Page 1: Table Of Contents
Via S. Silvestro, 92 21100 Varese Tel + 39 0332 - 213045 212639- 220185 Fax +39 0332 - 822553 www.assicontrol.com e-mail: info@assicontrol.com C.F. e P.I. 02436670125 S T R U M E N T I & S E R V I Z I p e r i l s i s t e m a q u a l i t à...
Page 2: Introduction
Service De- partment. Our technicians are always ready to help you. What can you measure with EASY-CHECK FE-S ? On iron and steel (FE) all non-magnetic coatings, such as varnish, paint, plastics, enamel, rubber, ceramics and galvanization (except niquel) up to 5 mm.
Page 3: Short Instructions
And this is really unique: • EASY-CHECK FE-S can measure up to 80 hours with only one 1.5V Mignon battery. • Worldwide the only device with a swinging measuring probe allowing to measure inside pipes and in other in- accessible places.
Page 4: Function Modes
FUNCTION MODES Switch on the device by pressing the key until <on> is displayed. Re- lease the key. When you now press the key once again for a longer time the following modes will appear one after another: Store readings in the Data Memory Display Statistics Print or activate the Serial Interface Clear the last reading...
Page 5 <Prn> Print or Activate the RADIO CONTROL function When EASY-CHECK FE-S is connected to the printer MEGA-PRINT or operated with the RADIO CONTROL module, press the key until <prn> is displayed. Then release the key and press it again to start the data transfer.
Page 6 <cLr> Clear the whole Data Memory Press the key until the symbol <cLr> is displayed. Release the key shortly and press it again to confirm. Now the whole Data Memory is cleared. <Un> Change unit of measurement (µm / mils) In its basic setting the instrument measures in µm.
Page 7: Calibration
• Switch on the device. • Set the device with the probe on the base plate FE (blue) and press the key for about 2 sec until <0.0> is displayed stable. Then release the key and zero setting is performed and confirmed by a beep sig- •...
Page 8: Charge The Rechargeable Battery With The Line-Charging Unit
The battery may run out and destroy the device ! With the device switched off the charging connector is inserted into the interface plug of EASY-CHECK FE-S. The device switches on by itself and a bar diagram with the battery symbol is displayed. With the charger connected you can go on taking measurements.
Page 9: Technical Data
TECHNICAL DATA Measuring Technique: Magnetic induction on iron and steel (ISO 2178) Measuring Range: 0 – 5000 µm Indication: LCD 3½ digits with floating decimal point and guides for operation Resolution: selectable 1.0 µm or 0.1 µm 100 µm: ± 1 µm Accuracy: below 1000 µm: ±...
Page 10: Optional Accessories
OPTIONAL ACCESSORIES SOFTWARE incl. Operation Instructions • Software TRANSFER Sends the data and statistics to the computer. • Software TRANSFER-EXCEL Transfers the data directly in an existing Excel file. • Graphic Statistics Software STAT-6 Sends the data and statistics to the computer. Limit values can be set which are evaluated as line and bar diagrams.
Page 11: Data Printer Mega-Print
The charging time should be at least 4 hours. Operating Instructions 1. The operation of MEGA-PRINT together with the Coating Thickness Meter EASY-CHECK FE-S is explained in the operating instructions of EASY-CHECK FE-S (Page 5). 2. When the printer MEGA-PRINT is connected to the Coating Thickness Meter EASY-CHECK FE-S, MEGA-PRINT switches on automatically (the green LED flashes every 2 sec).
Page 12 3. The manual paper feed is performed with the key „Paperfeed“. When the printout is finished the paper stripe is transported out of the casing by pressing this key and can be neatly turned off. 4. Faulty print out Incorrect printed lines mean that the printer should be recharged. Insert a new paper roll •...
