DuraTech™ 6' Mini Single/Twin Self Retracting Device
This manual is intended to meet the Manufacturer's Instructions as required by the American National Standards
Institute (ANSI) Z359 and should be used as part of an employee training program as required by the Occupational
Safety and Health Act (OSHA).
This product is part of a personal fall arrest, restraint, work positioning, suspension, or rescue system. A Personal Fall
Arrest System (PFAS) is typically composed of an anchorage and a Full Body Harness (FBH), with a connecting device,
i.e., a Shock Absorbing Lanyard (SAL), or a Self-Retracting Device (SRD), attached to the dorsal D-ring of the FBH.
These instructions must be provided to the worker of this equipment. The worker must read and understand the
manufacturer's instructions for each component or part of the complete system. Manufacturer's instructions must be
followed for proper use, care, and maintenance of this product. These instructions must be retained and be kept
available for the worker's reference at all times. Alterations or misuse of this product, or failure to follow
A Fall Protection Plan must be on file and available for review by all workers. It is the responsibility of the worker and
the purchaser of this equipment to assure that workers of this equipment are properly trained in its use,
maintenance, and storage. Training must be repeated at regular intervals. Training must not subject the trainee to fall
Consult a doctor if there is reason to doubt your fitness to safely absorb the shock of a fall event. Age and fitness
seriously affect a worker's ability to withstand falls. Pregnant women or minors must not use this equipment.
User Instruction Manual
WARNING
instructions, may result in serious injury or death.
hazards.
NOTE: For more information consult ANSI Z359
FallTech
1306 South Alameda Street
Compton, CA 90221, USA
1-800-719-4619
1-323-752-0066
www.FallTech .com
MSRD07 Rev D
010819
Advertisement
Related Manuals for Falltech DuraTech 6 Mini
Summary of Contents for Falltech DuraTech 6 Mini
- Page 1 Pregnant women or minors must not use this equipment. NOTE: For more information consult ANSI Z359 FallTech 1306 South Alameda Street Compton, CA 90221, USA 1-800-719-4619 1-323-752-0066 www.FallTech .com MSRD07 Rev D 010819...
- Page 2 4.4 Swing Fall and Expanded Work Zone 1. DESCRIPTION The FallTech® DuraTech™ 6' Mini Single/Twin SRD is a self-retracting lifeline for those working at height and subject to fall hazards. The DuraTech 6' Web Mini Single/Twin SRD This manual contains two Appendices, Appendix A and Appendix B. Appendix A contains figures and tables specific to the SRD discussed in this manual.
- Page 3 Contact FallTech if you have any questions about compatibility. Connectors must be compatible with the anchorage or other system components.
- Page 4 All anchoring situations present different clearance values, performance characteristics, and requirements. Table 4 provides typical performance attributes of a FallTech DuraTech 6' Mini Single/Twin SRD, for workers up to a maximum total weight of 310 lbs, for both overhead and non-overhead anchor attachment. See paragraph 3.5.1. The qualified person may find this data useful in determining anchor location.
- Page 5 4.7 Impact Indicator: The shock absorber is the fall arrest impact indicator for this unit. Torn stitching, expansion or lengthening, of the shock absorber is an indication that a fall event has occurred. If you have any questions contact FallTech.
- Page 6 7.5 Inspection Document: Record inspection results on the Inspection Record provided in Appendix B, or on a similar document. 8. LABELS The labels must be present and legible. FallTech READ AND FOLLOW INSTRUCTIONS SUPPLIED WITH Style # 72706SB1 PRODUCT AT THE TIME OF SHIPMENT. REFER TO ANSI Z359.14...
- Page 7 La edad y el estado físico afectan gravemente a la capacidad de los trabajadores para soportar caídas. Las mujeres embarazadas y los menores de edad no deben utilizar este equipo. NOTA: Para obtener más información, consulte ANSI Z359 FallTech 1306 South Alameda Street Compton, CA 90221, USA...
- Page 8 1. DESCRIPCIÓN El Mini dispositivo autorretráctil doble/individual DuraTech™ de FallTech® de 6 pies (1,8 m) es una cuerda de salvamento auto-retráctil para personas que trabajan en alturas y están sujetas a peligros de caídas. El Mini dispositivo autorretráctil doble/individual DuraTech de 6 pies (1,8 m) Este manual contiene dos apéndices, el Apéndice A y el Apéndice B.
- Page 9 Los conectores deben ser compatibles en tamaño, forma y resistencia. Los mosquetones y ganchos de cierre y bloqueo automático son requeridos por ANSI Z359.12 y la OSHA. FallTech ofrece una amplia variedad de conectores para usar con el SRD de 6 pies (3,04 m).
- Page 10 La Tabla 4 ofrece los atributos de rendimiento típico de un Mini dispositivo autorretráctil doble/individual DuraTech de FallTech de 6 pies (1,8 m), para los trabajadores hasta un peso máximo total de 310 libras (140,6 kg), tanto para las conexiones de anclajes por encima del nivel de la cabeza o que no estén por encima del nivel de la cabeza.
