Acclaim USB Camera Installation
Required materials:
•
A/T Acclaim drivers CD
•
A/T Acclaim camera and
control box
•
USB cable
•
Power cable
•
Game port cable
NOTE: The Air Techniques Acclaim Camera is only supported on Windows 2000 and
Windows XP Professional with Patterson Eaglesoft software.
NOTE: The Air Techniques Acclaim Camera is only supported on USB 2.0. NOTE: DIRECT X
version 9.0 has to be loaded for Windows.
**WINDOWS XP INSTRUCTIONS** (Windows 2000 begins with step 20)
1.
Insert the A/T Acclaim Drivers CD into the CDROM.
2.
Click Exit.
3.
Attach the camera to the control box with the camera cable.
4.
Plug the power supply for the camera into the control box and then into the outlet.
5.
Connect the USB cable to the control box then plug into the USB port on the
computer. The Add New Hardware Wizard will appear.
Printed copies of this document are considered uncontrolled.
5240.4.Rev001
02.02.2017
Required Eaglesoft
Install on the following computers:
modules:
•
•
Video Capture
1
Any operatory workstation using the
Acclaim

Advertisement

loading
Need help?

Need help?

Do you have a question about the Acclaim USB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Air Techniques Acclaim USB

Summary of Contents for Air Techniques Acclaim USB

  • Page 1 NOTE: The Air Techniques Acclaim Camera is only supported on Windows 2000 and Windows XP Professional with Patterson Eaglesoft software. NOTE: The Air Techniques Acclaim Camera is only supported on USB 2.0. NOTE: DIRECT X version 9.0 has to be loaded for Windows.
  • Page 2 Mark the option Install the software automatically (recommended). Click Next. If the Logo Testing message should appear, click Continue Anyway to complete the installation. Printed copies of this document are considered uncontrolled. 5240.4.Rev001 02.02.2017...
  • Page 3 Click Finish (to close the Add New Hardware Wizard). Verify the driver has been loaded correctly through Device Manager. To access Device Manager, go to: • Start | Settings | Control Panel. Double-click on the System icon. • Choose the Hardware tab. •...
  • Page 4 To activate the buttons on the Acclaim hand piece, connect the serial game port cable to the back of the camera control box (port labeled PC) and then to the game port on the computer. Go to Start | Settings | Control Panel. Double-click on the Gaming Options icon. Click Add.
  • Page 5 You should now have a listing for 2-axis, 2-button joystick with a status of OK. To test the buttons on the camera, highlight the joystick listing and click Properties. Press and release the top button on the camera. The red indicator to the left should illuminate.
  • Page 6 Press and release the bottom button on the camera. The red indicator to the right should illuminate. Click OK (to exit Gaming Options). Printed copies of this document are considered uncontrolled. 5240.4.Rev001 02.02.2017...
  • Page 7 **WINDOWS 2000 INSTRUCTIONS** Insert the A/T Acclaim Drivers CD into the CDROM. Click Exit. Attach the camera to the control box with the camera cable. Plug the power supply for the camera into the control box and then into the outlet. Connect the USB cable to the control box then plug into the USB port on the computer.
  • Page 8 Mark the option Search for a suitable driver for my device (recommended). Click Next. Check the box for CD-ROM drives. Click Next. Printed copies of this document are considered uncontrolled. 5240.4.Rev001 02.02.2017...
  • Page 9 The wizard should find the device under ?\device drivers\at slc usb camera.inf. Click Next. If the Digital Signature message should appear, click Yes (to complete the installation). If the Digital Signature message should appear, click Yes to complete the installation. Click Finish (to close the Add New Hardware Wizard).
  • Page 10 Verify the driver has been loaded correctly through Device Manager. To access Device Manager, go to: • Start | Settings | Control Panel. Double-click on the System icon. • Choose the Hardware tab. • Click on the Device Manager button. A/T SLC USB Camera will appear under Imaging Device.
  • Page 11 Highlight the option for 2-axis, 2-button joystick. Click OK. Printed copies of this document are considered uncontrolled. 5240.4.Rev001 02.02.2017...
  • Page 12 You should now have a listing for 2-axis, 2-button joystick with a status of OK. To test the buttons on the camera, highlight the joystick listing and click Properties. Press and release the top button on the camera. The red indicator to the left should illuminate.
  • Page 13 Press and release the bottom button on the camera. The red indicator to the right should illuminate Click OK (to exit Gaming Options). Printed copies of this document are considered uncontrolled. 5240.4.Rev001 02.02.2017...
