INSTALLATION

Caution: Make sure that the rear panel mounted voltage selector is set to correct voltage!
• Connect inputs and outputs to XLR connectors using high quality cables only.
• Both inputs and outputs are balanced.
• For unbalanced connections either pin 2 or pin 3 should be terminated to audio ground.
• Always connect audio screens to pin 1.
• Do not place the MPL-2 near or above other units producing excessive heat or
electro-magnetic fields.

SPECIFICATION

Input dynamic Range......................... Better than 120dB (balanced)
Output dynamic range........................ 100dB to 120dB (depending on gain and threshold settings)
Maximum input level.......................... +29dBu (balanced)
Maximum output level........................ +29dBu (balanced)
Distortion............................................ Typically less than 0.003%
Limiter attack time.............................. Instant
HF limiter attack time......................... Programme dependent 1msec to 20 msec
Release time...................................... Programme dependent
Ω
Input impedance................................ 100k ground floating electronically balanced
Ω
Output impedance............................. 33 electronically balanced
Threshold........................................... +14dBu to +22dBu
H.F. Threshold................................... 0dB to 26dB below limiter threshold
Gain................................................... 0dB to 10dB
H.F. Limiter........................................ >2kHz
Power................................................ 90-130, 180-260 Volts @ 50-60 Hz
Fuse...................................................315mA, anti surge (slow)
Subject to change without notice.
MASELEC MPL-2
Peak & High Frequency Limiter
