La Crosse Technology 404-1235UA-PL Manual

14" ULTRATOMIC WALL CLOCK
Model: 404-1235UA-PL | 404-1235UA-SS
DC:032218
POWER UP
1. Slide the Time Zone Switch to your time zone.
PT = Pacific, MT = Mountain, CT = Central, ET = Eastern
2. Select DST (Daylight Saving Time) setting ON/OFF.
When ON is selected, the clock will automatically adjust
for DST (most common).
3. Insert two or four fresh "C", batteries according to
the polarity markings. Four batteries will extend battery
life.
Important: When batteries are installed, the hands will
move to 4 o'clock, 8 o'clock, or 12 o'clock position and the
clock will start receiving the Atomic Time signal from
Colorado. When signal is received, the hands will move to
the correct time for the selected time zone.
Manual
Time Set
Set
DST Q-Mode
ON Q-Run
OFF Q-Set
DST ON/OFF
Page | 2
MANUAL TIME SET
1. Set DST switch to the OFF (Q-Set) and Time Zone switch to
the Q-MODE. The movement will move to 4, 8 or 12 o'clock
position and stop.
2. Press and release the SET button to change the time slowly.
Hold the SET button to set the time quickly.
3. When time is set, slide the DST switch to ON (Q-RUN)
position. The second hand will start running from 12:00 and
the clock will keep time as manually set.
FEATURES
Custom Time Zone Setting:
Select time zones from +0 UTC to -11 UTC.
1. Slide Time Zone Switch to CUSTOM ET.
2. Press and release Manual Time Set button to advance time
in one hour increments until you reach desired time.
Eco-Mode:
Eco-mode is a battery saving feature.
·
Time
When ON is selected: between the hours of 11pm-5am, the
·
Zone
second hand will stop at 12:00. The second hand will resume
running at 5am.
When OFF is selected: the second hand runs normally.
·
ECO Mode
Eco Mode
ON
Low Battery Indication:
ON/OFF
OFF
When the batteries are low the second hand will stop at 6:00
and the hour and minutes hands will run as usual.
Page | 3
