Task Force Tips Twister Instructions For Installation, Safe Operation And Maintenance page 3

WARNING
CAUTION
CAUTION
CAUTION
CAUTION
2.0 GENERAL INFORMATION
The Task Force Tips Twister and Bubblecup nozzles are hand-held nozzles with clean far reaching straight stream. They are
adjustable from straight stream to a wide fog pattern. Their rugged construction is compatible with the use of fresh water as well as
fi re fi ghting foam solutions. The nozzles are constructed of hard anodizes aluminum, stainless steel, rubber and engineering grade
polymers. A summary of each nozzle's characteristics is shown in the tables below.
WARNING
2.1 VARIOUS MODELS
SERIES
C
D
D
F
F
F
The C series Twister is available in a tip-only nozzle confi guration. The D and F Series Twisters and Bubble Cups
NH (National Hose Threads per NFPA #1963) threads are standard on all nozzles. Other threads such as NPSH (National Pipe
Straight Hose threads per ANSI/ASME #B1.20.7) can be specifi ed at time of order.
©Copyright Task Force Tips, Inc. 2002 - 2010
Water is a conductor of electricity. Application of water solutions on high voltage equipment
can cause injury or death by electrocution. The amount of current that may be carried back to
the nozzle will depend on the following factors:
• Voltage of the line or equipment
• Distance from the nozzle to the line or equipment
• Size of the stream
• Whether the stream is solid or broken
• Purity of the water 2
1 Electrostatic Hazards of Foam Blanketing Operations by Peter Howels. Industrial Fire Safety July/August 1993
2
The Fire Fighter and Electrical Equipment,
The University of Michigan Extension Service, Fourth Printing 1983. Page 47.
Fire streams are capable of injury and damage. Do not direct water stream to cause injury or
damage to persons or property.
Do not couple aluminum to brass. Dissimilar metals coupled together can cause galvanic
corrosion that can result in inability to unscrew threads or complete loss of thread
engagement.
The nozzle may become damaged if allowed to freeze while containing water. Always drain
after use to avoid damage and possible loss of use.
Nozzle must be mated to a hose line with matched threads. Mismatched or damaged threads
may cause nozzle to leak or uncouple from hose under pressure and could cause injury.
This equipment is intended for use by trained personnel for fi refi ghting. Their use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
MODEL
TWISTER
TWISTER or BUBBLECUP
TWISTER or BUBBLECUP
TWISTER or BUBBLECUP
TWISTER
BUBBLECUP
are available in tip-only, ball-valve, or ball-valve with pistol grip confi gurations.
1
STANDARD GALLONAGE SETTINGS
COUPLING SIZE
3/4 GHT
1 NH
1 NH
1-1/2 NH
1-1/2 NH
1-1/2 NH 95 Single Gallonage Only
3
(GPM AT 100 PSI)
10, 24
10, 24
10, 40
20, 60
20, 95
LKB-100 January 18, 2009 Rev9
