7. Air Velocity and Temperature Distribution
 Heating
Side View
Discharge angle: 55°
Air velocity [m/s]
0.3
m 10 8
・Vertical Louver : Center
・Vertial Louver angle : 0˚
• Fan speed : High
Top View
Discharge angle: 55°
Air Velocity [m/s]
0.3
0.5
0.3
m
10 8
・Vertical Louver : Center
・Vertial Louver angle : 0˚
・Air speed 0.3m/s Range : 11.9m
• Fan speed : High
