: Switching Off Of The Transmitting Unit
If the Transmitting Unit is no longer usable, it can be replaced with Remote Control on the Machine. a new identical Transmitting Unit, which can be requested from Elca. The signals occur through the coming on of the LED available on the Transmitting Unit during normal use of the Radio Remote Control. - Page 38 Remove the data plate from the transmitter that is no longer used and fix it to the new one. If this is not possible because it is lost, destroyed or illegible, contact an ELCA Assistance Centre for a new one.
-
Page 39: Charging System Of The Transmitting Unit
Inside the Transmitting Unit there is a rechargeable battery that cannot be removed from the Radio Remote Control. To charge the battery, the charging device (Elca-Clip) supplied with the The charging system is for professional use, therefore it Elca Radio Remote Control must be used. -
Page 40: Charging Indicator Lights
2 hours of run time. It is advisable to always keep the batteries fully charged to be able to CLICK ensure full effectiveness. Avoid leaving the batteries discharged for long periods. Charge the batteries at least once a year. ELCA... -
Page 41: Removing The Charging System
12.3in reverse order. 12.5 Charge level indicator of the Transmitting Unit To check the charge level of the Transmitting Unit, start and keep active simultaneously the START + K1 actuators with the Transmitting Unit off. START STOP CHECK CHARGE ELCA... -
Page 42: Maintenance
- the Transmitting Unit is off; - use the Machine on which the Elca Radio Remote Control is installed - the STOP button is pressed. only in safe conditions and only if it is possible to get a good view of the working area of the Machine;... -
Page 43: Routine Maintenance
- clean the Transmitting Unit without using solvents or corrosive or supply. flammable products. Do not use steam cleaners, pressure washers or high pressure appliances; - put the Transmitting Unit in a clean and dry place, sheltered from rain, the sun and heat sources. ELCA... -
Page 44: Special Maintenance
No specialised technician can carry out special undamaged. They should be clearly visible. maintenance operations on the Radio Remote Control if he does not belong to the Elca assistance network or 13.2.3 Quarterly routine maintenance who is not expressly authorised by Elca. -
Page 45: Actuators (Buttons, Joysticks And Potentiometers)
The actuators of the Transmitting Unit (joystick, keys, buttons, selectors) must be replaced before reaching the “maximum number of movements”. Replacement is necessary even when these are working. 1.000.000 This type of maintenance can prevent possible dangerous situations caused by faults with the actuators. ELCA... -
Page 46: Guide To Solving Problems
- move all the Transmitting Units in the work area away from the Elca the assistance service of the Machine Manufacturer. Transmitting Unit used, in order to avoid possible radio disturbance and interference;... - Page 47 Release the STOP no other similar steady. pressed. button. systems or sources of interference such as The green LED blinks There is radio radio relay systems or rapidly. disturbance. transmitters. Switch off the Transmitting Unit and then switch it back on. ELCA...
-
Page 48: Decommissioning And Disposal
LED not activate the The command was not comes on of the relay corresponding transmitted. corresponding to the movement. command activated on the Transmitting Unit. Check the wiring in the The wiring is incorrect. Receiving Unit ELCA...
