Summary of Contents for eHome EH102
-
Page 2: System Requirements
802.11g or 802.11b wireless adapter (for Ad-Hoc networking mode.) Package Contents Manual, software, and eHome EH102 warranty on CD Wireless PCI Card If any of the above items are missing, please contact your reseller. eHome EH10 Quick Install Guide... -
Page 3: Hardware Overview
Hardware Overview WLAN LED A solid light indicates that wireless is ready. This LED blinks during wireless data transmission. eHome EH10 Quick Install Guide... -
Page 4: Installation Considerations
Installation Considerations The eHome wireless adapter lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. -
Page 5: Adapter Installation
CD. Turn off your computer and unplug the power cord from the computer. Open the case and insert the eHome adapter into an available PCI slot. Once inserted, close the case and insert the power cable into the computer. - Page 6 Click Next to continue. By default setup will install to the default location: C:\Program Files\ eHome, where C: represents the drive letter of your hard drive. To install to a different location click Browse and specify the location.
- Page 7 You may manually enter the SSID or network name. Click Next to continue. Click on the network name (SSID) and click Connect. If there is a lock icon under Security, this means the network is encrypted (WEP, WPA, or WPA2). eHome EH10 Quick Install Guide...
- Page 8 (systray). If this icon appears GREEN, then you have successfully installed the EH102, are connected to a wireless network and are ready to communicate! eHome EH10 Quick Install Guide...
-
Page 9: Connect To A Wireless Network
The utility provides the user an easy interface to change any settings related to the wireless adapter. After you have completed the installation of the EH102 and whenever you start the computer, the Configuration Utility starts automatically and the system tray icon is loaded in the toolbar. - Page 10 Please refer to the manual on the CD for more information on Wireless Security. If the network you are connecting to is using WEP or WPA/WPA2, enter the key or passphrase for the network and click OK. eHome EH10 Quick Install Guide...
- Page 11 Notes eHome EH10 Quick Install Guide...
-
Page 12: Technical Support
Version 1.0 August 7, 2006 Copyright ©00 D-Link Corporation/D-Link Systems, Inc. All rights reserved. eHome Networking and the eHome Networking logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners. Maximum wireless signal rate based on IEEE Standard 0.11g specifications. Actual data throughput will vary.
