Transforming Technologies GTS600 Instruction Manual

Wrist strap & footwear combination tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
T R A N S F O R M I N G
O
U
T
S
T
Ohm Metrics™
Wrist Strap & Footwear Combination Tester
GTS600
Instruction Manual
T E C H N O L O G I E S ,
A
N
D
I
N
G
A
L
T
E
R
N
A
T
I
V
E
S
I
N
S
T
A
T
I
C
C
O
N
T
L L C
R
O
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTS600 and is the answer not in the manual?

Questions and answers

Related Manuals for Transforming Technologies GTS600

Summary of Contents for Transforming Technologies GTS600

  • Page 1 T R A N S F O R M I N G T E C H N O L O G I E S , L L C Ohm Metrics™ Wrist Strap & Footwear Combination Tester GTS600 Instruction Manual...

  • Page 2: Table Of Contents

    Contents Description GTS 600 Installation Battery Installation Stationary Installation Freestanding Installation Testing Wrist Strap Footwear Calibration Parts Included List Specifications Service and Warranty...
  • Page 3 ESD ground devices. The dual test circuits in the GTS600 gives the option for both wrist strap and footwear testing and a positive rocker switch makes test mode selection easy.

  • Page 4: Battery Installation

    When the LED lights, stop testing and replace with fully charged 9v battery. Stationary Installation The GTS600 has two options for installation: Stationary in- stallation or Free-standing installation with optional foot- plate and stand.

  • Page 5: Freestanding Installation

    1/4” Figure 1. Mounting Hole Location Figure2: Mounting Screw Location on wall Free Standing Installation NOTE: Free standing installation requires Model: GTS600FP or GTS600k. The Rugged stainless steel footplate and pedestal allows for both footwear and wrist strap testing in a free standing moveable unit.

  • Page 6: Testing

    Testing The GTS600 safely tests for proper ESD protection. The GTS600 can function as solely a wrist strap tester or in combination with the GTS600FT as duel wrist strap and foot wear tester. Wrist Strap Testing 1.

  • Page 7: Footwear

    Figure 2. Wrist Strap testing with foot plate Footwear Testing In order to test footwear you will need the GTS600 and GST600FT or the GST600K. For the following testing, one must be wearing foot grounding ESD protection. 1. Press rocker switch to “FOOTPLATE”...
  • Page 8 Footwear Testing Cont. 3. Press the test button and hold for 2-3 seconds 4. The green LED labeled “PASS” indicates that the foot ground is functioning properly. 5. If either the yellow LED “FAIL LO” or the red LED “FAIL HI” light and audible alarm sound, then check the foot ground set immediately.

  • Page 9: Calibration

    CALIBRATION AND PERIODIC TESTING: The GTS600 is calibrated to NIST traceable standards. We recommend that calibration is performed annually to en- sure proper testing standards. Due to duel testing circuits, both test circuits must be calibrated individually. Trans- forming Technologies offers a calibration unit CAL1000 to perform these tasks.

  • Page 10: Parts Included List

    GTS600FT Weight 15lbs Dimensions 19.75” x 16” x 2” Parts Included List GTS600k 1. GTS600 tester. 2. GTS600FT foot plate. 3. AC adapter 4. 2 piece pedestal. 5. Connection cord for pedestal. 6. Connection cord for Foot plate. GTS600 only 1.

  • Page 11: Service And Warranty

    Transforming Technologies. The company does not war- rant damage due to misuse, neglect, alteration or acci- dent. In no event shall Transforming Technologies be li- able for collateral or consequential damages. To receive service under warranty, please contact Transforming Technologies Technical Support.
  • Page 12 3719 King Rd | Toledo, OH 43617 | P: 419-841-9552 | F: 419-841-3241 | info@transforming-technologies.com...
