Operation; Power Up; Preparation - DTronics DT-01 User Manual

2 OPERATION

POWER UP

► Turn the D-50 on first, then the DT-01.
The Common Parameter of the Tone(s) whose indicator is lit can be
edited. Each time the button is pushed, the indicator alternately comes
on and goes out.

PREPARATION

►Before using the DT-01, take the following 2 steps
Step 1 – set MIDI channel
Set the D-50's basic channel to the same number as the MIDI channel of
the DT-01.
The DT-01 defaults to channel number 1 at power up.
The DT-01 MIDI channel can be changed to other number than 1.
Hold MIDI Channel button and press the channel button you want.
For channel 1 to 10: press buttons 1 to 10
For channel 12: press button 10 and then button 2
(See Figure 1)
