Page 2: Introduction
They will be pleased to assist you. Which magnetic fields can the MP-2000 measure? The MP-2000 field meter measures all practically occurring magnetic fields, both DC and AC, in a range from 0.1 to 40,000 A/cm (Oersted). The device has two measurement ranges: 0 - 199.9 A/cm (Oersted)
Page 3 And what is really unique: For the first time, the MP-2000 uses measuring probes in which an integrated micro- controller digitises and linearizes the special analogue signals directly in the probe. This new technique is highly immune to interference and permits extremely precise measurements even with high magnetic field strengths, where Hall probes no longer operate linearly.
Page 4: Fast Start
FAST START • Connect the probe cable to the measuring probe and device. • Switch on the MP - 2000 with the ON-OFF key. Automatic zero balancing takes place when the device is switched on, therefore the probe should not be in a magnetic field when doing so.
Page 5: Important Notes
IMPORTANT NOTES 1. Retention of the Stored Measured Values when changing the Battery The stored measured values are retained even after switching off the device or storing it without a battery. 2. Power Supply The device is supplied as standard with three 1.5 V (Mignon) batteries. However, it can optionally be powered by three 1.2 V NiCd rechargeable batteries.
Page 6: Menu Operation
I. MENU OPERATION -0- key – Zero Point Setting Zero point adjustment takes place after pressing the -0- key. The probe must not be in a magnetic field during this time! After the zero balancing is complete, the display ± shows 0.2 (influence of the earth’s magnetic field when moving the measuring probe).
Page 7: Display Settings
PEAK Measuring Range P1 / P2 Switch to the peak value memory range P1 in order to measure peak fields < 500 A/cm (G) or < 50.0 kA/m (mT). The PEAK symbol is shown behind the current measured value on the display. If the measurement range is exceeded, the display shows: PEAK-Value >...
Page 8: Memory Settings
• Statistics: 100.5 DC/AC/PEAK A/cm Digital Display Batch-No.: 1 No.: 200 Statistic Batch Min: 50.0 A/cm Analogue Print+PC Max: 349 A/cm Mean: 199 A/cm Setup Std.Dev.: 87.0 A/cm MENU When the statistics display is activated, the current measured value is displayed at the top and the statistical parameters are additionally displayed.
Page 9: Print & Pc Settings
• Display / Select: Batch-No. DC/AC/PEAK Display / Select Min.: 31.0 A/cm Display Max.: 130 A/cm Delete Batch Mean: 80.5 A/cm Max.Batch-No. Print+PC Std.Dev.: 29.0 A/cm Setup - 130 A/cm < > The memory contents are displayed or the current memory is selected here. At the same time, any measured value in the memory can also be deleted here, upon which the statistics will be automatically updated.
Page 10 • Send to PC: DC/AC/PEAK Send to PC Print+PC Display Print Values Batch Print all Batches Print+PC Current Transfer Send to PC Setup Send the statistical evaluation & measured values from the current memory to the PC via the USB wireless interface and our serial interface. Start the data transfer in the PC program first! •...
Page 11: Setting Options
5. Setting - options • Select Language: Deutsch DC/AC/PEAK Language Display LCD-Light English Batch Unit Spanisch Niederlande Print+PC Bat. Voltage Setup Reset • • Switch LCD Lighting on/off: Language DC/AC/PEAK Setup LCD-Light Display LCD-Light Batch Unit Print+PC Bat. Voltage Reset Setup Auto Off:...
Page 12: Measuring Probes
• Reset: Setup DC/AC/PEAK Language Instrument-Reset Language LCD-Light LCD-Light Unit Reset Language Bat. Voltage LCD-Light Reset Reset returns all device settings to the factory settings. This function should be used if settings have been changed and the device does not work properly or if the calibration of the probe does not work properly.
Page 13: Calibration Standard
Operating instructions 1. Connect the printer cable to the device socket (RS 232C) and the printer. 2. Switch on the MP-2000; the printer then switches on automatically. 3. See menu operation item 4 – Transfer & PC V. INTERFACE SETTINGS The device’s interface parameters are set as standard for the USB wireless interface.
Page 14: Software
VI. SOFTWARE TRANSFER data read-in program The TRANSFER read-in program runs under Windows XP and Vista 32-bit. It reads the measured values into a file and displays them on the screen. Refer to the soft- ware instruction manual for more details. TRANSFER-EXCEL data transfer program This program automatically reads the measured values into an existing Excel file.
Page 15: Technical Data
TECHNICAL DATA MP - 2000 Model Display: Illuminated graphics display: Measuring units: kA/m – A/cm – Gauss(Oe) – Tesla selectable Measuring ranges: DC: 0 – 4000 kA/m DC: 0 – 40.000 A/cm (Gauss/Oe) DC: 0 – 4000 mT AC: 20 – 20.000 A/cm (Gauss/Oe) AC: 20 –...
Page 16: Mega-Print Data Printer
The capacity of the rechargeable battery is sufficient for approx. 60 hours of opera- tion. Notes on operation 1. The operation of the MEGA-PRINT printer in conjunction with the MP-2000 mag- netic field meter is explained under Menu Operation item 4 – Transmit & PC in the MP-2000 operating manual.
Page 17: Internet Survey
4. Faulty printout The MEGA-PRINT must be charged up again if individual lines of the printout are not printed correctly. Inserting a new paper roll • Open the cover • Insert the paper roll • Pull out the end of the paper •...
