- Page 1 T R A N S F O R M I N G T E C H N O L O G I E S , L L C Ohm Metrics™ Static Field Meter & Ionizer Verification Unit Model EFM115 Instruction Manual...
-
Page 2: Table Of Contents
Contents Description EFM115 Ohm Metrics Specifications Operation Battery Installation Static Field Meter Ion Balance Measuring Two Point Resistance LED Indication Guide Calibration Parts Included List Service and Warranty... -
Page 3: Description Efm115
Compliance Verification ESD TR53 and conforms to ANSI/EOS/ESD (S4.1, S7.1, S12.1, S2.1). Ohm Metrics test and measurement products, from Transforming Technologies, are useful, reliable tools for characterizing and identifying the electrical resistance of materials and the performance of personal grounding products. -
Page 4: Ion Balance
The EFM115 features: Easy to read, easy to use operations Lightweight, compact design Range light assures accurate and repeatable measure- ments Automatic range switching up to ±20kV (20,000V) at 1" (25mm) Digital and bar graph display ... -
Page 5: Power Requirements
Power Requirements The EFM115 uses a 9V, 6F22Y Manganese battery and has a life of about 30 hours. The life of the battery is displayed on the LED front panel, with a battery icon that changes in 4 stages: Full 3/4ths Replace Battery... - Page 6 EFM115 Front Panel Sensor for Determining Electrostatic charge levels Charge plate for ion balance is built in. Focus-Ring LED lights Ground unit prop- erly prior to use to ensure accuracy The below message appears during sensor failure Four color coded buttons to switch Measurement modes...
- Page 7 Operation: Four Button Interface The EFM115 has four push buttons: Power (Red) Ion Bal- ance (Blue) Hold (Yellow) and Reset (Orange). The but- tons operate by pressing once lightly. Note: Do not push the buttons with excessive force or repeatedly. The effective life may be decreased by re- peated misuse.
- Page 8 Mode" and resume testing, press the Hold button once more. The Orange Reset button sets the meter to a zero charge. Note: The Reset button is inoperative in "Hold Mode". Proper Measurement Distance The EFM115 is equipped with two "Focus Rings" that are beamed from the front of the meter in ensure proper measuring distance.
- Page 9 Operation: Field Meter 1. The field meter must be grounded properly with the ground lead provided. 2. Press the Power Button once to activate the meter. A single beep will indicate proper operation. 3. The meter reading should be zero (0). Use the Reset button if it is not.
- Page 10 The EFM115 is calibrated for the voltage range 0 to + 20kV. The meter displays results in Kilovolts (kV). 1 kV = 1000 volts (V). A display of (+) or (-) next to the numerical results represents the polarity of the static charge.
- Page 11 5. Turn the meter towards an uncharged surface. The meter reading should be zero (0). Press the Reset button is it is not. 6. Hold the meter centered in front of the ionizer at any convenient repeatable distance, such as one foot.
-
Page 12: Service And Warranty
(after evaluating, repairing or replacing) any product returned to Transforming Technologies. The company does not warrant damage due to misuse, neglect, alteration or accident. In no event shall Transforming Technologies be liable for collateral or consequential damages. To receive service under warranty, please contact Trans- forming Technologies Technical Support.
