- Page 1 RangerBOSS Network Ready Constant Monitor Model CM2800 Instruction Manual...
-
Page 2: Table Of Contents
Contents Description CM2800 Features Installation Installation Instructions Installation Diagram Operation Wrist Strap Indications Mat Indications GND monitor Indications Maintenance Specifications Service and Warranty... -
Page 3: Cm2800
Ohm Metrics Resistance Monitor: CM2800 The Ohm Metrics' CM2800 Series dual conductor workstation moni- tor provides continuous monitoring of voltage and resistance for two wrist straps along with two mat and two workstation tool grounds. The status’ are displayed using tricolor LED’s on the front panel of the monitor and abnormal levels trigger an alarm to inform opera- tors on the line. - Page 4 Operation The CM2800 monitors the grounding functions of a workstation and alerts users when levels are out of the set range. The CM2800 has the capabilities to monitor: Operators: Resistance and voltage of two wrist straps/personnel, Work surfaces: Resistance levels of two dissipative surfaces. Tools: Resistance levels of two grounded work station tools.
- Page 5 1. Operator Grounding The operator is grounded when the dual conductor wrist strap is plugged in to the jack labeled “OP” of the grey remote. The corre- sponding LED label “OP” and “V” will be GREEN if levels are normal. If the any of these parameters exceed preset high limits, the corre- sponding LED will turn RED and alarm will sound.
- Page 6 If the cable connecting to a wrist strap remote is unplugged or sev- ered at either end, the monitor’s audible alarm will sound, and the corresponding “OP” LED will turn red. Note: Each remote has two jacks labeled “OP” and “AUX”. The “OP” jack is monitored and “AUX”...
-
Page 7: Installation
Installation Before you install your device, check for the items below: 1 - CM2800 workstation monitor 2 - Remote Jacks 1 - Power Supply 2 - Telephone Cables 3 - Grounding Cables: FM1515, FM1515CM, FM1515NR Please carefully read the following instructions before proceeding with product installation. - Page 8 Note: The work surface mats have to be connected to the CM2800 with zero Ohm wire for proper mat monitoring operation. Using a wire with a 1M resistor may cause alarm. The FM1515NR is the pro- vided zero Ohm cord and more can be purchased from Transforming Technologies.
- Page 9 Operator voltage: ±10%, or within 3 counts at 2V or less Mat resistance: ±10% Tool resistance: ±10%, or within 3 counts at 5Ω or less If you need to calibrate the operator resistance of your CM2800 unit, please contact Transforming Technologies...
- Page 10 Accessories The CM2800 comes with a line of optional accessories: 1. CM2800-D: Digital Display & External Control Module 2. CM2800-SEE: Alarm and Hardware Management Software 3. CM2800-H: Network Router 4. CM2800-IMS: Real-time Central Monitoring Software 5. GZ-Relay: External Relay Box CM2800–...
- Page 11 CM2800-D Display Screens Main Screen: Display the real-time measure- ment value of the resistance and voltage. PAGE 1: CM2800’s ID number, S/N#, current limit option and status for V1 & V2. PAGE 2: Current High/Low limit option and status of OP1&OP2. PAGE 3: Current limit option and status of M1, M2, G1 &...
- Page 12 1A DC power adaptor will be required if you plan to let 4 sets of CM2800 + CM2800-D share one DC power.) These monitors are interlinked with a special 10-feet communication cable provided by Transforming Technologies with the Part# of GZ-485CABLE.
- Page 13 4096 workstations. An entire assembly line’s ESD protection can be remotely monitored and adjusted with one computer. For more information on the CM2800 accessories please contact Transforming Technologies.
-
Page 14: Specifications
CM2800 Series Monitor Specifications Wrist-strap resistance alarm limit: User programmable from resistance “Low” wrist-strap 750KΩ~2.4MΩ alarm 8MΩ~35MΩ resistance for “High” wrist-strap alarm. Maximum wrist-strap operator voltage: 50 mV max with 10 M max operator resistance, less than 100 mV under wrist strap open fault conditions. -
Page 15: Service And Warranty
Service and Warranty Transforming Technologies, LLC provides a limited warranty for the CM2800 series. All new products are guaranteed to be free from defects in material and workmanship for a period of one (1) year from the date of shipment. Liability is limited to servicing (after evaluating, repairing or replacing) any product returned to Trans- forming Technologies. - Page 16 T r a n s f o r m i n g T e c h n o l o g i e s , L L C 3719 King Rd. Toledo, Ohio 43617 Phone: 419-841-9552 Fax: 419-841-3241 E-mail: info@transforming-technologies.com...
