Table of Contents

Introduction ............................................................................. 1
1. Specifications .................................................................. 2
2. Important Safety Instructions ........................................ 2
3. Operation ......................................................................... 2
3.1 Transporting the Phoenix AirMax ............................. 2
3.2 Electrical Requirements ............................................ 2
3.3 Ducting ....................................................................... 2
3.4 Resettable Circuit Breaker ....................................... 3
3.5 GFCI Protection and On-Board Duplex Receptacle . 3
4. Maintenance .................................................................... 3
4.1 Power Cord ................................................................. 3
4.2 Cleaning ..................................................................... 3
4.3 Service ....................................................................... 3
5. Wiring Diagram ............................................................... 4
6. Service Parts .................................................................... 5
Warranty ........................................................................... 6
Serial No.__________________________________
Purchase Date_____________________________
Dealer's Name_____________________________
Read the operation and maintenance instructions carefully
before using this unit. Proper adherence to these instructions
is essential to obtain maximum benefit from your Phoenix
AirMax.
Toll-Free 1-800-533-7533

1 Specifications

Part No. 4035000
Power 110-120 VAC, 1.9 Amps
Blower 925 CFM
Cord 20ft 6in Power Cord
Warranty One Year, 100% Parts and Labor
Dimensions Width
Height
Depth
Weight

2 Important Safety Instructions

CAUTION: Risk of electric shock. Can cause injury or death
to reduce the risk of electric shock:
• Do not expose to standing water or rain
• Do not use an extension cord
• Unplug fan before servicing.
• Do not block air intake or outlet. One foot minimum
distance to obstructions.
Indoor use only
• Do not use as stool or bench
• Do not operate with damaged cord or plug.
• Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or similar coverings. Do not route
cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
WARNING: Not Suitable for use with Solid-State Speed
Controls
AVERTISSEMENT: Ne Convient Pas a Des Regulateurs De
Vitesse a Semi-Conducteurs

3 Operation

3.1 Transporting the Phoenix AirMax

The Phoenix AirMax is designed to be stacked vertically or
horizontally ("Bookshelf Stacking") for transport.

3.2 Electrical Requirements

The Phoenix AirMax can be plugged directly into any standard
wall receptacle. Without ducting, the Phoenix AirMax will
draw 1.9 amps at 120 VAC. Ducting will reduce amp draw. Up
to 6 Phoenix AirMaxs can be daisy chained on a standard 15
amp branch circuit.
2
www.UsePhoenix.com • sales@UsePhoenix.com
17"
8 7/8"
20 1/2"
21 lbs.
