5. For Kenwood radios, make sure that the AXSWC-RF displays that a Kenwood radio is being
used; reference to Radio Legend. If the Radio Legend shows a JVC radio instead, then reference
to the Changing Radio Type to force program the AXSWC-RF to display as a Kenwood.
Tip: Some Kenwood radios have a feature called Remote Sensor. If your radio has this
feature, ensure it is turned on. If it is on, turn it off, then back on.
6. For Alpine radios: Remove the 3.5mm jack from the radio, reprogram the AXSWC-RF with
the jack removed, and then reconnect the 3.5mm jack back into the radio.
Tip: Some Alpine radios have a feature that turns the remote to either the back, or the front.
If you have one of these radios, ensure the sensor is on the rear setting. If the setting is on
the rear, turn it to the front, then back to the rear.
7. For Pioneer and Sony radios: If the AXSWC-RF works, but the buttons are out of order,
or become out of order; this could be caused by the 3.5mm jack on the AXSWC-RF not
seating properly, slipping out, or dirt on the contacts. Additionally, sometimes this can be
intermittent. Remove any dirt on the contacts, reinsert the jack firmly into the radio, and
then put a stress loop on the 3.5mm cable to prevent this from happening in the future.
Also, if anything is prohibiting the jack from seating all the way in, such as a heatsink,
lightly trim some of the plastic from the 3.5mm jack as needed.
If you have performed any of the steps above, reset the AXSWC-RF by pressing the reset button on
the AXSWC-RF for 3 seconds, release, then wait until the LED goes solid (approximately 20 seconds).
TROUBLESHOOTING
LED Feedback Legend
1. Eclipse (Type 1)
2. Kenwood
3. Clarion (Type 1)
4. Sony and Dual
5. JVC
6. Pioneer and Jensen
7. Alpine
8. Visteon
(CONT)
9. Valor
10. Clarion (Type 2)
11. Metra OE
12. Eclipse (Type 2)
13. LG
14. Parrot
15. XITE
9
REV. 1/21/2020 INSTAXSWC-RF
