Assa Abloy SL100 Quick Start Manual

SL100 Latch Adaptor
For Installation Assistance, Call 855-594-6989 • www.assaabloyglass.us

Table of Contents:

1. Parts List ................................................................................1
2. Tools Needed .......................................................................1
3. Applicable on Glass Door Types.....................................1
4. Remove Assembly from the Door ................................2
5. Removing Old Latch Assembly ......................................2
6. Installing SL100 Latch Adaptor ..................................3-4
7. Install Assembly on the Door ........................................5
8. Strike Installation ...............................................................5
9. Final Checks ......................................................................6-7
10. Maintenance .....................................................................7

1. Parts List:

• SL100 Latch Adaptor
• Rockwood Manual Strike
• Latch-Actuator Gauge

2. Tools Needed:

• Allen Keys:
• Flat Head Screw Driver
• Vise Grips (Non-marring): Curved Jaw, Straight Jaw
• Gasketing (Vertical Ball Joint Removal)

3. Applicable on Glass Door Types:

A
Copyright © 2018, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
• Lubricant Packet
• Threadlocker
• Fasteners
/ ", / ", / ", / ", / "
5 1 5 3 1
64 8 32 16 4
BP P
NOT TO SCALE
