- Page 1 Alert-it Care Systems P163xxB General Alarm Monitor (wired) Handbook Models covered by this handbook P163ACB Wired Touch-iT Monitor P163BAB Wired Sense-iT Bed/Chair Vacation Monitor P163BCB Wired Switch-iT Monitor One of a range of Alert-it Care Alarms available from...
- Page 2 This handbook is intended to assist carers install, configure and use the monitors. The carer therefore needs to understand the needs of the user and asses that the monitor meets those needs and if any supplementary monitoring is needed taking into account any health risks.
- Page 3 Quick Reference Sheet: Installation Call for assistance Alarm Indicator 12v power supply or power off key on non- rechargeable versions Connection for sensors (bed Slide open door mats, floor mats, or switches. under unit to See page for pinout replace batteries RESET and standby power enable Connection to Nurse Call for rechargeable versions...
- Page 4 Installation (cont) Sensor Testing Occupancy Sensors Ensure the bed/chair is unoccupied and after pressing RESET there will be a four tone beep and the unit should be in STANDBY. Five tones will indicate the sensor is being falsely triggered by the weight of the bedding/cushion or otherwise in- stalled incorrectly.
-
Page 5: Reset The Alarm
Operation (cont) Link” (see page 8). The alarm will automatically reset if the user returns to bed/chair. To special order the monitor can be programmed to play a warning tune for 30 seconds prior to sending the alarm P163BCB Switch Input Activating an external switch will result the same function as for the Call for Assistance above. -
Page 6: Battery Replacement
Maintenance Battery Replacement Expected Battery Life: Operating Mode Battery capacity No failsafe heartbeat, no alarms 1 year Fail safe heartbeat, and alarms 6 months Maximum alarm number (based on 2 min response) 2000 alarms The battery needs replacing when the alarm led flashes intermittently every 8 seconds. -
Page 7: Input Connections
Technical Information & Configuration Input Connections The connection details pin Function FCC64 for the unit are shown cable above and, in general, +12v (option) Brown the alarms will be activated when a Delay in Yellow connection is made Instant in Green from pin 2 or pin 3 to 0v (pin 4 or 5). - Page 8 Technical Information & Configuration 1-Input Link The two input s can be joined by this link so that one level of alarm is INSTANT and a second level DELAYED. To access this link , remove the 4 case screws and separate the two halves. The picture shows the two possible positions for the Bed/Chair Vacation Alarm.
- Page 9 Safety Instructions and Warnings This symbol indicates there are warnings and precautions associated with the use of this equipment that should be carefully read and understood before using the equipment. Ensure that the senor cable is routed and secured to avoid the risk of entanglement or strangulation.
- Page 10 Alert-it Care Alarms are social aids designed and manufactured in accordance with 93/42/EEC as Class 1 Medical Devices. They are intended to improve the vigilance of carers to distressing side-effects of various diseases, such as Epilepsy and Dementia. They do not monitor vital physiological processes and should not be expected to diagnose any disease or predict the onset of any symptoms.
