Operation – C120LCD model
The heat output is controlled electronically, according to the room
temperature. When the unit is plugged in the power light illuminates
(see '2' in Fig. 2). The unit is now in stand by mode. The power light
will remain lit until the heater is disconnected from the power outlet.
Table 1
Stand by button
Mode button
Oscillation button
Timer button
Up button
Down button
Table 2
Fan symbol
Low heat mode
High heat mode
Auto heat mode
Timer symbol
Air Temperature symbol
Set Temperature symbol
Pressing the Stand by button see Table 1 and Fig 4 will start the
heater. Pressing the Stand by button again will return the heater
to stand by mode. Upon turning the heater on, the unit will be
in Auto heating mode with a set temperature of 35°C. The set
temperature, heating mode and fan icons appear on the display – see
Table 2 and Fig. 7. The current air temperature will also appear on the
display. The display is back lit and to conserve energy the back light will
turn off after 15 seconds if no control buttons have been pressed. If the
Mode, Oscillating or Timer button (see Table 1 and Fig. 4) is pressed, the
back light will turn on again.
I n A u t o h e a t i n g m o d e t h e s e t t e m p e r a t u r e c a n b e
a d j u s t e d a s d e s i r e d u s i n g t h e U p / D o w n b u t t o n s ( s e e
Table 1 and Fig. 4), located on the control panel. Pressing the Mode
button selects the heating mode. Pressing the Mode button will cycle the
heater through the heating modes Auto mode/Fan only/Low heat/High
heat. By pressing this button once Fan only mode is selected, pressing
twice provides Low heat mode, pressing three times High heat mode is
selected. Pressing the Mode button once more returns the heater to Auto
heat mode. When the heater is in Low heat, High heat or Fan only mode
the current air temperature will appear on the display, the set temperature
indicator will not be displayed – see Table 2 and Fig. 7.
Note: If switched to stand by mode the heater will retain its last heat
setting. The last heat setting will be cleared from memory once the heater
is disconnected from the power outlet.
Thermostat
Press the Mode button until the display shows Auto heat mode - see
Table 2 and Fig. 4. To adjust the set temperature, press "+" to increase
the temperature and "-" to decrease the temperature - see Table 1 and
Fig. 4. The set temperature can be adjusted from 5°C to 35°C and this
will be shown on the display. When the air temperature rises above the
set temperature, the heat will switch off but the fan will continue to run for
approximately 20 seconds. When the air temperature drops below the set
temperature, the unit will come back on.
Note: When in heating mode if the unit is set to stand by mode the fan will
continue to run for approximately 20 seconds.
Runback Timer Mode - C120LCD model only
The heater is fitted with a run-back timer feature which can be set in any
of the operating modes – Auto, Fan only, Low heat or High heat mode.
The run time can be set by pressing the Timer button - see Table 1 and
Fig. 4. If the Timer symbol (see Table 2) is not shown pressing the Timer
button once activates timer mode and "1HR" will appear on the display –
see Fig. 4. Pressing the Timer button again will advance the set running
time to "2HR" and this will appear on the display. If the timer button is
pressed and held the hour display continues to count up until "8HR"
appears on the display. At this point releasing and pressing the Timer button
again will deactivate the timer mode and the Timer symbol will disappear
from the display but the heater will continue to run.
Once the run time has been set the heater will run and the Timer symbol
will remain on the display until the set time runs out. At this point the
heater will switch to stand by mode. To turn the heater back on, press
the Stand by button.
Oscillating Function – C120LCD model – see Fig. 5
This heater is provided with an oscillating function. When the Oscillation
button is pressed (see Table 1 and Fig. 4) the heater will oscillate back
and forth. Press the Oscillation button again and the oscillation will stop.
Safety Cut-out
The heater is fitted with a thermal cut-out. If the air inlet or outlet grilles
are restricted in anyway the cut-out switches the heater off automatically.
To bring the heater back into operation, remove the cause of over heating
then unplug the unit from the electricity supply for a few minutes. When
the heater has cooled sufficiently reconnect and switch on the heater.
Fuse Link
A thermal fuse link is provided as an added safety feature. If the fuse link
operates and opens circuit it is the result of abnormal overheating within the
appliance and servicing of the appliance by a competent service engineer
will be required in order to ensure the future safe operation of the heater.
Air Filter – C120LCD model – see Fig. 6
This heater is provided with an air filter. Dust and fluff can accumulate
in the filter and to avoid overheating of the element the filter should be
cleaned when required. To clean the filter remove the filter bracket from
the back of the heater – see 'A' in Fig. 6. The filter (see 'B' in Fig.6) can be
taken from the filter bracket and dust or fluff can then be removed using
a vacuum cleaner. When cleaning of the filter is complete the filter should
be refitted to the filter bracket. The filter bracket should then be refitted to
the rear of the product.
Note: Disconnect the heater from the power supply before cleaning the
filter.
Cleaning
Switch off the appliance first and disconnect the plug from the socket. Clean
the housing with a moist cloth, vacuum cleaner or brush. Do not use any
abrasive or caustic cleaning agents. Do not use any flammable cleaning
agents e.g. petrol or spirit for cleaning the appliance. Never immerse
the appliance in water. Air inlet and outlet area should be cleaned with a
vacuum cleaner regularly· If the appliance is not used for extended periods,
it must be protected against excessive dust and dirt.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not
be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for
recycling advice in your country.
After sales service
Should you require after sales service please contact the retailer from
whom the appliance was purchased or contact the service number relevant
to your country on the warranty card.
Please do not return a faulty product to us in the first instance as this may
result in loss or damage and delay in providing you with a satisfactory
service.
In the interests of further development, the appliance may be subject to
constructional or design changes without prior notice.
Please retain your receipt as proof of purchase.
Model Identifier(s):
Heat output
Nominal heat output
Minimum heat output (indicative)
Maximum continuous heat output
Auxiliary electricity Consumption
At nominal heat output
At minimum heat output
In standby mode
Type of heat output/ room temperature control
Mechanical thermostat room temperature
control
Electronic room temperature control
Contact details
C120TLS C120LCD
Pnom 2.0 2.0
Pmin 1.1 1.1
Pmax,c 2.0 2.0
elmax 0.0 0.0
elmin 0.0 0.0
elSB 0.0 0.0012
Yes No
No Yes
GDHVI
Barn Road, Dunleer, Co. Louth,
Ireland
kW
kW
kW
kW
kW
kW
