- Page 1 English Installation, use, maintenance manual DualSun FLASH v1.5 2020...
-
Page 2: Table Of Contents
Installation, use, maintenance manual DualSun FLASH Table of Contents 1. Introduction ..........................3 1.1. General safety instructions ....................3 1.2. General standards to be observed ..................3 1.2.1. Photovoltaic solar standards ..................3 2. General description ........................5 2.1. Technical characteristics ..................... 5 2.2. -
Page 3: Introduction
Please read this installation manual thoroughly and in detail in order to be able to fully exploit the functionality of the product. DualSun disclaims all liability for defetcs and damages that would result from non-compliance with the installation instructions (improper use, incorrect installation, handling error, etc.). - Page 4 Installation, use, maintenance manual DualSun FLASH • CEI / EN 61730 1 and 2: Qualification for dependability of photovoltaic (PV) modules - part 1: Requirements for construction and part 2: requirements for tests. The installation instructions and safety instructions must be met.
-
Page 5: General Description
Installation, use, maintenance manual DualSun FLASH 2. General description 2.1. Technical characteristics The technical characteristics of the DualSun panels can be found in the technical sheets published in our - online library 2.2. General recommendations 2.2.1. Handling DualSun modules should be handled like any glass product. To avoid accidents, injuries, or damage to the module during work, the following precautions must always be observed: •... -
Page 6: Static Roofing Requirements
DualSun suggests installing the modules in areas where the temperatures are between -20 ° C and + 50 ° C, which corresponds to the minimum and maximum monthly average temperatures, in accordance with IEC 60364-5-51. -
Page 7: Types Of Mounting
2.3.6. Protection against fire / explosion Do not install the DualSun modules in the vicinity of highly flammable gases, vapours, or dust (e.g., next to a gas station or containers). The national and local fire prevention standards and regulations must be respected during installation. -
Page 8: Mechanical Installation
DualSun panels can be installed both in portrait and in landscape. DualSun does not provide the mounting system for fastening the modules on the roof: please refer to the instal- lation instructions of the chosen mounting system, to install the modules whether for an integrated or for a su- perimposed installation, in landscape or portrait. - Page 9 IMPORTANT It is important to make sure that the clamping brackets do not distort the top of the aluminium frame of the DualSun panel, this may weaken or even break the glass. CAUTION The tightening torque of the clamps must not exceed 24 N.m.
-
Page 10: Assembly Specifications
Installation, use, maintenance manual DualSun FLASH 3.2. Assembly specifications Installation areas on the rails of the mounting system [10] 3.2.1. Installation areas on the rails of the mounting system Fixing zones on the installation system Up to 2400 Pa Up to 5400 Pa... -
Page 11: Electrical Installation
Installation, use, maintenance manual DualSun FLASH 4. Electrical Installation Electrical connection [11] Electrical fittings, cables and diodes [12] Grounding and lightning protection [14] Indirect lightning strike [14] 4.1. Electrical connection The nominal electrical parameters Icc, Vco and Pmax of the modules are determined under standard test con- ditions STC (standard testing condition): illumination of 1000 W/m²... -
Page 12: Electrical Fittings, Cables And Diodes
3 mm at the contact level. 4.2. Electrical fittings, cables and diodes The DualSun solar modules are supplied with cables, connectors, and a pre-equipped junction box. Before in- stallation, check that the plugs and connections are not damaged. - Page 13 Never open the junction box The junction box of the DualSun module contains bypass diodes which are in parallel connection with the cell wires. If a hot spot occurs locally on one or more cells, the diode will enter into service to prevent the main current from flowing through the hot cells in order to limit overheating and loss of performance of the module.
-
Page 14: Grounding And Lightning Protection
It is imperative to refer to the local reg- ulations in force to comply with specific requirements DualSun modules must be grounded with prongs, lugs or other suitable means. Grounding can be done through the holes made for this purpose as part of each module. - Page 15 Installation, use, maintenance manual DualSun FLASH electrical cable loops must be avoided and the surface between the cables must be as small as possible, as can be seen in the graph below:...
-
Page 16: Cleaning The Surface Of The Modules
Installation, use, maintenance manual DualSun FLASH 5. Cleaning the surface of the modules The greater the degree of contamination of the surface of the PV system, the less the cells are able to absorb the energy contained in the incident sunlight. -
Page 17: Decommissioning Of The Installation
Separate the module from its support. • Disconnect the electrical connectors. • Disconnect the module grounding. 6.2. Waste treatment When handling waste from a used DualSun system, the applicable regional and national regulations must be observed. DualSun is a PV Cycle member. -
Page 18: Responsibilities
For the other components of the installation, see the warranty conditions of the various manufacturers. 7.2. Disclaimer DualSun cannot be held liable in the following cases: • Failure to comply with the instructions contained in the Notice concerning the installation, use, operation and maintenance of the installation.
