Digi Neo Hardware Installation Manual

Pin Assignments
DB-25 and DB-9 Pin Assignments
Signal Description DB-25 Pin
GND Chassis Ground Shell
TxD Transmitted Data 2
RxD Received Data 3
RTS Request To Send 4
CTS Clear To Send 5
DSR Data Set Ready 6
SG Signal Ground 7
DCD Data Carrier Detect 8
DTR Data Terminal Ready 20
RI Ring Indicator 22
RJ-45 Pin Assignments for 10-Pin and 8-Pin RJ-45
Connectors
Signal Description Pin # (of 10) Pin # (of 8)
RI Ring Indicator 1
DSR Data Set Ready 2†
RTS Request To Send 3
GND Chassis Ground 4
TxD Transmitted Data 5
RxD Received Data
6
SG Signal Ground 7
CTS Clear To Send 8
DTR Data Terminal Ready 9
DCD Data Carrier Detect 10
† DSR (Pin 2 on a 10 pin connector, Pin 1 on an 8 pin
connector) can be swapped with DCD by using the ALTPIN
configuration option. ALTPIN reverses the position of these two
signals in 10 pin connectors and allows DCD to be used instead
of DSR on an 8 pin connector.
Consult the driver documentation for how to do this in your
specific operating system.
Refer to the Access Resource CD for more detailed cabling information.
DB-9 Pin
Shell
3
2
7
8
6
5
1
4
9
N/A
1†
2
3
4
5
6
7
8
N/A
Digi, the Digi logo, AccelePort and Digi Neo are trademarks or registered trademarks of
Digi International in the United States and other countries. All other brand and product
names are trademarks of their respective holders.
© Digi International Inc., 2001 All Rights Reserved; www.digi.com
Information in this document is subject to change without notice and does not represent a
commitment on the part of Digi International.
Digi provides this document "as is," without warranty of any kind, either expressed or
implied, including, but not limited to, the implied warranties of fitness or merchantability
for a particular purpose. Digi may make improvements and/or changes in this manual or in
the product(s) and/or the program(s) described in this manual at any time.
This product could include technical inaccuracies or typographical errors. Changes are peri-
odically made to the information herein; these changes may be incorporated in new editions
of the publication.
91001071 Rev A
Hardware Installation
Introduction
™
A Digi Neo adapter easily expands the number of EIA-232 ports avail-
able on your computer, allowing you to cable additional peripheral
devices, such as modems, terminals or serial printers, directly to your
computer.
Digi Neo adapters are equipped with an HD-68 connector to which a spe-
cial Digi connector assembly is attached to provide the peripheral port
connections. There are seven different connector assembly options avail-
able to use with Digi Neo 4 and Neo 8 adapters:
• RJ-45 Connector Box
• DB-25 Connector Box (male connectors)
• DB-9 Connector Box (male connectors)
• DB-25 Fan-out Cable (male or female connectors)
• DB-9 Fan-out Cable (male or female connectors)
This installation guide describes how to plan your setup and install a Digi
Neo adapter.
Digi Neo
PCI Host Adapters
EIA-232
Guide