- Page 11 D = Es el sub-total de A – C. Si el anclaje está directamente por encima del nivel de la cabeza, no hay un componente de caída con balanceo en este cálculo, y D es la MRFC sin una condición de caída con balanceo. E = Si existe una condición de caída con balanceo, el parámetro E se factoriza en la misma.
- Page 12 4.7 Indicador de impacto: El amortiguador es el indicador del impacto de la detención de caídas para esta unidad. Las costuras rotas, la expansión o ampliación del amortiguador es una indicación de que ha ocurrido un evento de caída. Si tiene alguna pregunta, póngase en contacto con FallTech.
- Page 13 7.5 Documento de la inspección: Registre los resultados de la inspección en el Registro de inspección que se encuentra en el Apéndice B, o en un documento similar. 8. ETIQUETAS Las etiquetas deben estar presentes y legibles. FallTech LEA Y SIGA LAS INSTRUCCIONES SUMINISTRADAS Estilo # 72706SB1 CON ESTE PRODUCTO EN EL MOMENTO DE LA ANSI Z359.14...
- Page 14 APPENDIX A Table 1A: Specifications for 6ft Mini Web SRDs Minimum Maximum Standards and SRD Configuration Tensile Strength 6’ Mini Web SRD and Part Numbers User Capacity Regulations and Material Single-leg SRDs: 72706SA1 72760SA2 72706SA3 72760SA4 Webbing: 72706SA5 72706SA6 6,100 lbs 72706SB1 72706SB2 100% Dyneema 19mm width...
- Page 15 Table 1B: Specifications for Single-leg Swivel Eye Connectors Housing Swivel Eye Connector Connector Material Gate Opening Part # Reference All Anchorage Connectors shown below have 5,000 lb Minimum Tensile Strength and 3,600 lb minimum Gate Strength to comply with ANSI Z359.12 Eye: Integral Housing Swivel Eye only Steel...
- Page 16 Tabla 1B: Especificaciones para conectores con ojal de oscilación individual Apertura del Referencia de No. de Conector con ojal de oscilación de Conector Material parte carcasa pestillo Todos los conectores del anclaje que se muestran abajo tienen una resistencia mínima a la tensión de 5.000 libras (2.268 kg) y una resistencia mínima en el pestillo de 3.600 libras (1.634 kg) para cumplir con ANSI Z359.12 Sólo ojal de oscilación...
- Page 17 Table 1C: Specifications for SRD Leg-end Connectors Part # Gate Leg-End Connector Connector Material Reference Opening All Anchorage Connectors shown below have 5,000lb Minimum Tensile Strength and 3,600lb minimum Gate Strength to comply with ANSI Z359.12 Snap Hook Steel .85” Swivel Snap Hook .85”...
- Page 18 Table 1D: Mini SRD Part Numbers with Connector Reference Housing Swivel Eye Connectors Leg-End Connectors Retracted Extended Weight Single-leg Part #s Length Each Lbs Length 72706SA1 17” 6’ 0” 72706SA2 19” 6’ 2” 72706SA3 21” 6’ 4” 72706SA4 17” 6’ 0” 72706SA5 21”...
- Page 19 Tabla 1D: Números de partes del Mini SRD con referencia del conector Conectores con ojal con eslabón de carcasa Conectores del extremo de las piernas Longitud Longitud Peso No. de partes extendida libras (kg) retraída individuales 72706SA1 17” (43,2 cm) 6’...
- Page 20 Table 2: ANSI Z359.14 SRD Inspection Requirements Application Inspection Frequency Type of Use Conditions of Use Examples Competent Person Good Storage Conditions, Rescue and Confined Indoor or Infrequent Outdoor Space, Factory Infrequent to Light Annually Use, Room Temperature, Clean Maintenance Environments Fair Storage Conditions, Indoor Transportation,...
- Page 21 Table 3: Guidelines for SRD Inspection (use Figure 1 where needed) Inspection Pass Fail The web lifeline should extract and retract completely and without faltering and should remain taut under tension without sagging. Extract the web lifeline several inches and apply a firm pull to confirm the SRD locks.
- Page 22 Table 4: 6’ Mini Web SRD Performance Attributes 6’ Mini SRD Class B ANSI Required Typical FallTech Part #72706SA4 used in both Performance Attributes - Class B Performance Attributes User Conditions below Average Average Maximum User Arrest Arrest Maximum Arrest Force...
- Page 23 Figure 1: About 6’ Mini Web SRDs Integral Swivel Eye Triple-lock Carabiner Unit Housing Carabiner Body Web Lifeline Alignment Clip Energy Absorber Triple-lock Gate Leg-end Connector Integral Stirrup Connector *Stirrup Connector on some single-leg models only; see Table 1B Figura 1: Acerca de los Mini SRD con correa de 6 pies (1,8 m) Ojal de oscilación integral Mosquetón de bloqueo triple Carcasa de la unidad...
