- Page 1 ® Owner’s Manual Airgle Room Air Purifier (Model: AG500) ® Airgle Room Air Purifier (Model: AG600) ® Airgle Clean Room Air Purifier (Model: AG800) ® Airgle Clean Room Air Purifier (Model: AG900) ®...
- Page 2 • Disconnect the power supply from your air cleaner by unplugging the power cable before replacing filters, cleaning, movement, or maintenance. • Do not use attachments or filters not recommended by Airgle ® • Do not use the air cleaner outdoors.
- Page 3 Connecting to Power Airgle Components ® How the Airgle System Works ® Using the Control Panel Using the Remote Control Care and Maintenance of your Airgle Air Cleaning System ® Component List ® Titanium Pro Filter Carbon Filter HEPAfast Filter...
- Page 4 (VOCs). AG500 can effectively filter these toxic airborne pollutants, along with dust, pollen, pet dander, smoke and haze. AG800 is most effective for those experiencing multiple or severe chemical allergies. With more activated carbon in the Gas &...
- Page 5 Its large filter is also economically beneficial, extending the service life of the machine, and the Airgle ®...
- Page 6 • High oxidation yields for gas phase reactants and odors. • Low energy requirements. • Works in humid conditions. • Long service life. The Airgle AG500/AG800 Air Cleaning Systems ® Airgle ® (AG500/AG800) is designed with: 1) A Gas & Odor filter 2) A HEPAfast filter Effectively filters airborne dust and particulate matter;...
- Page 7 Decomposition of formaldehyde, toluene and other decoration pollutants. Efficient removal of gaseous pollutants such as smoke, odors, and other volatile organic compounds. Strong degradation of indoor decoration pollution, such as formaldehyde, benzene, and more. The Airgle AG500/600/800/900 Air Cleaning Systems Parameters ® AG500 AG600 AG800 AG900 Model 33.2 lbs...
- Page 8 5. For your future convenience, record the model information here. Model information can be found on the name plate located on the bottom of your unit. Model Number: Purchase Date: QR Code: AG500/600 Pre-Installed Filters View: Titanium Pro UV is installed horizontally ® Pre-Installed Filters: AG500: HEPAFast Filter + Gas &...
-
Page 9: Choosing A Suitable Location
® Introduction to Airgle ® Install the supplied casters as follows: 1) Carefully insert the caster stem into receptor tube vertically. 2) Press on the caster until it aligns with the bottom. Repeat steps 1) and 2) with the remaining casters. - Page 10 ® Introduction to Airgle ® Home office or den: Keeping your system in your home office or den will certainly clean the air in that room – but probably only that room. Be sure to have at least one foot of...
-
Page 11: Connecting To Power
® Introduction to Airgle ® CONNECTING TO POWER ter r After selecting the best location for your air cleaning system and clearing the space around where it will stay, connect the power cord to the unit and the other end into the socket. - Page 12 AIRGLE AIR CLEANER COMPONENTS ® AG500/AG800 Filter Components Showing 5 and 6 here AG600/AG900 Filter Components showing 4, 5 and 6 here Sensor: Monitors the amount of particles in the room to determine airflow activity (if unit is on auto).
- Page 13 ® The art of purification HOW THE AIRGLE ® SYSTEM WORKS Room air is drawn into the system via the rear grill. The process begins when air moves through the Gas & Odor filter, which captures the large particles and VOCs that are adding to air pollution.
-
Page 14: Using The Control Panel
® The art of purification USING THE CONTROL PANEL USING THE CONTROL PANEL The Airgle system is equipped with a state-of-the-art control panel. This advanced control ® panel allows you to assess the unit’s status with one quick glance. Mode... - Page 15 ® The art of purification Air Quality: The Airgle system is equipped with an advanced air quality monitoring sensor. ® The Air Quality Gauge displays the quality of the air in the room – the air you breathe. The six status bars indicate the quality from Unhealthy (one bar) to Good (six bars).
- Page 16 4. Power/Speed: When the air cleaner is turned off, the “Power Off” indicator will display as red, and the fan speed indicator will be off. To turn the system on, rotate the Power/Speed knob counterclockwise or clockwise to select a speed from 1 to 5. The default speed for AG500/600 starts from “1” and for AG800/...
-
Page 17: Control Setting
For advanced users only: 1. When you use Models AG500/AG600, make sure the units are powered on (plug in the units and confirm the knob is at the “Speed 1 to 5” position). When you use models AG800/AG900, make sure the units are on standby mode (plug in the units, and confirm the knob is at the “power off”... - Page 18 ® The art of purification 3. If you release the Timer button (for AG500/AG600) or the “Auto” button (for AG800/AG900) when “High” is blinking, the system is set to High Mode. Answer the following questions to assess whether you need to change your control setting:...
-
Page 19: Using The Remote Control
Mode: Change the mode to Auto or Sleep. Press the Mode button (for AG500/AG600) or the “Auto” button (for AG800/AG900). You can turn on/off the UV lamp for AG500/600 if held down for five seconds . Speed: Regulate fan speed from 1 to 5. AG500/600... -
Page 20: Filter Removal
Gas & Odor filter, HEPAfast filter, or Titanium UV (if your model is AG600 or AG900). ® 1 pull up 、 2 pull out 、 Open Rear Door Remove Filters (AG500/800 Models) Remove Filters and UV (AG600/900 Models) -
Page 21: Replacing The Filters
® The art of purification Replacing Filters Replace the Titanium Pro UV (Models ® AG600/AG900 only), Gas & Odor filter, and HEPAfast filter (cHEPA filter for AG600/AG900) in reverse order of removal, making sure the pull ribbon is facing left towards the rear door when finished. - Page 22 “Reset” button on the Control Panel to reset. The “light bulb” will stop blinking. Cleaning the Housing and Sensor Our unique Airgle system design includes a rear ® door with a grill that acts as a filter for human hair and large particles.
-
Page 23: Environmentally-Friendly Disposal
® The art of purification WARRANTY TIPS: Airgle Corporation offers a Five Year Limited Warranty on Airgle Series air cleaners. To activate your warranty, ® please scan the QR code label on the package or visit us on the web at www.airgle.com...
