Agri-Fab
OWNERS
MANUAL
Model No.
45-0358
CAUTION:
Read Rules for
Safe Operation
and Instructions
WMV-
Digitally signed by WMV-Dresden
PRINTED IN USA
DN: cn=WMV-Dresden, c=DE,
o=WMV-Dresden,
Dresden
email=noreply@wmv-dresden.de
Date: 2017.01.26 13:00:41 +01'00'
¨
BOX SCRAPER ATTACHMENT
Carefully
• Safety
• Assembly
• Operation
• Maintenance
• Parts
the fastest way to purchase parts www.speedepart.com
(FOR 45-0354 GRADER BLADE)
FORM NO. 48972 (REV. 3/04)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Agri-Fab 45-0358
Summary of Contents for Agri-Fab 45-0358
- Page 1 ¨ Agri-Fab OWNERS MANUAL Model No. 45-0358 BOX SCRAPER ATTACHMENT (FOR 45-0354 GRADER BLADE) CAUTION: Read Rules for Safe Operation and Instructions Carefully • Safety • Assembly • Operation • Maintenance • Parts the fastest way to purchase parts www.speedepart.com...
- Page 2 SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. CAUTION: VEHICLE BRAKING AND LOOK FOR THIS SYMBOL TO POINT OUT STABILITY MAY BE AFFECTED BY THE IMPORTANT SAFETY PRECAUTIONS.
- Page 3 PARTS PACKAGE CONTENTS – PARTS SHOWN ACTUAL SIZE QTY. DESCRIPTION QTY. DESCRIPTION Hex Bolt, 1/2" x 4" Lg. Hex Nut, Nylock, 3/8" Hex Nut, Nylock, 1/2" Hex Bolt, 3/8" x 1" Lg. Clevis Pin Haircotter Pin...
- Page 4 2. Connect the brace located on top of the box scraper ASSEMBLY to the mast assembly using a 1/2" x 4" hex bolt and 1/2" Nylock hex nut. Tighten all nuts now. See figure 2. TOOLS REQUIRED FOR ASSEMBLY (2) 3/4" Wrenches MAST (1) 9/16"...
- Page 5 4. Remove the pivot pin and the slotted hex nut from 1. Before starting, make sure the material to be the mast assembly as shown in figure 4. Attach moved or conditioned is dry enough by squeezing the weight tray to the end of the mast assembly some in your hand.
- Page 7 REPAIR PARTS FOR MODEL NO. 45-0358 BOX SCRAPER ATTACHMENT REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 47134 Haircotter Pin, 25193 Weight Tray 0.08" x 1.58" Lg. 43001 Hex Bolt, 3/8" x 1" Lg. 44049 Clevis Pin, 1/2" x 1-1/4" Lg.
- Page 8 REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 www.agri-fab.com © 2004 Agri-Fab, Inc.
