- Page 1 A Bergey WindPower Company Manual POWERSYNC II INVERTER Operator’s Manual & Installation Instructions Part No. MANPSII Rev. 1.1 November 2014 Bergey WindPower Company. All Rights Reserved. 2200 Industrial Blvd. Norman, Ok US 1.405.364.4212 w ww.bergey.com...
-
Page 2: Table Of Contents
CNL - Additionally evaluated to CAN/CSA C22.2 No. 107.1-1, "General Use Power Supplies." 3rd Edition, Dated September 1 , 2001 with revision through 2006. The Bergey WindPower Company’s model PSII12 and PSII126208 inverters are intended for variable frequency un-rectified 3-phase AC input from Wind Powered Turbines. 1. Table of Contents TABLE OF CONTENTS ............................ -
Page 3: Ratings
153 lbs. / 64 Kg Enclosure NEMA Type 1 NEMA 1 indicates that the enclosure is constructed for indoor use only. It provides protection to personnel against incidental contact with the enclosed equipment. Page 2 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 4: Important Safety Instructions
Note that the input and output circuits are isolated from the enclosure. In accordance with Clause 15.2.1.1 of CAN/CSA-C22.2 No. 107.1, system grounding, when required by the Canadian Electrical Code, Part I, is the responsibility of the installer. Page 3 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 5: Installation
PowerSync II Operator’s Manual & Installation Instructions 4. Installation 4.1. Dimensions Page 4 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 6: Locating
CUTTING ADDITIONAL HOLES IN THE ENCLOSURE IS NOT RECOMMENDED AND VOIDS THE WARRANTY ON THE ENCLOSURE AGAINST CORROSION AND WATER DAMAGE. ANY DAMAGE TO THE ELECTRONICS CAUSED BY THE MODIFICATION WILL BE YOUR RESPONSIBILITY. Page 5 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 7: Ac Line (Output) Connection
250VAC (BUSSMANN BK/GMD-2.5-R). Three input fuses are located in a separate fuse box provided by the installer. Fuse type may vary, but must be UL listed fuses rated, 400 VAC minimum, 50 Amp maximum. Page 6 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 8: Connection Example
The standard inverter is capable of withstanding input line to ground surges of about 6kV at 3kA. Contact your distributor or BWC for application specific lightning surge suppression solutions. Page 7 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 9: Operation
The inverter is transferring power to the utility grid Fault A fault has occurred. See fault messages Manual Stop The manual stop button has been pressed Press Reset Fault Limit Three faults have occurred in an hours time Press Reset Page 8 Rev: 1.1 1.405.364.4212 / www.bergey.com... - Page 10 This is the voltage of the boosted DC link bus that is used to generate the output sine wave. This voltage should stay between 200 and 570 Vdc but will not trip off until it reaches 680Vdc. Page 9 Rev: 1.1 1.405.364.4212 / www.bergey.com...
-
Page 11: Trouble Shooting
OV limiting was not able to prevent the high grid voltage. AC OVER VOLT 2030 Site issues should be investigated such as loose grid side connections, undersized wires or grid voltage flickers. Page 10 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 12: Equipment Maintenance
The touch screen display may become dirty over time. To clean the display use clean water applied to a soft non-abrasive cloth. Water sprayed directly onto the display could possibly leak inside and cause damage. Dirt and fingerprints do not affect the operation of the touch screen display. Page 11 Rev: 1.1 1.405.364.4212 / www.bergey.com... -
Page 13: Return Shipment Information
Contact BWC if replacement material is required. Seal the carton securely and ship prepaid to the following address with the RMA number on the label. Be sure to insure your inverter with your shipper. Bergey WindPower Company Service Department 2200 Industrial Blvd.