- Page 24 6’ Mini Single-leg mounted to Dorsal D-ring Figure 2A: 6’ Mini Orientation and Acceptable Anchorage Range Shaded area indicates Range of Allowable Connection from: Directly Overhead to as low as 5’ Below Dorsal D-ring for 310 lb User 6’ Mini Single-leg mounted to Anchorage Figure 2B: 6’...
- Page 25 Mini SRD de 6 pies (1,8 m) montado en anillo en “D” dorsal Figura 2A: Orientación del Mini SRD de 6 pies (1,8 m) y rango aceptable del anclaje el área sombreada indica el Rango permisible de conexión desde: Directamente por encima de la cabeza a tan bajo como a 5 pies (1,5 m) por debajo del anillo en ”D”...
- Page 26 310 lbs Maximum User Capacity Overhead Anchorage Figure 3A: 6’ Mini SRD Minimum Required Fall Clearance 2½ ft SRD Deceleration Distance 1 ft D-ring shift and harness stretch 1½ ft Safety factor Sub Total- Minimum Required Fall Clearance- 5 ft for direct overhead use of SRD with No Swing Fall (sum of A, B and C only) *Additional Fall Clearance Calculation due to Swing Fall...
- Page 27 Anclaje por encima del nivel de la cabeza Capacidad máxima del usuario de 310 libras (140,6 kg) Figura 3A: Distancia mínima de caída despejada requerida para Mini SRD de 6 pies (1,8 m) 2½ pies Distancia de desaceleración del SRD (0,8 m) 1 pie Cambio del anillo en “D”...
- Page 28 Figure 5A: Swing Fall Hazards Overhead Anchorage Overhead Anchorage 6’ Single-leg Self-Retracting Device Walking/Working Surface Swing Fall Impact after fall event Next Lower Level or Obstruction See Chart 1 for additional Swing Fall hazard due to increased Fall Distance Figura 5A: Peligros de caída con balanceo con anclaje porencima del nivel de la cabeza Anclaje por encima del nivel de la cabeza Dispositivo autorretráctil individual de 6 pies (1,8 m)
- Page 29 Chart 1: Additional Required Fall Clearance Due to Swing Fall (ft) Limited to 310 lb Max User Weight 6’ 6’ 6’ 6’ 6’ 6’ 0’ 0’ 0’ 6’ 6’ 6’ 6’ 6’ 6’ 6’ 6’ 1’ 0’ 0’ 0’ 0’ 0’...
- Page 30 Gráfico 1: Distancia despejada de caída adicional requerida debido a la caída con balanceo (pies/metros) Limitado al peso máximo del usuario de 310 libras (140,6 kg) 6’ 6’ 6’ 6’ 6’ 6’ 6’ 6’ 6’ 6’ 6 pies (1,8 0 pies 0 pies 0 pies 6’...
- Page 31 Figure 6A: Attaching Single-leg Mini to FBH Anchorage Leg End Connector External Shock Absorber Web Lifeline SRD Body/Housing SRD Integral Swivel Eye Carabiner Dorsal D-ring on FBH Figura 6A: Conectar un Mini SRD individual a un FBH Anclaje Conector del extremo de la pierna Amortiguador de energía externo Cuerda de salvamento Cuerpo/carcasa del SRD...
- Page 32 Figure 7A: Attaching 6’ Mini Twin-leg SRD to FBH 1. Prepare Twin-leg SRD for Attachment 2. Prepare FBH and Preliminary Attachment 2. Prepare FBH and Preliminary Attachment: (E) Lift the Dorsal D-ring to the up-pointing position then loosen the intersection of the two web straps that pass through the D-ring slot to create slacked loops of about 2”...
- Page 33 Figura 7A: Conectar un SRD doble de 6 pies (1,8 m) a un FBH 1. Preparar el SRD doble para la conexión 2. Prepare FBH and Preliminary Attachment 2. Preparación del FBH y conexión preliminar: (E) Levante el anillo en “D” dorsal hasta la posición de señalización hacia arriba, luego afloje la intersección de las dos correas que pasan por la ranura del anillo en “D”...
- Page 34 INCORRECT INCORRECT INCORRECT INCORRECT CORRECT Figure 7B: Incorrect Twin-leg SRD Attachment DO NOT Attach directly to the Dorsal D-ring DO NOT Attach to only one of the intersecting web straps DO NOT Attach to intersecting web straps over/above the Dorsal D-ring DO NOT Attach anywhere outside the intersecting web straps CORRECT attachment to both intersecting web straps with Dorsal D-ring in the up position...
- Page 35 Before Lateral Movement Starting Lateral Movement Momentary Transition Ending Lateral Movement After Lateral Movement Figure 8: Use of Twin-leg Mini SRD for Lateral Movement Orginal Work Location before lateral movement Starting lateral movement; one leg connected to Anchor During lateral move; both legs connected in momentary transition between Anchors Ending lateral movement;...
