Argus Cordex CXC How To Connect

Cordex Controller Ethernet Connection

Summary
Procedure on how to connect a computer to the CXC Controller via a crossover Ethernet cable for CXC
versions
1.71 and greater.
Part 1 will configure the CXC using its LCD touch screen and Part 2 will set up the local computers Ethernet
port for direct connection to the CXC.
Tools/ Reference Documents Required
• Ethernet crossover cable
• Computer with an Ethernet Port
• Cordex Controller Manuals
• Hand tools
Part 1 – Controller Setup

CXCR and CXCP controllers:

Direct connection requires a crossover cable. It also requires your PC to have a network connection
configured to communicate directly with the Cordex. If the Cordex is on a local network, always use that
option first. To access the web interface via a local connection;
1. Connect the crossover cable from your PC to the CXC Ethernet port; both the CXC green and yellow
lights must be on steady when connected. If not verify the cable is a cross-over and is a good cable.
2. On the Cordex, record the existing IP communication settings including IP, subnet mask and gateway
(if any).
3. Set the IP to 10.10.10.201 the subnet mask to 255.255.255.0 the gateway should be blank.
4. Save setting.

CXCI controller:

1. Reboot the CXCI by press and holding the front panel reset button for three seconds. The unit will
beep three times and IP address will be reset to 10.10.10.201 and DHCP will be disabled. Wait until
the controller completes its reboot process.
