Phoenix Stackable CAM Pro - Centrifugal Air Mover
The Phoenix Stackable CAM Pro offers all the great features of our proven CAM air movers, with the addition of an innovative
stackable cabinet design. Featuring multiple contact points and interlocking side grills, the Phoenix Stackable CAM Pro can be stored
safely and securely up to 4 units high, freeing up valuable space in your trucks and warehouses.
The Stackable CAM Pro features class-leading airflow and efficiency. Using a unique 1/3 horsepower motor design and proprietary
blower technology, the Phoenix Stackables achieve 1050 CFM at over 2800 FPM with high static pressure, while using only 2.6 amps
of electricity on high speed (2.0 amps on low). With it's low amp draw and onboard GFCI, the Phoenix Stackable CAM Pro gives
you maximum airflow on a circuit, allowing up to 4 CAMs on a standard 15 amp household circuit on high speed (or up to 6 on low
speed). The Phoenix Stackable CAM housing is durable, washable, and chemical resistant. It features multiple operating positions
allowing it to be aimed horizontally, vertically, or at 45°. And, like all Phoenix air movers, the Stackable CAM Pro is ETL Listed, UL
Certified.
The Phoenix Stackable CAM Pro is also lightweight and properly balanced for easy handling. Other convenience features include a
lighted cord for easier determination of power to the outlet and superior cord management for better handling, packing, and storage.
The Phoenix Stackable Centrifugal Air Mover Pro
• 2-Speed 1/3 Horsepower Motor
2.6 Amps on High Speed
2.0 Amps on Low Speed
• Maximum Velocities 2800 FPM
• Balanced Exhaust Airflow
• Directional Airflow
Horizontal, 45° Angle, 90° Angle
• Durable, rugged, chemical resistant housing, fan wheel,
and controls design.
• Operator interface conveniently located for easy access,
featuring: power indicator lamp and large three-position
switch.
• Ergonomic carry handle and power cord storage.
• Non-marking, anti-skid, rubber feet.
• 4 CAMs on a circuit on high
• 6 CAMs on a circuit on low
• 20% more CFM/Amp than our current industry leading
CAM
• On-board duplex GFCI and circuit breaker
• Stacks up to 4 units high
1.800.533.7533
OWNER'S MANUAL
Installation, Operation & Service Instructions
– READ AND SAVE THESE INSTRUCTIONS –
USEPHOENIX.COM
pictured to demonstrate
Phoenix Stackable Centrifugal Air Mover Pro
PN 4030990
Specifications subject to change without notice.
WISCONSIN
1
*PN 4030980 is
stackability
TS-669
08/18 Rev. A
