8.3. Ordering spare parts
Please provide the following information on all
orders for spare parts:
Model/type of the equipment
■
Article number of the equipment
■
ID number of the equipment
■
Part number of the required spare part
■
For our latest prices and information please go
to www.isc-gmbh.info

9. Storage

9.1 Equipment
Store the equipment and its accessories out of
children's reach in a dark and dry place at
above freezing temperature. The ideal storage
temperature is between 5 and 30 °C. Store the
equipment in its original packaging.
9.2 Liquid gas cylinder
Never store the liquid gas cylinder inside
■
the house, in rooms below ground level or in
non-ventilated areas!
The valves on the liquid gas cylinder must
■
have valve guard caps and lock nuts.
Gas cylinders must be stored upright, even
■
when they are empty.
10. Connection diagram (Fig. 3)
Q1 ON/OFF switch
F1 Fuse-thermostat
M1 Fan motor
Y1 Thermoelectrical ignition guard (gas valve)
Y2 Safety solenoid valve
B1 Thermal element
B2 Piezo ignition
B3 Ignition electrode
B4 Burner
10.06.2011 13:49 Uhr Seite 11

11. Technical data

Rated thermal load:
Air throughput:
Gas consumption:
Equipment category:
Country of destination:
Type of gas:
Operating pressure P:
Mains connection: 230 V ~ 50 Hz, 0.17 A, 38 W
Protection type:
Temperature class:

12. Disposal and recycling

The equipment is supplied in packaging to
prevent it from being damaged in transit. The
raw materials in this packaging can be reused
or recycled. The equipment and its accessories
are made of various types of material, such as
metal and plastic. Defective components must
be disposed of as special waste. Ask your
dealer or your local council!
To comply with European Directive 2002/96/EC
concerning old electric and electronic
equipment and its implementation in national
laws, old electric power tools have to be
separated from other waste and disposed of in
an environment-friendly fashion, e.g. by taking
to a recycling depot.
max. (Hi) 17 kW
500 m
G 30: 1340 g/h
HU/CZ/SK
Standard propane
Standard butane
300 mbar (propane/butane)
For EU countries only
Never place any electric power
tools in your household refuse.
GB
3 /h
I3B/P
IP44
75°C
