Insert SIM card

By pressing of yellow button release the SIM card holder.
Insert the SIM card and replace the SIM card holder.

Insert antenna

The available place for installation select up following point of view:
1. Distance from PBX lines –
possibility of GSM interferences
2. Main 230 V for power supply of BlueGate ISDN Brave
3. Quality of GSM signal at the installation place
Correctly connect USB cable
and ISDN lines
Connect device to main 230V
INPUT : 100-240V 0.7A 50/60Hz
OUTPUT : 5V 3A
DC Plug Dimension : 5.5mm x 2.5mm.
Set initial parameters of Bluegate ISDN Brave Configuration SW on the PC
to work device correctly.
Start Bluegate ISDN Brave Configuration
Click on New File
