MULTI V
Indoor Unit
2. Specifications
Model
Cooling Capacity
Heating Capacity
Power Input (H / M / L)
Dimensions(WxHxD)
Body
Rows × Columns × FPI
Coil
Face Area
Type
Motor Output × Number
Running Current
Fan
Air Flow Rate(H / M / L)
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Liquid Side
Pipe Connections
Gas Side
Drain Pipe(ID)
Net Weight
Sound Pressure Levels (H / M / L)
Sound Power Levels (H / M / L)
Power Supply
Refrigerant Control
Transmission cable
Color
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national code. And "Electric characteristics" chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound pressure level is measured on the rated condition in the anechoic rooms by ISO 3745 standard.
Sound power level is measured on the rated condition in the reverberation rooms by ISO 3741 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
4. Capacities are net capacities and based on the following conditions. Refer to the Outdoor Unit Specifications for calculating the real capacity.
• Cooling : Indoot Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Heating : Indoot Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is Zero.
10
Type
Unit
kW
kcal/h
Btu/h
kW
kcal/h
Btu/h
W
mm
inch
m²
W
A
m³/min
ft³/min
mm (inch)
mm (inch)
mm (inch)
kg (lbs)
dB(A)
dB(A)
Ø, V, Hz
mm²
Wall Mounted Unit
ARNU30GSVA4
8.8
7,500
30,000
9.4
8,100
32,000
54 / 43 / 31
1,190 × 346 × 265
46-27/32 × 13-5/8 × 10-7/16
2 × 18 × 19 + 1 × 6 × 19
0.34
Cross Flow Fan
113 × 1
0.51
23.0 / 20.0 / 17.0
812 / 706 / 600
Direct
BLDC
Microprocessor, Thermostat for cooling and heating
Foamed polystrene
Resin Net(washable)
Fuse
Ø9.52 (3/8)
Ø15.88 (5/8)
16 (5/8)
16.6 (35.6)
49 / 44 / 42
-
1, 220-240, 50
1, 220, 60
EEV
1.0 ~ 1.5 × 2C
White
Wall Mounted Unit (Standard)
ARNU36GSVA4
10.4
9,000
35,500
10.8
9,300
37,000
85 / 51 / 36
1,190 × 346 × 265
46-27/32 × 13-5/8 × 10-7/16
2 × 18 × 19 + 1 × 6 × 19
0.34
Cross Flow Fan
113 × 1
0.81
26.0 / 23.0 / 19.0
918 / 812 / 671
Direct
BLDC
Foamed polystrene
Resin Net(washable)
Fuse
Ø9.52 (3/8)
Ø15.88 (5/8)
16 (5/8)
16.6 (35.6)
52 / 47 / 43
-
1, 220-240, 50
1, 220, 60
EEV
1.0 ~ 1.5 × 2C
White
