- Page 1 MBK101 User & Installation Manual www.audac.eu...
- Page 2 Introduction Wall mounting bracket for Bass Cabinet The MBK101 is a mounting bracket that can be used to mount different kinds of bass cabinets with a limited size and weight. The simple, nevertheless very efficient principle provides an easy and quick installation.
- Page 3 Installation Step 1 Mount the cylindrical metal bushings to your bass cabinet using the included M6x25 bolts and washers, make sure the flat side of the cylindrical bushings rests against the bass cabinet while a washer sits flat inside the recessed side. Both cylindrical bushings must be mounted on the same horizontal height, and the mutual distance should be as large as possible.
- Page 4 N-shaped notch of the mounting bracket and then the cabinet is properly mounted and ready for use. Additional information Package content The MBK101 package contains following parts: - 2 pcs mounting bracket with N-shaped notch - 2 pcs cylindrical metal bushing - 1 pcs plastic stopper...
