Samsung DW-BG970B Setting Up

setting up your dishwasher
ConTroL PAnEL
1 pOWeR
pROGRAm
2
SeleCTOR
dISplAy
3
delAy START
4
4 in 1
5
STeRIlIZATION
6
1/2
7
plUS
8
12_ setting up your dishwasher
UserManual-DMS400TU_GB.indd 12
5 1
When pressed, all indicator lights turn on and off and the most recently
finished program light is lit.
When the dishwasher is running and a selected program has finished, 'En' is
displayed and the power turns off automatically.
You can select the appropriate wash program depending on the soil level of
your dishes. When a program is selected, the indicator for that program lights
up.
Displays the remaining wash time, the wash information (Delay start, Salt refill,
Rinse refill, Child lock), and error messages.
If an error occurs during an operation, an error message is displayed with a
warning sound. Refer to the information on page 28.
Use the delay Start button to preset the start time. The indicator changes
each time the button is pressed. The delay start time can be adjusted from 1
hour to 24hours.
If you want to use multi-functional detergent such as "2 in 1", "3 in 1", and
"4 in 1" detergent, select a program and then press this button. (The 4 in
1 function is only available when selecting the Normal, Eco, Pots & Pans,
Crystal and Quick programs.)
Though the "Rinse Refill" indicator is lit while the 4 in 1 function is activated,
you do not have to add rinse detergent to the rinse aid dispenser.
Press this button to use the sterilization function by increasing the heat by 80
degrees during the final rinse cycle.
This function is only available when selecting the Normal, Pots & Pans, Eco,
or Rinse Dry courses or the 4 in 1 function.
For small loads, only use the top or bottom basket to save energy. Pressing
the button cycles between selecting the top or bottom basket.
Use the plus button to add the drying and rinse cycles to the original course.
If the program has already started, this button is deactivated.
2
2010-06-13 9:33:37
